OWNER'S MANUAL
COMMERCIAL DRYER
Before beginning installation, read these instructions carefully. this will
simplify installation and ensure that the dryer is installed correctly and
safely. leave these instructions near the dryer after installation for future
reference.
MODEL
RN1329AD1S / RV1329AD1S
RN1329AD5S / RV1329AD5S
RN1329AD6S / RV1329AD6S
P/NO. : MFL62512875
RN1329AN4S / RV1329AN4S
RN1329AN7S / RV1329AN7S
RN1329AN1S / RV1329AN1S
RN1329A4S / RV1329A4S
RN1329A7S / RV1329A7S
RN1329A1S / RV1329A1S
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RV1329AD1S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG RV1329AD1S

Summary of Contents for LG RV1329AD1S

  • Page 1 Before beginning installation, read these instructions carefully. this will simplify installation and ensure that the dryer is installed correctly and safely. leave these instructions near the dryer after installation for future reference. MODEL RN1329AD1S / RV1329AD1S RN1329AN4S / RV1329AN4S RN1329A4S / RV1329A4S RN1329AD5S / RV1329AD5S RN1329AN7S / RV1329AN7S...

  • Page 2: Product Features

    PRODUCT FEATURES PRODUCT FEATURES OUTSTANDING PERFORMANCE The dryer features the largest capacity, quick drying times, quiet operation, and an energy-saving system. ARTISTIC DESIGN Modern front panel look and big clear glass door make your dryer look stylish EASY OF USE An entire selection of user-friendly functions makes operating the dryer easy.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, Injury to persons, or death. Your Safety and the safety of others is very important.

  • Page 4: Basic Safety Precautions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE BASIC SAFETY PRECAUTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Read all instructions before using the dryer. •...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE disposal of your old appliance 1. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 2.

  • Page 6: Grounding Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. GROUNdING INSTRUCTIONS This appliance must be grounded.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR INSTALLATION •...

  • Page 8: Safety Instructions For Connecting Electricity

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,...
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE CAUTION These instructions are only valid if the following country code is on the appliance. If this code is not present on the appliance, it is necessary to refer to the technical instructions which will provide the necessary information concerning the modification of the appliance to the condition of use for the country Before installation, check that the local distribution conditions, nature of gas and pressure, and the adjustment of the appliance are compatible.

  • Page 10: Table Of Contents

    CONTENTS CONTENTS PRODUCT FEATURES Programming Mode - Collect Mode IMPORTANT SAFETY 46 MAINTENANCE INSTRUCTIONS BASIC SAFETY PRECAUTIONS 47 STACK MACHINE INSTALLATION GROUNDING INSTRUCTIONS INSTRUCTIONS SAFETY INSTRUCTIONS FOR INSTALLATION SAFETY INSTRUCTIONS FOR CONNECTING Suitable model for stacking ELECTRICITY Sliding kit Stacking kit INTRODUCING YOUR DRYER Stacking the machine Stacking bracket installation...

  • Page 11: Introducing Your Dryer

    INTRODUCING YOUR DRYER INTRODUCING YOUR DRYER Specifications ■ Type : Electric and Gas Dryer ■ Rating : Please refer to the rating label regarding detailed information. ■ Single dryer size : 686mm(W) x 764mm(D) x 983mm(H) ■ Stack dryer size : 686mm(W) x 764mm(D) x 1954mm(H) ■...

  • Page 12: Control Panel Features

    INTRODUCING YOUR DRYER Control panel features ■ Card type - Side by side(RN1329Ad1S / Rv1329Ad1S) - Stack upper(RN1329Ad5S / Rv1329Ad5S) - Stack lower(RN1329Ad6S / Rv1329Ad6S) ■ OPL type - Side by side(RN1329A4S / Rv1329A4S) - Stack upper(RN1329A7S / Rv1329A7S) - Stack lower(RN1329A1S / Rv1329A1S) 1.
  • Page 13 INTRODUCING YOUR DRYER Control panel features ■ Coin type - Side by side (RN1329AN4S / Rv1329AN4S) - Stack upper (RN1329AN7S / Rv1329AN7S) - Stack lower (RN1329AN1S / Rv1329AN1S) 1. display LEd 3. Start button 2. Cycle button 4. Status LEd...
  • Page 14 INTRODUCING YOUR DRYER Status LEd display LEd Cycle button Start button display LEd Start button The Display shows the vend price, remaining time, and The Start LED flashes when the full vend price has been programming options. satisfied then the cycle has been chosen or the machine Error codes are also displayed here.

