AOC LC32D1320 Service Manual

32'' & 42'' lcd tv.
Hide thumbs

Advertisement

32" & 42" LCD TV
Service
Service
Service
Description
Table of Contents............................................................1
Important Safety Notice...................................................2
Revision List.........................................................3
1. General Specification..................................................4
2. Operating Instructions............................................5
2.1 The Use of Remote Control...................................5
2.2 To Use the Menus................................................6
2.3 How to Connect................................................15
2.4 Front Panel Control Knobs..................................17
3. Input/Output Specification.......................................19
4. Mechanical Instructions.........................................22
5. Repair Flow Chart ..............................................30
6. PCB Layout .....................................................37
6.1 Main Board....................................................37
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

TABLE OF CONTENTS

SAFETY NOTICE
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Page
Description
6.2 Power Board..................................................41
6.3 Key Board....................................................46
6.4 IR Board....................................................46
6.5 Daughter Board........................................46
7. Adjustment..............................................................47
8. Block Diagram........................................................48
9. Schematic Diagram..........................................49
9.1 Main Board....................................................49
9.2 Power Board..................................................69
9.3 Key Board.....................................................71
9.4 IR Board....................................................72
9.5 Daughter Board........................................73
10. Exploded View..............................................74
11. BOM List......................................................78
1
AOC LC32D1320-LC42D1320
Horizontal Frequency
31~60 KHz(LC32D1320)
31~67 KHz(LC42D1320)
Page

Advertisement

Table of Contents

   Related Manuals for AOC LC32D1320

   Summary of Contents for AOC LC32D1320

  • Page 1: Table Of Contents

    32″ & 42″ LCD TV AOC LC32D1320-LC42D1320 Service Service Service Horizontal Frequency 31~60 KHz(LC32D1320) 31~67 KHz(LC42D1320) TABLE OF CONTENTS Description Page Description Page Table of Contents..……........…..1 6.2 Power Board……...…………..….…….………..41 Important Safety Notice........……..2 6.3 Key Board………………………………………..46 Revision List…………………………………………………3 6.4 IR Board………………………………………..46 1.
  • Page 2: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.
  • Page 3: Revision List

    Revision List Version Release Date Revision Instructions Customer Model TPV Model LC32D1320 E32BATNSW3B13N May.09,2012 Initial release LC42D1320 E42BATNSW3B23N...
  • Page 4: General Specification

    1. General Specification Notas: • Este modelo está em conformidade com as especificações listadas abaixo. • O design e as especificações estão sujeitas a alterações sem prévio aviso. • Este modelo pode não ser compatível com as apresentações e/ou especificações que podem ser acrescidas no futuro.
  • Page 5: Operating Instructions

    2. Operating Instructions 2.1 The Use of Remote Control...
  • Page 6: To Use The Menus

    2.2 To Use the Menus...
  • Page 15: How To Connect

    2.3 How to Connect...
  • Page 17: Front Panel Control Knobs

    2.4 Front Panel Control Knobs...
  • Page 19: Input/output Specification

    3. Input / Output Specification 3.1 RGB Signal Input 15 - Pin Color Display Signal Cable Pin No. Description Pin No. Description Red Video Green Video Ground Blue Video Serial Data for DDC Ground H-Sync. Red Ground V-Sync. Green Ground Serial Clock for DDC Blue Ground 3.2 HDMI Digital Connector Pin Assignments...
  • Page 20 3.3 Compatible Mode Table Analog RGB Input Signal Timing LC32D1320 LC42D1320...
  • Page 21 HDMI Input Signal Timing LC32D1320 LC42D1320...
  • Page 22: Mechanical Instructions

    4. Mechanical Instructions LC32D1320 1. Remove the screws to remove BASE. 2. Remove the screws to remove REAR COVER.
  • Page 23 3. Remove the screws to remove SPEAKERS, MAIN BOARD, POWER BOARD and DAUGHTER BOARD. 4. Remove the screws to remove BKT.
  • Page 24 5. Remove the screws to separate the Panel and Bezel.
  • Page 25 6. Remove the screw to remove IR BOARD.
  • Page 26 LC42D1320 1. Remove the screws to remove BASE. 2. Remove the screws to remove REAR COVER.
  • Page 27 3. Remove the screws to remove SPEAKERS, MAIN BOARD and POWER BOARD. 4. Remove the screws to remove BKT.
  • Page 29 5. Remove the screw to remove IR BOARD.
  • Page 30: Repair Flow Chart

