ORTOLED -81-720 Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Prodotto e consigli per l'utilizzo
ORTOLED S LINE
Cod. Modello
Dimensioni
Consumo
Applicazione
Distanza minima
Cod. Modello
Dimensione
Consumo
Applicazione
Distanza minima
Cod.Modello
Dimensione
Consumo
Applicazione
Distanza minima
ORTOLED-81-720
900x900x85mm
720W
Serre indoor
40-50cm
ORTOLED-82-720V
1100X1100X85mm
720W
Vertical farming
15-25cm
ORTOLED-83-960
1100x1100x85mm
960W
Serre indoor
40-50cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ORTOLED-81-720 and is the answer not in the manual?

Questions and answers

Related Manuals for ORTOLED ORTOLED-81-720

Summary of Contents for ORTOLED ORTOLED-81-720

  • Page 1 ORTOLED S LINE Prodotto e consigli per l'utilizzo Cod. Modello ORTOLED-81-720 Dimensioni 900x900x85mm Consumo 720W Applicazione Serre indoor 40-50cm Distanza minima Cod. Modello ORTOLED-82-720V Dimensione 1100X1100X85mm Consumo 720W Applicazione Vertical farming 15-25cm Distanza minima Cod.Modello ORTOLED-83-960 Dimensione 1100x1100x85mm Consumo 960W...

  • Page 2: Delivery Contents

    Delivery contents 6/8 x LED bars 1 x driver box 1 x power cable 1 x 3m long RS485 cable 2 x Adjustable hanging kits Please keep the instruction manual and desist from throwing it away. It might come in handy with future troubleshooting.

  • Page 3: Product Data Sheet

    Fixed bracket Plastic part 3. Product Datasheet: 3.1 Product specifications ORTOLED-83-960 ORTOLED-82-720V ORTOLED-81-720 Item LED bar qty. 6x LED bars 6x LED bars 8x LED bars Product Size 900*900*85mm 1100*1100*85mm 1100*1100*85mm N.W./ G.W. 14.25KG/16.10KG 16.50KG/18.00KG 19.75KG/22.25KG Power consumption 720W 720W...
  • Page 4 3.2 Spectrum 4. Control 4.1 control diagram: 4.2 Control function: - Timer setting - Dimming control - High Temp Protection - For Large Application up to 252units - Perfect simulation of sunrise and sunset...

  • Page 5: Installation Instruction

    5. Preparation • Transportation Improper transportation may harm or can even cause damage to LED lamp and power housing box). In case of obvious damage or incomplete scope of supply, please refer to your vendor and Haulage company immediately. • Unboxing Please handle and unbox the LED lamp with care! Check the delivery contents for completeness first.
  • Page 6 7. DC distribution DIAGRAM S-8-960： S-6-720: Caution: Do not remove single bar from one group of one driver while S-720/960 is still powered on, rest bar (s) of the group may get burnt by current overloading.

  • Page 7: Operation

    8. Operation 8.1 Safety measures & precaution Warning! This LED fixture is powered with electricity (AC100-277V)! To prevent injury, we ask you to desist from improper use! •• Never open the case of the device! Health hazards await the consumer and the warranty of the device expires.

This manual is also suitable for:

Ortoled-82-720vOrtoled-83-960
