- Page 1 ORTOLED QB-EVO LED GROW LIGHT INSTRUCTION MANUAL...
- Page 2 1. Picture of products Product and recommended application ORTOLED-89-QBEVO-150W Model no. Dimension 358*357*40MM Power 150W Application Indoor growing Recom. Height 40-70CM ORTOLED-90-QBEVO-240W Model no. Dimension 500*500*43MM Power 240W Application Indoor growing Recom. Height 40-70CM ORTOLED-90-QBEVO-240W Model no. Dimension 500*620*48MM Power...
- Page 3 2. Delivery contents - 1 x LED Grow Light - 1 x Power Cable - 1 x 3m long RJ11 Signal Cable - 2 x Adjustable Hanging Kits + 2 x Un-adjustable Hanging Kits Please keep the instruction manual and desist from throwing it away. It might come in handy with future troubleshooting.
- Page 4 Driver Dimming Knob Signal output Master/Slave switch Signal input 4. Product Datasheet 4.1 Product Specification Model ORTOLED-91-QBEVO-320W ORTOLED-90-QBEVO-240W ORTOLED-89-QBEVO-150W Power Consumption 150W 240W 320W Product Size 358*357*40mm 500*500*43mm 500*620*48mm N.W/G.W 1.87KG/2.79KG 2.6KG/4.5KG 3.8KG/5.6KG Packing size 410*90*445mm 550*90*580mm 550*95*710mm Samsung lm201b 3000K 5000K LEDs + Honglitronic SMD3535 3w 660nm...
- Page 5 4.2 Spectrum Signal 5. Control Control Method: 1. Single led fixture: Switch to master button, use the dimming knob to dimming. Notice: If switch to slave button, the dimming knob will not functional.
- Page 6 2. Multi-led fixture: Step one: Choose one light as master, and the other lights as slaves Step two: Use the dimming knob to dimming, all the slaves will be controlled by master. 3．Existing 0-10V Controller to control the fixtures: Step one: use RJ12 cable to connect the controller and fixture Step two: switch all the fixture to slave (max.
- Page 7 Through transport or due to a long storage time, the LED-modules might get a little polluted. Therefore we recommend to clean the modules before each use with a dry and soft tissue. 7. Operation 7.1 Safety measures & precaution Warning! This LED fixture is powered with electricity (AC100-250V)! To prevent injury, we ask you to desist from improper use! ••...
- Page 8 www.ortoled.com...