    5. Repair Flow Chart 1. No power No power (LED “Off”) Check the AC input and Power “On” the power is “ON”? Power board output=5V? Replace the power board Check the IR board and LED Replace the IR board Replace the main board...
  • Page 31 2. Can’t start Can’t start (LED red) Replace the power board Power board output=24V? Replace the key board Check the power key is under control? Replace the IR board Check the IR receiver is normal? Replace the main board Replace the Power board...
  • Page 32 3. Abnormal display Abnormal Display Reset the source Check the source Enter factory mode to do “EEPROM initial”&“Reset” Replace the main board Check the main board Check the LVDS cable Replace the LVDS cable Check the panel Replace the panel...
  • Page 33 4. No display No display (No LED) Check TV is under control and power Replace the main board on/off by remote control and power key? Check the backlight is “On”? Check the LVDS cable Check the B/L signal is available? Reinsert or replace the LVDS cable Replace main board...
  • Page 34 5. Sound problem No sound or sound abnormal Check the audio source connection and the TV system are correct? Reinsert the audio cable or change the TV system Check the TV is muted, adjust the volume or enter the menu to reset? Enter factory mode to do “Reset”...
  • Page 35 6. Remote control malfunction Remote Control malfunction Check the remote control battery is Replace the battery not properly placed or no power? Use the other remote controls Replace the remote control Whether the IR board is Replace the IR board abnormal? Replace the main board...
  • Page 36 7. OSD is unstable or can’t work normally OSD is unstable or can’t work normally Key board connected properly? Reconnect the key board Replace the button function Buttons are OK? Replace the key board Key board is OK? Enter factory mode to do “Reset” Replace the main board...
  • Page 37: Pcb Layout

    6. PCB Layout 6.1 Main Board 715G4786M01000005K...
  • Page 41: Power Board

    6.2 Power Board LC32D1320 715G4088P01W30003H...
  • Page 44 LC42D1320 715G3885P03W30003S...
  • Page 46: Key Board

    6.3 Key Board 715G3814K01003004S 6.4 IR Board 715G3821R01000004M 6.5 Daughter Board (Only for LC32D1320) 715G4417T01001004K...
  • Page 47: Adjustment

    7. Adjustment ADC Adjustment 1. Factory Mode Turn on the TV. Press menu key and then press number key 1+9 +9+9+back. It will achieve the factory mode. 2. ADC Adjustment (It’s no need to adjust ADC.) 3. White Balance Adjustment (1) Enter into the factory mode;(same as the above-mentioned).
  • Page 48: Block Diagram

    8. Block Diagram Nutune TS Stream TC90517FG FK1604 STA339BWTR Speaker SPEAKER Amplifier HDMI 1 HDMI 2 SXL SOC Headphone VGA RGB +Audio IN YPbPr +Audio IN CVBS+Audio IN(Share with Y+L/R) SPDIF Out Service Only LVDS Interface Ethernet 4M bit 64Mx16_DDR3 NAND Flash Serial 128Mx8 bit...
  • Page 49: Schematic Diagram

