Page 16
MSD6306-ISDB Factory Mode Adjustment MSD6306-ISDB Factory Mode Adjustment MSD6306-ISDB MSD6306-ISDB Factory Factory Mode Mode Adjustment Adjustment Press "Menu" key to enter the menu interface, then press 8202 to enter factory menu. Level Level Level Level 1 1 1 1 menu menu menu menu...
Page 17
Watchdog switch(Does not open) Image type(close、white、red、green、blue、 WHITE PATTERN black) Restore User Default Factory reset Set a switch to record all programs in a code PVR RECORD All stream Power Power on mode(Power on,power off,memory) Mirror Headstand enabling Aging Mode Aging mode switch VIF1 VIF1 VIF2...
Page 18
MSD6306 software upgrades (After Service) 1、 Software upgrade tools and materials u Personal computer (WINDOWS XP system,USB2.0) u AC100~240V power supply and power cord u ISP burning board and connecting line u USB flash disk(2.0 version,Capacity not more than 2G) 2、...
Page 19
Software update menu will pop up when press confirm key, then select “Yes” to confirm: The process of software updating:...
Page 20
Method 2:Keep pressing VOL+ and CH+ keys on the machine panel, power on the machine, the standby light flashes quickly after about 5 seconds, standby light extinguish and turn into lighting after about a minute, means that the upgrade is completed. 3.3.
Page 21
To VGA interface To computer USB Direction of switch (2). Insert the Mstar USB Tool into the USB port of your PC. The PC can recognize the new device. You can choose to install it in the list, or choose to install at a specified directory and specify the path to the drive file. See the figure below:...
Page 23
(3) When PC finds the drive file, it will give the prompts as in the figure below during the installation process. Please click “Continue" to go ahead. The system will go through three drive installation processes, including Mstar USB Debug Tool A, Mstar USB Debug Tool B, and Mstar USB SerialPort.
Page 24
c. Click Connect button, If it prompts "Device Type is GD25Q32" means that connect normally; If it prompts "Program File Not Ready!" means that there is poor connection, please have a check. Abnormal d.Click "Read" button, then click "Read" button again to load the current mainboard software.
Page 25
The file’s suffix .bin must be e.Click "Auto" button, then set it according to the following figure. Status bar If select All Chip option carelessly and execute loading action, it will erase HDCP KEY on mainboard. So EDID and HDCP KEY must reload after software upgrading.
Page 26
When display “PASS” after burning, means that software has burnt successfully. Never plug or unplug the connection lines in the burning process. Please turn the power switch to “Off” when installing ISP board. Pull out the power cord from the machine and then pull out the burning adapter from the machine, when burning completed, change the TV and click Run button to burn next machine.
Page 27
Panel standby light bright, resetting Press OK key on remote control implement factory reset Panel standby light extinguish, reset completed Press OK key on remote control to implement factory reset (2). Insert signal cable to the machine, switch to the PC message source. (3).
Page 28
(4). Under the YPbPb message source, press the MENU button after popping the main menu, then press 8202 number keys to enter the factory menu, select ADC ADJUST item, press the OK key to enter the next level menu, move the cursor to the MODE item, press the left/right Moving key mover cursor to select YPbPr(SD)item, change the R-GAIN/G-GAIN/B-GAIN value and R-OFFSET/G-OFFSET/B-OFFSET value of the machine after the upgrade to the value before the upgrade.
Page 29
NC/1Kohm-0402-¡ À 5 %-1/16W 10PIN-2.54-D-H-G 5V_STB 5V_M 1Kohm-0402- ¡ À 5 %-1/16W 5V_M 510ohm-0402-¡ À 5 %-1/16W 33ohm-0402-¡ À 5 %-1/16W 5V_M 4K7ohm-0402-¡ À 5 %-1/16W 5V_STB MMBT3904(f≥350MHz) 5V_Panel KMBT3906 RB13 NC/2K2ohm-0402-¡ À 5 %-1/16W 5V_Panel 10Kohm-0402-¡ À 5 %-1/16W 10Kohm-0402-¡...
Page 30
1.15V_STB 1V8_DDR CD10 CL16 CL23 CL22 MSD3393LU 0.1uF-0402-X5R- ¡ À 2 0%-16V 0.1uF-0402-X5R- ¡ À 2 0%-16V 1uF-0402-X5R-¡ À 2 0%-6.3V 0.1uF-0402-X5R- ¡ À 2 0%-16V 0.1uF-0402-X5R- ¡ À 2 0%-16V 0.1uF-0402-X5R- ¡ À 2 0%-16V 1uF-0402-X5R-¡ À 2 0%-6.3V HDMI2_RX1_N LED_RED 3V3_STB...
