2022-05-04
Hardware Installation Guide
DGW 48.5.2718
Download PDF Document
Safety Recommendations and Information
Danger, Warning, Caution, and Note Definitions
Electrical Safety Guidelines
General Safety Practices
Electrostatic Discharge Prevention
Translated Warning Definition
Requirements
Location Requirements
Wiring Guidelines
Mediatrix G7 Characteristics
Getting Started
Installation Check List
Package Check List
Cleaning Instructions
Mounting Tools and Equipment
Connectors and Indicators
Installing The Mediatrix Unit
Installing the Unit on a Flat Surface
Connecting the Telephony Cables
Connecting the Mediatrix Unit Using a DHCP Server
Connecting the Mediatrix Unit Using a Static IP Address
Verifying the Installation
Cables
Gigabit Ethernet Connection (RJ-45)
PRI Connection (RJ-48)
BRI S/T Connection (RJ-48)
FXS and FXO Connections (RJ-11)
Troubleshooting
Locating the Product Serial Number
Troubleshooting
LED Patterns
RESET/DEFAULT Button
Partial Reset
Performing a Partial Reset
Disabling the Rescue Interface
Factory Reset
Performing a Factory Reset
Standards Compliance and Disclaimers
Supported Standards
Federal Communications Commission (FCC) Disclaimer
Innovation, Science and Economic Development Canada (ISED) Disclaimer
CE Marking
RoHS China
Other Disclaimers
FXO Card - Standards of Compliane and Disclaimers
FXO Card - Supported Standards
FXO Card - Federal Communications Commission (FCC) Disclaimer
FXO Card - Innovation, Science and Economic Development Canada (ISED) Disclaimer
PRI/T1/E1/J1 Card - Standards Compliance and Disclaimers
PRI/T1/E1/J1 - Card Supported Standards
PRI/T1/E1/J1 Card - Federal Communications Commission (FCC) Disclaimer
PRI/T1/E1/J1 Card - Innovation, Science and Economic Development Canada (ISED) Disclaimer
Stock Keeping Unit (SKU) Number for Model M
Product Disposal Instructions
DGW Documentation
Copyright Notice
Top
Safety Recommendations and Information
Danger, Warning, Caution, and Note Definitions
Danger: Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Warning: Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Caution: Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury or damage to property or equipment.
Note: Indicates important information not related to personal injury.
