CUBE-ST
CUBE-ST-R
Table of Contents
Cautionary Notes ..............................................................2
Specifications .....................................................................3
Difference between CUBE-ST and CUBE-ST-R ............3
Location of Controls .........................................................4
Location of Controls Parts List........................................5
Exploded View ..................................................................6
Exploded View Parts List.................................................8
Parts List ...........................................................................10
Checking Version Number ............................................12
Revise Information
2008. 01. 25
p. 10
Copyright © 2007 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
Added
symbols.
17058510E0
SERVICE NOTES
Issued by RJA
Test Mode .........................................................................12
Block Diagram .................................................................14
Circuit Board (Main, Jack, Input, Mic Board) .............16
Circuit Diagram (Main Board: 1/3, Jack Board) .........18
Circuit Diagram (Main Board: 2/3) ..............................20
Circuit Diagram (Main Board: 3/3) ..............................22
Circuit Diagram (Input, Mic Board) .............................24
Circuit Board (Panel, Pedal Board)...............................26
Circuit Diagram (Panel, Pedal Board)..........................28
Printed in Japan (0370) (SC-KWS)
CUBE-ST/CUBE-ST-R
Advertisement
Table of Contents
Related Manuals for Roland CUBE-ST
Summary of Contents for Roland CUBE-ST
-
Page 1: Table Of Contents
Cautionary Notes ..............2 Test Mode .................12 Specifications ..............3 Block Diagram ..............14 Difference between CUBE-ST and CUBE-ST-R ....3 Circuit Board (Main, Jack, Input, Mic Board) .....16 Location of Controls ............4 Circuit Diagram (Main Board: 1/3, Jack Board) ..18 Location of Controls Parts List........5 Circuit Diagram (Main Board: 2/3) ......20... -
Page 2: Cautionary Notes
Sep. 2007 CUBE-ST/CUBE-ST-R Cautionary Notes Before beginning the procedure, please read through this document. The matters described may differ according to the model. No User Data This product cannot save user data. Backing up user data during servicing is not required. -
Page 3: Specifications
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice. Difference between CUBE-ST and CUBE-ST-R CUBE-ST-R is different from CUBE-ST in the following parts. Other specifications are all same. CUBE-ST CUBE-ST-R... -
Page 4: Location Of Controls
Sep. 2007 CUBE-ST/CUBE-ST-R Location of Controls fig.panel1.eps_50 fig.panel2.eps_50... -
Page 5: Location Of Controls Parts List
Sep. 2007 CUBE-ST/CUBE-ST-R Location of Controls Parts List Part Code Part Name Description Q’ty SD000911 POTENTIOMETER RD901F-40E1-15F-0B10K-00DM8 SD000043 R-KNOB W/HOT STAMP 17048630 VR ACCESSORY NUT M9 40452178 VR WASHER M9 SD001038 LED GREEN L-710XVGD-E-SZ SD001037 LED RED L-710XSURD-E-SZ 02456390 3.5MM JACK... -
Page 6: Exploded View
Sep. 2007 CUBE-ST/CUBE-ST-R Exploded View fig.bunkai.eps@L... - Page 7 Sep. 2007 CUBE-ST/CUBE-ST-R fig.bunkai.eps@R...
-
Page 8: Exploded View Parts List
Part Name Description Q’ty SD000017 BADGE SD001028 GRILL SILVER (for CUBE-ST) SD001029 GRILL BRIGHT SILVER (for CUBE-ST-R) SD001030 CABINET ASSY BLACK (for CUBE-ST) SD001031 CABINET ASSY RED (for CUBE-ST-R) * The CABINET ASSY includes the following parts. SD001026 TRIM SASH... - Page 9 Sep. 2007 CUBE-ST/CUBE-ST-R Screws Part Code Part Name Description Q’ty SD000067 SCREW 3X12 TRUSS TAPTITE A1 BZC 40010134 SCREW M4X20 BINDING MACHINE BZC 40010567 SCREW M4X35 SPECIAL TRUSS BZC SD000069 WASHER M4 11FAI ADDITIONAL WASHER 40230789 SCREW 3X10 OVALHEAD MACHINE BZC...
