  • Page 4 1) Prepare 12 bolts assembly by inserting lock washer (#D), then flat washer (#C) onto bolts (#A). Attach wood dowels (#I) to the holes of leg stand A (#4) and leg stand B (#6) as shown in the diagram. 2) Align leg stand A (#4) and leg stand B (#6) to the holes of leg stand C (#5). Secure with bolts (#A). 3) Align leg stand D (#7) to the holes of leg stand B (#6) and leg stand A (#4).
  • Page 5 Prepare 6 bolts assembly by inserting lock washer (#F), then flat washer (#E) to bolts (#B). Align table top base (#3) to the holes of the leg stand, then secure with bolts (#B). Make sure to pull the electrical connectors through the hole of the table top base (#3) as shown in the diagram.
  • Page 6 Connect the electrical connectors together. Separate the table top (#1), then place the leaf (#2) in-between the extended table top (#1) as shown in the picture. Touch sensor to activate light.
