PRODUCT FEATURES PRODUCT FEATURES OUTSTANDING PERFORMANCE The dryer features the largest capacity, quick drying times, quiet operation, and an energy-saving system. ARTISTIC DESIGN Modern front panel look and big clear glass door make your dryer look stylish EASY OF USE An entire selection of user-friendly functions makes operating the dryer easy.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, Injury to persons, or death. Your Safety and the safety of others is very important.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE BASIC SAFETY PRECAUTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: Items that have been soiled with •...
Page 5
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WhAT IS NOT COvEREd. Service trips to your home to instruct you on the product. If the product is connected to any voltage other than that shown on the rating plate. If the fault is caused by accidents, neglects, misuses of Acts of God.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. GROUNdING INSTRUCTIONS This appliance must be grounded.
Page 7
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR INSTALLATION The appliance must not be •...
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,...
Page 9
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE CAUTION These instructions are only valid if the following country code is on the appliance. If this code is not present on the appliance, it is necessary to refer to the technical instructions which will provide the necessary information concerning the modification of the appliance to the condition of use for the country Before installation, check that the local distribution conditions, nature of gas and pressure, and the adjustment of the appliance are compatible.
INTRODUCING YOUR DRYER INTRODUCING YOUR DRYER Specifications Type : Electric Dryer Rating : Please refer to the rating label regarding detailed information. Single dryer size : 686mm(W) x 764mm(D) x 983mm(H) Stack dryer size : 686mm(W) x 764mm(D) x 1954mm(H) Electric Dryer Max capacity : 10kg Weight : 59.4 kg A-weighted emission sound pressure level : <...
INTRODUCING YOUR DRYER Accessories OPL sheet (only for OPL type) Control panel features Card type - Side by side(Rv1329Cd4P) - Stack upper(Rv1329Cd7P) - Stack lower(Rv1329Cd1P) OPL type 1. display LEd 3. Start/Pause button 2. Cycle button 4. Status LEd...
Page 13
INTRODUCING YOUR DRYER Control panel features Coin type - Side by side (Rv1329CN4P) - Stack upper (Rv1329CN7P) - Stack lower (Rv1329CN1P) 1. display LEd 3. Start/Pause button 2. Cycle button 4. Status LEd...
Page 14
INTRODUCING YOUR DRYER Status LEd display LEd Cycle button Start/Pause button display LEd Start/Pause button The Display shows the vend price, remaining time, and The Start LED flashes when the full vend price has been programming options. satisfied then the cycle has been chosen or the machine Error codes are also displayed here.
OPERATING YOUR DRYER OPERATING YOUR DRYER 1. Ready mode 4. Top off (To add more time) 1) Coin / Card type After a debit card is inserted, the operating time can - The cycle LEDs flash at the same time, when the price be increased to 10 minutes/10p (default), when the of cycles are equal.
PROGRAMMING MODE PROGRAMMING MODE 1. Programming mode You can check machine information or change setting on Program setup or Diagnostic test. There are two methods that you can enter programming mode. how to enter “Programming mode” how to use button You can enter programming mode only for Idle state You can change Dryer vend price, cycle time and Cycle and pause state.
Page 17
PROGRAMMING MODE Card / Coin type Algorithm Flow Chart shows how to control programming mode. Before program set, check the structure of programming mode. 1. Turn on/off toggle switch or Insert the service card to entering set up mode. 2. Press high Temp. button to move the upper level. 3.
Page 18
PROGRAMMING MODE OPL type Algorithm Flow Chart shows how to control programming mode. Before program set, check the structure of programming mode. 1) Push the high Temp. and Low Temp. button at the same time. 2) Push the Med Temp. button 3 times. 3) Push the Start button.
PROGRAMMING MODE PROGRAMMING MODE - Setup Mode Setup Mode : (display) You can change dryer vend price, cycle time, and cycle parameters, etc. Entering set up mode • Coin type - Turn on/off toggle switch. • Card type - Insert the service card. •...