-
Page 10: Parts List
SD001031 CABINET ASSY RED (for CUBE-ST-R) SD001022 CHASSIS ASSY 22365714 CORD HOOK SD001028 GRILL SILVER (for CUBE-ST) SD001029 GRILL BRIGHT SILVER (for CUBE-ST-R) SD000035 HANDLE WITH ESCUTHEON SD001026 TRIM SASH KNOB, BUTTON SD000043 R-KNOB W/HOT STAMP SD000906 KEYTOP SD000082 PUSH BUTTON... - Page 11 ADDITIONAL WASHER SD000916 WASHER M9 T=2.5 PACKING SD001044 PACKING PAD UPPER SD001045 PACKING PAD LOWER SD001042 PACKING CASE for CUBE-ST SD001043 PACKING CASE for CUBE-ST-R MISCELLANEOUS SD000446 HIMERON 87-YP5-228-01 4X15XT0.25 SD000464 HIMERON W/ADH 6 X 50 X 0.5T BADGE SD000418...
-
Page 12: Checking Version Number
When the result of test is OK: Turn off the power of the CUBE-ST. LEDs of Left, Center and Right blink. When the result of test is NG: LED of TUNER blinks. - Page 13 Sep. 2007 CUBE-ST/CUBE-ST-R 2. Switch Test 3. Volume Test When entering Switch Test, all LEDs go off temporarily. When entering Volume Test, all LEDs go off temporarily. Operate buttons, rotary switches, plugs and foot switches as the order in the Operate the following knobs minimum–center–maximum and confirm the all...
-
Page 14: Block Diagram
Sep. 2007 CUBE-ST/CUBE-ST-R Block Diagram fig.block.eps@L... - Page 15 Sep. 2007 CUBE-ST/CUBE-ST-R fig.block.eps@R...
-
Page 16: Circuit Board (Main, Jack, Input, Mic Board)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Board (Main, Jack, Input, Mic Board) fig.b-main-components.eps... - Page 17 Sep. 2007 CUBE-ST/CUBE-ST-R fig.b-main-foil.eps...
-
Page 18: Circuit Diagram (Main Board: 1/3, Jack Board)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Diagram (Main Board: 1/3, Jack Board) fig.c-main1.eps@L... - Page 19 Sep. 2007 CUBE-ST/CUBE-ST-R fig.c-main1.eps@R...
-
Page 20: Circuit Diagram (Main Board: 2/3)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Diagram (Main Board: 2/3) fig.c-main2.eps@L... - Page 21 Sep. 2007 CUBE-ST/CUBE-ST-R fig.c-main2.eps@R...
-
Page 22: Circuit Diagram (Main Board: 3/3)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Diagram (Main Board: 3/3) fig.c-main3.eps@L... - Page 23 Sep. 2007 CUBE-ST/CUBE-ST-R fig.c-main3.eps@R...
-
Page 24: Circuit Diagram (Input, Mic Board)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Diagram (Input, Mic Board) fig.c-input-mic.eps@L... - Page 25 Sep. 2007 CUBE-ST/CUBE-ST-R fig.c-input-mic.eps@R...
-
Page 26: Circuit Board (Panel, Pedal Board)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Board (Panel, Pedal Board) fig.b-panel-pedal.eps@L... - Page 27 Sep. 2007 CUBE-ST/CUBE-ST-R fig.b-panel-pedal.eps@R...
-
Page 28: Circuit Diagram (Panel, Pedal Board)
Sep. 2007 CUBE-ST/CUBE-ST-R Circuit Diagram (Panel, Pedal Board) fig.c-panel-pedal.eps@L... - Page 29 Sep. 2007 CUBE-ST/CUBE-ST-R fig.c-panel-pedal.eps@R...
- Page 30 Sep. 2007 CUBE-ST/CUBE-ST-R...
- Page 31 Sep. 2007 CUBE-ST/CUBE-ST-R...
- Page 32 Sep. 2007 CUBE-ST/CUBE-ST-R MEMO...