  • Page 15: Operating Your Dryer

    OPERATING YOUR DRYER OPERATING YOUR DRYER 1. Ready mode 4. Top off (To add more time) 1) Coin / Card type ■ After a debit card is inserted, the operating time can - The cycle LEDs flash at the same time, when the be increased to 10 minutes/10p (default), when the price of cycles are equal.

  • Page 16: Programming Mode

    PROGRAMMING MODE PROGRAMMING MODE 1. Programming mode You can check machine information or change setting on Program setup or Diagnostic test. There are two methods that you can enter programming mode. ■ how to enter “Programming mode” ■ how to use button You can enter programming mode only for Idle state You can change Dryer vend price, cycle time and Cycle and pause state.
  • Page 17 PROGRAMMING MODE Card / Coin type ■ Algorithm Flow Chart shows how to control programming mode. ■ Before program set, check the structure of programming mode. 1. Turn on/off toggle switch or Insert the service card to entering set up mode. 2.
  • Page 18 PROGRAMMING MODE OPL type ■ Algorithm Flow Chart shows how to control programming mode. ■ Before program set, check the structure of programming mode. OPL/Coin Type 1) Push the High Temp. and Low Temp. button at the same time. 2) Push the Med Temp. button 3 times. 3) Push the Start button.

  • Page 19: Programming Mode - Setup Mode

    PROGRAMMING MODE PROGRAMMING MODE - Setup Mode Setup Mode : (display) ■ You can change dryer vend price, cycle time, and cycle parameters, etc. ■ Entering set up mode • Coin type - Turn on/off toggle switch. • Card type - Insert the service card. •...

  • Page 20: 20 2. How To Change Special Price

    PROGRAMMING MODE 2. how to change special price Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 21: 21 3. How To Enter The Fea1

    PROGRAMMING MODE 3. how to enter the Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
  • Page 22 PROGRAMMING MODE 3-1. Special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
  • Page 23 PROGRAMMING MODE 3-2. vend type setup - card type or coin type setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
  • Page 24 PROGRAMMING MODE 3-3. Top off apply or not setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 25: 25 4. How To Enter The Special Price Day Setup

    PROGRAMMING MODE 4. how to enter the special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
  • Page 26 PROGRAMMING MODE 4-1. how to change sunday Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 27: Special Price Beginning Time Setup

    PROGRAMMING MODE 5. Special price beginning time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 28: Special Price Ending Time Setup

    PROGRAMMING MODE 6. Special price ending time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 29: 29 7. Regular Priced Dryer Cycle Time

    PROGRAMMING MODE 7. Regular priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 30: 30 8. Special Priced Dryer Cycle Time

    PROGRAMMING MODE 8. Special priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.

  • Page 31: Value Of Coin

    PROGRAMMING MODE 9. value of coin 1 Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
  • Page 32 PROGRAMMING MODE 10. value of coin 2 (Set up for top off price and e-suds coin pulse) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display.

  • Page 33: Penny Increment Pricing Offset

    PROGRAMMING MODE 11. Penny increment pricing offset This represents the cent increment price offset used when debit card is setup. Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display.

  • Page 34: Top Off Time

    PROGRAMMING MODE 12. Top off time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.

  • Page 35: Beep Volume

    PROGRAMMING MODE 13. Beep volume Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.

  • Page 36: Time To Keep The Coin (Use Only For Coin Type)

    PROGRAMMING MODE 14. Time to keep the coin (Use only for coin type) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.

