SFF time MNLT Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SFF time MNLT manual
Dear customer,
Thank you for purchasing the SFF time MNLT case. Please read the full compatibility list before assembling your PC and make sure that your
components fit. You can find it on
If you have any doubts about choosing your components, or steps in this manual, please contact us via email on info@sfftime.com, and we will
be glad to assist you.
Important notes:
-
always use correct screwdriver tip for corresponding bolts (PH1 or PH2)
-
always use correct bolt type
-
do not overtighten the bolts
-
do not force any components in, each component should be installed without using excessive force
sfftime.com
or on the next page of the manual.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MNLT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SFF time MNLT

Summary of Contents for SFF time MNLT

  • Page 1 SFF time MNLT manual Dear customer, Thank you for purchasing the SFF time MNLT case. Please read the full compatibility list before assembling your PC and make sure that your components fit. You can find it on sfftime.com or on the next page of the manual.
  • Page 2 SFF time MNLT manual Sff time MNLT specifications:  19.7 L volume with 231 x 209 x 408 mm outer dimensions  vertical riser-less tower case with bottom IO  support for ITX and m-DTX motherboards  support for 3 slot GPU's up to 345 mm long (315/320 mm with 200 mm top fan) ...
  • Page 3 SFF time MNLT manual 1. Preparing the case – disassembly (part 1) unscrew thirteen bolts marked in the picture that hold the side panel and shell...
  • Page 4 SFF time MNLT manual 2. Preparing the case – disassembly (part 2) remove the rear panel...
  • Page 5 SFF time MNLT manual 3. Preparing the case – disassembly (part 3) remove the top panel by pulling it away from the case. The panel is held to the case with magnetic tape...
  • Page 6 SFF time MNLT manual 4. Preparing the case – disassembly (part 4) remove the screw that holds the fan bracket as shown in the picture...
  • Page 7 SFF time MNLT manual 5. Preparing the case – disassembly (part 5) remove the fan bracket...
  • Page 8 SFF time MNLT manual 6. Preparing the case – disassembly (part 6) slide the chassis out of the shell in the direction shown below...
  • Page 9 SFF time MNLT manual 7. Installing the motherboard prepare the motherboard by installing CPU, *note about the CPU cooler: if you are using a smaller CPU cooler or if your RAM and M.2 drives CPU cooler mounting holes are not reachable from the rear side after the...
  • Page 10 SFF time MNLT manual 8. Installing the PSU place the PSU in the position like shown in the picture screw down the power supply to the bracket using four silver bolts we recommend using the bolts supplied with your PSU, as they vary in length...
  • Page 11 SFF time MNLT manual 9. Installing 2.5” hard drives place the drives in the position like shown in the picture screw down the drives to the bracket using four black bolts connect power and data cables for the drives...
  • Page 12 SFF time MNLT manual 10. Installing CPU cooler if using large dual tower CPU cooler, you can mount in after installing the motherboard IMPORTANT NOTE: orient CPU cooler fan(s) in a way that they blow air towards the top of the case or towards the PSU.
  • Page 13 SFF time MNLT manual 11. Installing the GPU – removing the cover (part 1) remove the bolt shown in the picture...
  • Page 14 SFF time MNLT manual 12. Installing the GPU – removing the cover (part 2) remove the PCI cover...
  • Page 15 SFF time MNLT manual 13. Installing the GPU insert the GPU into the motherboard’s PCI-e x16 slot screw down the GPU to the case with two or three bolts connect the GPU power cable(s)
  • Page 16 SFF time MNLT manual 14. Final assembly (part 1) to assemble the case, follow steps 1 – 6 in reverse order slide the populated chassis into the shell but not the whole way in, then bring the fan bracket closer to the chassis and connect the...
  • Page 17 SFF time MNLT manual 15. Final assembly (part 2) after aligning the screw holes, screw in all the bolts for the chassis, fan bracket and the rear panel take care of the screw type, rear panel uses pan head screws while chassis and fan bracket use countersunk head screws...
  • Page 18 SFF time MNLT manual 16. Final assembly (part 3) place the top panel to the top of the case while taking care of the orientation...
  • Page 19 SFF time MNLT manual 17. Build complete congratulations, you have completed your build in the MNLT case! if you have any questions, comments or want to send us your feedback, please write to us at info@sfftime.com be sure to check out our website sfftime.com for...