PROGRAMMING MODE 2. how to change special price Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 3. how to enter the Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 22
PROGRAMMING MODE 3-1. Special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 23
PROGRAMMING MODE 3-2. vend type setup - card type or coin type setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
Page 24
PROGRAMMING MODE 3-3. Top off apply or not setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 25
PROGRAMMING MODE 3-4 Sense dry apply or not setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 4. how to enter the special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
Page 27
PROGRAMMING MODE 4-1. how to change sunday Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 5. Special price beginning time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 6. Special price ending time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 7. Regular priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 8. Special priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 9. value of coin 1 Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 33
PROGRAMMING MODE 10. value of coin 2 (Set up for top off price and e-suds coin pulse) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 11. Penny increment pricing offset This represents the cent increment price offset used when debit card is setup. Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 12. Top off time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 13. Beep volume Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 14. Time to keep the coin (Use only for coin type) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
Page 38
PROGRAMMING MODE 15. how to enter the Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE PROGRAMMING MODE - Test Mode diagnostic tests : (display) This program has been added for testing the dryer and detecting errors. Entering the test mode data Name Button display description Insert service card (card type)Turn on/off toggle switch (coin type) 1.
PROGRAMMING MODE 2. Factory reset - EEPt After a factory reset, all values are reset to the default values. Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button.
PROGRAMMING MODE 3. Time Set Up Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. The display cycles through 2000 --> 0101 --> Sat --> 0000. Press the Start button.
PROGRAMMING MODE 4. Courtesy cycle Courtesy cycle is like a complimentary cycle given to the customer when the dryer goes out of order when the customer has made the payment to dry one’s clothes. Entering set up Button display mode. You will see LqC1 Press the Med Temp.
PROGRAMMING MODE 5. Cycle Kill Coin type Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button. Press the Med Temp. button until appears in the display.
PROGRAMMING MODE PROGRAMMING MODE - Collect Mode Collect Information data : CLCt (display) The dryer collects the usage data so that the owner can check various information like number of various cycles used, how many times card or coins used, etc. Entering the collect mode data Name Button...
Page 45
PROGRAMMING MODE Collect Mode data lists Abbreviation Meaning description Itnr Interval No Runs Itnr is not available in dryer. Ittb Interval Trouble Cycles Money inserted, but no run. ItPd Interval Power Downs No money, but ran. Interval Unauthorized Service Door Number of Unauthorized Service Door Itdd Openings...
MAINTENANCE MAINTENANCE Regular cleaning Cleaning the Lint Filter Always clean the lint filter after every cycle. WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Unplug the dryer before cleaning to avoid the risk of electric shock.
Rv1329CN7P Fh069Fd6F Rv1329CN1P Model Name Rv1329Cd7P Fh069FdF Rv1329Cd1P 2. Sliding kit - Sliding kit is provided in the upper dryer. - Sliding kit includes the slide bracket(2), sliding pad(4), screw(10), machine screw(8). 1) Sliding bracket 2) Sliding pad 3) Screw...
STACK MACHINE INSTALLATION INSTRUCTIONS 4. Stacking the machine - Lift and stack the upper dryer on the lower washer. - Set the rear of the upper dryer and the rear of the lower washer in the same position. - Push the upper dryer matching the slide & stacking bracket to make upper and lower front parallel. 5.
ERROR MODE / POWER FAIL RECOVERY / DEFAULT DRYER SETTINGS ERROR MODE Meaning of Error Codes that LEd displays during occurrence or problem. dryer error code PROBLEM POSSIBLE CAUSE SOLUTION It is displayed when thermistor is opened or Thermistor should be replaced. shorted It is displayed when thermistor temperature have increased about 17 degrees for 10...
Page 52
CARACTERÍSTICAS DEL PRODUCTO CARACTERÍSTICAS DEL PRODUCTO RENDIMIENTO EXCEPCIONAL La secadora cuenta con la mayor capacidad, tiempos de secado rápido, funcionamiento silencioso y un sistema de ahorro de energía. DISEÑO ARTÍSTICO Vista del panel frontal de diseño moderno y un cristal grande para hacer que su secadora se vea a la vanguardia. FACILIDAD DE USO Una selección completa de funciones amigables facilitan la operación de la secadora.
Page 53
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO ADVERTENCIA Para su seguridad, debe seguir la información de este manual para disminuir el riesgo de fuego, explosión, descargas eléctricas o para prevenir daños a la propiedad, lesiones a personas o pérdida de la vida. Su Seguridad y la Seguridad de Otros son muy importantes Hemos colocado muchos mensajes importantes de seguridad en este manual y en su aparato.
