Merlyn Industries Ltd (MER01)
Declaration of performance number
Shower enclosures with aluminium
profiles and safety glass
Cleanability
Impact resistance/
shatter properties
Durability
MERLYN
Merlyn Showering
Unit 8, Purcellsinch Industrial Park,
Dublin Road, Kilkenny, Ireland.
Tel: 00353 56 779 1555
Fax: 00353 56 779 1576
www.merlynshowering.com
To download the Declaration of Performance (DOP) for
this product please use the link below.
https://merlynshowering.com/aftersales-support/dop-certs/
20
EN 14428
CEARH1.2
: Pass
: Pass
: Pass
Hinge Door & 2 Inline
Panels-Recess
INSTALLATION GUIDE
Advertisement
Related Manuals for MERLYN ARYSTO COLOUR
Summary of Contents for MERLYN ARYSTO COLOUR
- Page 1 Hinge Door & 2 Inline Panels-Recess Merlyn Industries Ltd (MER01) EN 14428 Declaration of performance number CEARH1.2 Shower enclosures with aluminium profiles and safety glass Cleanability : Pass Impact resistance/ : Pass shatter properties Durability : Pass MERLYN Merlyn Showering Unit 8, Purcellsinch Industrial Park, Dublin Road, Kilkenny, Ireland.
- Page 2 SP010SP281000 ×1 Door assembly tool AC07 8S1300511 ×1 AC10 Wall bracket Clamp Bracing bar cover cap Wall plug cover cap 4×30 screw 4mm Hex key ×4 ×2 ×2 MGST5X65 AC34 AC35 ×4 ×1 ×1 MGVC45 Installation tool MG8x51PLUG AC25SPACER ×1 ×2 ∅...
- Page 3 Step 1 IMPORTANT! Whether fitting on a tray or on a tiled Wetroom the tray or floor must be 100% level ! 100% level ！ Step 2 Put bottom track in place on the tray, insert bottom brackets to both ends. Attention: Keep the sloped side of bottom profile to outside.
- Page 4 Step 4 Step 3 Before assembling the brackets make sure it is orientated the correct way. Measure hole centres from top and bottom to determine correct orientation of panel. Position the track parallel to the tray edge while ensuring the gap between the ends Note the differences between the hinged fixed panel (has notch cuts for hinge) and of the track and the inside edge of the bracket is within the 0-15mm adjustment.
- Page 5 Step 6 Step 8 Fix the wall brackets loosely making sure to have the wall bracket in the center Remove both fixed panels and the bottom track, then drill holes with 8mm of the hole in the glass. IMPORTANT ! diameter masonry bit and insert wall plugs.
- Page 6 Step 10 Step 12 Check panel for level and fully tighten screws to wall. Fit hinges to inline panel ensuring that the part of the hinge which has a notch will be on the moving panel side. Moving Hinge plate with notch Panel Screw 5×65 Inline Panel...
- Page 7 Step 13 Step 15 Check door opening at bottom and make sure that the distance at the top is the Standing inside the enclosure lift the door onto the locating aids. Make sure same. you have all the fixings and tools required inside the enclosure. Gap top and bottom should be width of Use door assembly tool to hold the door...
- Page 8 Step 17 Step 19 Measure between edge of fixed panel and the wall and cut infill seal to this Ensure gap is equal top and bottom, then fully tighten hinge bolts. length. Apply a dab of silicone to both ends, insert to bottom profile. Note: The vertical fin should be positioned to the front of the enclosure.
- Page 9 Step 21 Fix the top rails. Step 23 Left and right hand seal kits (A) are provided, determine handing and use appropriate seal kit. Left hand model shown below. Push on longest seal between hinges onto back edge Level the rail. of moving panel.
- Page 10 Step 24 Step 26 Adjusting fixed and hinged panels Where an angled bracing bar is fitted additional adjustment can be made by: If after fitting doors and fixed panels and you still need adjustment to align doors 1) Loosen the 3 screws clamping the glass. etc, you can achieve this by loosening the screws fixing the plate/hinge to the wall 2) Move the glass panel in the direction required(see arrow).
- Page 11 Only seal the outside of the enclosure(red line). Do not seal the inside. Seal vertically along the wall, along the outside edge of the bottom profile and any joins in the profile, including where the bottom track meets the end brackets. Merlyn Industries Ltd (MER01) EN 14428 2 4 h.