    9. Schematic Diagram 9.1 Main Board 715G4786M01000005K 3.3V 3.3V 3.3V 0.5A -->DTV R736 NC/0R05 1/10W FB729 R702 R737 120R/3000mA 4.7K 1/10W R703 NC/4.7K 1/10W U703 L0603 1K 1/10W NC/4.7K 1/10W 4.7K 1/10W TO263 TO252 HP_VDDM HP_VCC_15 U702 R701 R704 G1084T43Uf FB706 BL_ON/OFF_PRE FB705...
  • Page 50 5V_TUNER FB721 NC/220R/2000mA FB731 VA_1.1 NC/220R/2000mA 0.26 A FB720 NC/220R/2000mA 3.3V 3.3V 202mA U701 10K+-5%1/16W E-Pad R730 C741 C742 R732 NC/100UF 16V 100UF 16V 360OHM 1/10W EC63 C743 NC/100N 16V R731 NC/10K 1/10W SMD/0402 910 OHM +-1% 1/10W R758 U707 G9661 C748 C746...
  • Page 51 3VSB 0R05 1/10W R222 R408 R404 4.7K 1/10W 4.7K 1/10W NC BC857C 3VSB TouchKey _VCC 120 OHM Q210 FB402 1K 1/10W Q401 LED_R R403 PMBS3906 R402 spec 100mA max NC 0.1uF 50V C218 4.7K 1/10W R233 R247 NC 1K 1/10W NC 4.7K 1/10W Q402 NC BAS32L...
  • Page 52 VA_1.1 3.3V HP_VCC_25 3.3V VA_1.1 HP_VCC_25 U401F TSXL28-B1A10-H FB421 FB422 SXL_VDD_1 SXL_VDD_11 AVDD25_SP16 AVDDH_DRX 120R/600mA 3.3V power_ 120R/600mA C423 C421 for DRX AFE C424 C425 10uF 6.3V 100N 16V 100N 16V 10uF 6.3V AVSS25_SP16 AVSSH_DRX FB423 FB424 SXL_VDD_2 SXL_VDD_12 AVDD33_SP16 AVDDL_DRX 120R/600mA 1.1V power_...
  • Page 53 HP_VCC1V 3VSB 3.3V HP_VCC_15 3.3V 10uF 6.3V 100N 16V 100N 16V 100N 16V 100N 16V 100N 16V 3VSB C4002 C4003 C4004 C4005 C4006 C4007 C4001 C4008 C4009 U401H TSXL28-B1A10-H 10uF 6.3V 10uF 6.3V 10N 50V VDDC: 1.0V, core power VDDF: for VDDM : 1.5V, m em ory I/O power VDDF_ST B: for 3.3V digit al IO...
  • Page 54 100R R103 HP_RXD HP_TXD R105 100R R/G/B : 75 Ohm Trace 100N 16V C102 CN101 R101 0R05 1/16WR0402 PC_G_IN RED_GND R106 C0402 GRN_GND 100R VGA_SDA BLU_GND R107 C101 C103 VGA_HIN VGA_5V VGA_VIN GRN_GND VGA_SCL D101 D-SUB 15P VPORT0603100KV05 100R 100N 16V D0603 R108 C104...
  • Page 55 FB151 NC/22 OHM 1/16W R172 NC/300 OHM C160 NC/100N 50V R173 NC/1K 1/16W NC/1.2K 1/10W Q151 R174 NC/100N 50V NC/PMBS3904 SPDIF_OUT C162 C161 SPDIF_OUT_AR R175 R176 NC/180 OHM NC/1K 1/16W 3.3V Y/Pb/Pr SPDIF OUT FB603 0R05 1/16W R0402 0R05 1/16W R0402 NC/120R/3000mA R164...
  • Page 56 3.3V 5VSB R506 NC/4.7K 1/10W D501 5VSB HDMI0_5VIN NC/M24C02-WMN6TP Q505 FB501 HDMI0_DDC_SCL NC/2N7002 U501 DDC0_SCL HDMI0_HPD NC/BAT54C HDMI0_5VIN R508 NC/4.7K 1/10W R507 NC/4.7K 1/16W NC/120R/600mA HDMI0_5VIN HDMI INPUT 0 HDMI0_5VIN Q506 CN501 R509 HDMI0_DDC_SDA NC/2N7002 DDC0_SDA I2C Address: 1010 000x 5VSB SHELL7 SHELL2...