Page 54
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO PRECAUCIONES BÁSICAS DE SEGURIDAD ADVERTENCIA Para reducir el riesgo de fuego o descargas eléctricas o daños a las personas cuando se utilice este aparato, siga las precauciones básicas, incluyendo las siguientes: Los artículos que se han manchado con • Lea todas las instrucciones antes de utilizar la secadora.
Page 55
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO QUÉ NO ESTÁ CUBIERTO El servicio de mantenimiento a domicilio para impartir instrucciones sobre el producto. Si el producto está conectado a un voltaje distinto al que se muestra en la placa de características. Si la falla es causado por accidentes, descuido, mal uso de fuerza mayor.
Page 56
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO ADVERTENCIA Para su seguridad, debe seguir la información de este manual para disminuir el riesgo de fuego, explosión, descargas eléctricas o para prevenir daños a la propiedad, lesiones a personas o pérdida de la vida. INSTRUCCIONES DE CONEXIÓN DE TIERRA FISICA Este aparato debe conectarse a tierra física.
Page 57
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO ADVERTENCIA Para su seguridad, debe seguir la información de este manual para disminuir el riesgo de fuego, explosión, descargas eléctricas o para prevenir daños a la propiedad, lesiones a personas o pérdida de la vida. INSTRUCCIONES DE SEGURIDAD PARA LA INSTALACIÓN Que el electrodoméstico no • El aparato no debe ser utilizado por niños o personas...
Page 58
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO ADVERTENCIA Para su seguridad, debe seguir la información de este manual para disminuir el riesgo de fuego, explosión, descargas eléctricas o para prevenir daños a la propiedad, lesiones a personas o pérdida de la vida. INSTRUCCIONES DE SEGURIDAD PARA LA CONEXIÓN ELÉCTRICA ADVERTENCIA Para reducir el riesgo de fuego o descargas eléctricas o daños a las personas cuando se utilice este aparato, siga las...
Page 59
INSTRUCCIONES IMPORTANTES DE SEGURIDAD INSTRUCCIONES IMPORTANTES DE SEGURIDAD LEER TODAS LAS INSTRUCCIONES ANTES DE SU USO PRECAUCIÓN Estas instrucciones son válidas sólo si el siguiente código de país está en el electrodoméstico. Si este código no está presente en el electrodoméstico es necesario consultar las instrucciones técnicas que proporcionarán la información necesaria relativa a la modificación del electrodoméstico a la condición de uso para el país.
Page 60
CONTENIDO CONTENIDO CARACTERÍSTICAS DEL 14. Tiempo para mantener el valor de la PRODUCTO moneda (Sólo para tipo moneda) 15. Configuración del tipo de producto – Tipo Moneda/Tarjeta o OPL setup(Ajustes) MODO PROGRAMACIÓN - Modo de Prueba INSTRUCCIONES IMPORTANTES 1. Lqc1 DE SEGURIDAD 2.
PRESENTACIÓN DE SU SECADORA PRESENTACIÓN DE SU SECADORA Especificaciones Tipo : Secadora Eléctrica Voltaje : Por favor verifique las características eléctricas en la placa de datos de su producto Dimensiones : 6 86mm(W) x 764mm(D) x 983mm(H) Dimensiones Secadoras Apiladas : 6 86mm(W) x764mm(D) x 1954mm(H) Capacidad máxima de la secadora eléctrica : 10kg Peso : 59.4 kg Especificaciones sujetas a cambio por el fabricante. NOTA Especificaciones sujetas a cambio por el fabricante.
PRESENTACIÓN DE SU SECADORA Accesorios Hoja de OPL (sólo para el tipo OPL) Funciones del panel de control Tipo tarjeta - Lado a lado(RV1329CD4P) - Apilable Superior(RV1329CD7P) - Apilable Inferior(RV1329CD1P) Tipo OPL 1. DISPLAY 3. Botón de inicio / pausa 2. Selección de ciclos 4. Indicadores de proceso...
Page 63
PRESENTACIÓN DE SU SECADORA Funciones del panel de control Tipo Moneda - Lado a lado (RV1329CN4P) - Apilable Superior (RV1329CN7P) - Apilable Inferior (RV1329CN1P) 1. DISPLAY 3. Botón de inicio / pausa 2. Selección de ciclos 4. Indicadores de proceso...
Page 64
PRESENTACIÓN DE SU SECADORA Indicadores de proceso Display Selección de ciclos Botón de inicio / pausa Display Botón de inicio / pausa El display muestra el precio, el tiempo remanente y las El indicador Inicio (Start) parpadea cuando se ha opciones de programación.