  • Page 37: 15. Product Type Setup - Coin/Card Type Or Opl Setup

    PROGRAMMING MODE 15. Product type setup – coin/card type or OPL setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.

  • Page 38: Programming Mode - Test Mode

    PROGRAMMING MODE PROGRAMMING MODE - Test Mode diagnostic tests : (display) This program has been added for testing the dryer and detecting errors. Entering the test mode data Machine Button display description Name 1. Entering Insert service card (card type), Turn on/off toggle switch programming (Coin type).
  • Page 39 PROGRAMMING MODE Pressing the Start button cycles to the next test function. Number of times the Start Checking point display button is pressed None LqC 1 Check the version and code of Version and code of machine (All LED on) machine.

  • Page 40: 40 2. Factory Reset - Eept

    PROGRAMMING MODE 2. Factory reset - EEPt After a factory reset, all values are reset to the default values. Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button.

  • Page 41: Time Set Up

    PROGRAMMING MODE 3. Time Set Up Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. The display cycles through 2000 --> 0101 --> Sat --> 0000. Press the Start button.

  • Page 42: Courtesy Cycle

    PROGRAMMING MODE 4. Courtesy cycle Courtesy cycle is like a complimentary cycle given to the customer when the dryer goes out of order when the customer has made the payment to dry one’s clothes. Entering set up Button display mode. You will see LqC1 Press the Med Temp.

  • Page 43: Cycle Kill

    PROGRAMMING MODE 5. Cycle Kill ■ Coin Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button. Press the Med Temp. button until appears in the display.

  • Page 44: Programming Mode - Collect Mode

    PROGRAMMING MODE PROGRAMMING MODE - Collect Mode Collect Information data : CLCt (display) The dryer collects the usage data so that the owner can check various information like number of various cycles used, how many times card or coins used, etc. Entering the collect mode data Name Button...
  • Page 45 PROGRAMMING MODE ■ Collect Mode data lists Abbreviation Meaning description Itnr Interval No Runs Itnr is not available in dryer. Ittb Interval Trouble Cycles Money inserted, but no run. ItPd Interval Power Downs No money, but ran. Interval Unauthorized Service Door Number of Unauthorized Service Door Itdd Openings...

  • Page 46: Maintenance

    T : 030-25-85-077 (4 linee r.a.) water and allow to dry thoroughly before reinstalling. Maglione is the distributer & service in ITALY LG Electronics Service Europe B.V. Krijgsman1, 1186 DM Amstelveen, the Netherlands T : 31-20-456-3132 BIJELI SVIJET d.o.o.

  • Page 47: Stack Machine Installation Instructions

    STACK MACHINE INSTALLATION INSTRUCTIONS STACK MACHINE INSTALLATION INSTRUCTIONS 1. Suitable model for stacking Upper Lower Stack position dryer Washer dryer RN1329Ad5S F1069Fd6 RN1329Ad6S RN1329AN7S F1069Fd RN1329AN1S RN1329A7S F1069Fd2 RN1329A1S Stack position Rv1329Ad5S F1069Fd6 Rv1329Ad6S Rv1329AN7S F1069Fd Rv1329AN1S Rv1329A7S F1069Fd2 Rv1329A1S 2.

  • Page 48: Stacking The Machine

    STACK MACHINE INSTALLATION INSTRUCTIONS 4. Stacking the machine - Lift and stack the upper dryer on the lower washer. - Set the rear of the upper dryer and the rear of the lower washer in the same position. - Push the upper dryer matching the slide & stacking bracket to make upper and lower front parallel. 5.

  • Page 49: Error Mode

    ERROR MODE / POWER FAIL RECOVERY / DEFAULT DRYER SETTINGS ERROR MODE ■ Meaning of Error Codes that LEd displays during occurrence or problem. dryer error code PROBLEM POSSIBLE CAUSE SOLUTION It is displayed when thermistor is opened or Thermistor should be replaced. shorted It is displayed when thermistor temperature have increased about 17 degrees for 10...

  • Page 50: Declaration Of Conformity