OPERANDO SU SECADORA OPERANDO SU SECADORA 1. Modo listo 4. Completado (Para agregar tiempo) 1) T ipo Tarjeta / Moneda Después de insertar una tarjeta de débito, el - Los leds indicadores de los ciclos se encienden tiempo de operación puede ser incrementado a 10 parpadeando al mismo tiempo, cuando el precio de minutos/10p (defecto), cuando sea presionado el los ciclos son iguales.
MODO PROGRAMACIÓN MODO PROGRAMACIÓN 1. Modo Programación Usted puede cambiar información de la máquina o cambiar un ajuste en “Ajuste de Programa”, “Contadores” “Diagnóstico”. Hay dos métodos para entrar al modo de programación. 2. Modo Programación por botón Cómo entrar al “Modo Programación” Cómo utilizar el botón Solamente se puede entrar al modo de programación Puede cambiar el precio de secado, el tiempo del ciclo,...
Page 67
MODO PROGRAMACIÓN Tipo Tarjeta / Moneda El diagrama de flujo muestra cómo controlar el modo de programación. Antes de programar, revise la estructura del modo de programación. 1. Encender el interruptor o insertar la tarjeta de servicio para entrar al modo de ajustes. 2. Presionar el botón Temp. Alta (High Temp.) para moverse a un nivel superior. 3. Presionar Temp.Media (Med Temp.) (+) o Temp. Baja (Low Temp.) (-) si quiere mantenerse en el mismo nivel. 4. Presionar el botón Inicio (Start) para entrar a los detalles del Ajuste, Diagnóstico, Pruebas.
Page 68
MODO PROGRAMACIÓN Tipo OPL El diagrama de flujo muestra cómo controlar el modo de programación. Antes de programar, revise la estructura del modo de programación. Tipo OPL 1) Oprima al mismo tiempo los botones Temp. Alta (High Temp.) Y Temp. Baja (Low Temp.) 2) Oprima 3 veces el botón Temp.Media (Med Temp.) 3) Oprima el botón de Inicio (Start) 4) En la pantalla aparecerá “ “ Es para ajustar el valor del precio, del tiempo, tipo de venta, etc. Es para la línea de prueba, restablecer, ciclo libre y terminación de un ciclo.
MODO PROGRAMACIÓN MODO PROGRAMACIÓN - Modo Setup (Ajustes) Modo Setup (Ajustes): El display indica: Puede cambiar el precio, el tiempo del ciclo, los parámetros del ciclo, etc. Para Entrar al modo de Setup (Ajustes): • Tipo Moneda - Encienda el interruptor correspondiente. • Tipo Tarjeta - Inserte la tarjeta de servicio. • Tipo apilable - Quitar el panel de control y encender el interruptor correspondiente. • En las tipo OPL – O prima al mismo tiempo los botones de Temp. Alta (High Temp.) y Temp. Baja (Low Temp.) y oprima tres veces el botón de Temp. Media (Med. Temp.) • El display indicará: 1.
Page 70
MODO PROGRAMACIÓN 2. Cómo cambiar el precio especial Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 71
MODO PROGRAMACIÓN 3. Cómo entrar a Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 72
MODO PROGRAMACIÓN 3-1. Selección del día de precio especial Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 73
MODO PROGRAMACIÓN 3-2. Selección del tipo de contol - Tarjeta o Moneda Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 74
MODO PROGRAMACIÓN 3-3. Selección de la función de Completado (para agregar tiempo) Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 75
MODO PROGRAMACIÓN 3-3. Selección de la función de Completado (para agregar tiempo) Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 76
MODO PROGRAMACIÓN 4. Cómo introducir el día del precio especial Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 77
MODO PROGRAMACIÓN 4-1. Cómo cambiar a Domingo Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 5. Ajuste del tiempo de inicio del precio especial Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 6. Ajuste del tiempo para finalizar el precio especial Al inicio del Setup BOTÓN Display Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 7. Tiempo del ciclo de secado de precio regular Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 8. Tiempo del ciclo de secado de precio especial Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 9. Valor de la moneda 1 Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
Page 83
MODO PROGRAMACIÓN 10. Valor de la moneda 2 (Ajuste del precio para completar y pulso moneda e-suds) Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 11. Incremento para alcanzar el precio Esto representa el incremento en centravos para alcanzar el precio cuando se usa tarjeta de débito. Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 12. Tiempo para la función de completado Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 13. Volumen de la señal acústica (beep) Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN 14. Tiempo para mantener el valor de la moneda (Sólo para tipo moneda) Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start).
Page 88
MODO PROGRAMACIÓN 15. Cómo ingresar el Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el display Presionar el botón Temp. Alta (High Temp.). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN MODO PROGRAMACIÓN - Modo de Prueba Pruebas de Diagnóstico: (En el display) Este programa ha sido agregado para probar la secadora y detectar errores. Entrando al modo de prueba Nombre Botón Display Descripción Insertar la tarjeta de servicio (tipo tarjeta) o encender el interruptor (tipo 1. E ntrando al moneda) Oprima y sostenga al mismo tiempo el botón Temp.
MODO PROGRAMACIÓN 2. Restablecimiento a valores de fábrica - EEPt Después de restablecer, la información de la máquina cambia a los valores de origen. Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) display hasta que aparezca en el display.
MODO PROGRAMACIÓN 3. Ajuste del reloj. Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) display hasta que aparezca en el display. Presionar el botón Inicio (Start). El display muestra en secuencia 2000-->0101-->Sat-->0000 Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) (+) o Temp. Baja (Low Temp.) (-) para seleccionar el año entre 2000 y 2099.
MODO PROGRAMACIÓN 4. Ciclo de cortesía. El ciclo de cortesía se le da al cliente cuando la secadora no funcione después de que el cliente ha hecho el pago para el secado de su ropa. Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.)
MODO PROGRAMACIÓN 5. Terminación de un ciclo. Tipo Moneda Al inicio del Setup BOTÓN DISPLAY Verá LqC1 en el Presionar Temp.Media (Med Temp.) o Temp. Baja (Low Temp.) display hasta que aparezca en el display. Presionar el botón Inicio (Start). Presionar Temp.Media (Med Temp.) hasta que aparezca en el display.
MODO PROGRAMACIÓN MODO PROGRAMACIÓN - Modo de Datos Datos acumulados: CLCt (display) La secadora acumula información que el usuario puede revisar como el número de veces que se han utilizado los diferentes ciclos, cuántas veces se han utilizado las tarjetas o monedas, etc. Entrando al modo de datos Nombre Botón...
Page 95
MODO PROGRAMACIÓN Lista de Datos Acumulados Abreviatura Significado Descripción ACrt Acumulado de Tiempo de Operación Número de Minutos de Operación (0 ~ 65535) Itnr Intervalo sin Funcionar Itnr no es aplicable para secadora. Ittb Intervalo de Ciclos con Problema Dinero insertado, pero no funciona. ItPd Intervalo de interrupción eléctrica Sin dinero, pero funcionó. Intervalo de Aperturas No Número de Aperturas No Autorizadas de las Puertas Itdd...
MANTENIMIENTO MANTENIMIENTO LIMPIEZA REGULAR LIMPIEZA DEL FILTRO DE PELUSA Limpiar siempre el filtro de pelusa después de cada ciclo. PRECAUCIÓN: para evitar el riesgo de incendio, shock eléctrico, o algún otro daño a las personas cuando utilicen este aparato, siga las siguientes recomendaciones básicas: • D esconecte la secadora antes de cualquier limpieza para evitar un posible choque eléctrico.
NOTA - La máquina puede ser apilada solamente en los modelos designados por LG como compatibles - No apile la lavadora en la parte superior. - Puede ordenar las partes para apilar con los Distribuidores autorizados o con los agentes de LGE.
INSTRUCCIONES DE INSTALACIÓN DE SECADORA APILABLE 4. Apilar la máquina - Levante y coloque la secadora superior sobre la lavadora. - Coloque la parte trasera de la secadora con la lavadora quedando en la misma posición - Empuje la secadora superior para que coincida con la corredera y el soporte hasta alinear paralela- mente los paneles frontales superior e inferior.
MODO ERRORES / RECUPERACIÓN DESPUÉS DE INTERRUPCIÓN ELÉCTRICA / AJUSTES DE FÁBRICA MODO ERRORES Significado de los Códigos de Error que se muestran cuando hay un problema. Problema Causa Posible Solución Se muestra en el display cuando el termistor El termistor debe reemplazarse. está...