  • Page 57 3.3V 5VSB D551 R551 4.7K 1/10W HDMI2_5VIN NC/M24C02-WMN6TP Q552 FB551 BAT54C HDMI2_DDC_SCL 2N7002 DDC2_SCL U507 HDMI2_HPD HDMI2_5VIN R553 4.7K 1/10W R552 NC/4.7K 1/16W 120R/600mA HDMI2_5VIN HDMI2_5VIN HDMI INPUT 2 Q553 R554 HDMI2_DDC_SDA 2N7002 DDC2_SDA I2C Address: 1010 000x 5VSB HDMI SHLD1 R555 1K 1/16W...
  • Page 58 +3.3VD +3.3VD R1070 R1071 4.7K 4.7K R1053 R1054 10K+-5%1/16W 10K+-5%1/16W Crystal is 16MHZ U101-1 TNSCL TSCL R1055 10K+-5%1/16W SRCK_ORR R1079 0R05 OHM TS1_CLK TSMDO SRCK TNSDA R1080 33 OHM 1/16W TS1_D0 TSDA SRDT_ORR R1056 R1081 0R05 OHM TS1_SY NC XSEL1 SRDT R1082 0R05 OHM...
  • Page 59 NuTune FK1604 FK1604 3.3V_TUNER FB1002 TU102 NC/120R/3000mA NC/300 OHM FB1001 5V_TUNER 5V_TUNER FB1003 3.3V_TUNER 120R/3000mA Tuner_SCL C1002 10uF 6.3V Tuner_SDA C1009 C1025 C1010 C1016 C1011 C1001 470P 50V NC/470uF 16V 1UF 10V 1N 50V 100UF 16V 10N 50V IF_CTL IF_CTRL TU2_AIF TU2_DIF+ C1006...
  • Page 60 U401A TSXL28-B1A10-H AE23 I2S_OUT_CLK R4240 NC Digital_ AD23 I2S_OUT_LR AF23 I2S_OUT_DATA VDAC_OUT AE24 Audio_Out CVBS1_IN CVBS C4207 NC/100N 25V AD22 R4218 0R05 OHM CVBS2 SPDIF_O SPDIF_OUT AF24 AUD_CLK CVBS3 I2SCLK CVBS4 PC_G_IN Y _G1 Only MAIN_OL/R intergated PC_B_IN PB_B1 MAIN_OL HP_LOUT PC_R_IN PR_R1...
  • Page 61 3.3V TSXL28-B1A10-H U401B 3.3V R4283 NC/4.7K 1/10W FRD0/PODD0 POD_A7 FRD1/PODD1 POD_A8 FRD2/PODD2 POD_A9 R4281 FRD3/PODD3 R4278 4.7K 1/10W AC11 10K 1/10W R4267 4.7K 1/10W FRD4/PODD4 POD_IREQ R4279 4.7K 1/10W AA12 10K 1/10W R4268 FRD5/PODD5 POD_RST AF11 10K 1/10W R4269 R4282 FRD6/PODD6 POD_VS1 MEMC_SCL...
  • Page 62 U401D TSXL28-B1A10-H TS1_D[0..7] TS1_D0 AC13 AD15 TS1_D0 TS2_D0 TS1_D1 AD13 AE15 TS1_D1 TS2_D1 TS1_D2 AE13 AF15 TS1_D2 TS2_D2 TS1_D3 AF13 AB16 TS1_D3 TS2_D3 TS1_D4 AB14 AC16 TS1_D4 TS2_D4 TS1_D5 AC14 Parallel_ Parallel_ AD16 TS1_D5 TS2_D5 TS1_D6 TS2_D6 AD14 AE16 R4306 NC/0R05 OHM TS1_D6 TS2_D6...
  • Page 63 U401E TSXL28-B1A10-H HP_VCC_15 HP_VCC_15 MMDQ0 MMA0 Place each D-cap close MMDQ1 MMA1 MMDQ2 MMA2 to each MVREF ball MMDQ3 MMA3 R4351 R4352 MMDQ4 MMA4 20K OHM 1/16W 1% C4389 20K OHM 1/16W 1% MMDQ5 MMA5 C4388 100N 16V MMDQ6 MMA6 100N 16V MMDQ7 MMA7...
  • Page 64 5VSB 300 OHM FB4150 FB4151 100K 1/10W R4163 VCC5_PANEL_IN R4150 PANEL_VCC NC/360R 1/10W 5% U765 NC 300 OHM NC/AZ809ANSTR-E1 4.7K 1/10W R4159 RESET R4164 NC/RB501V-40 C4152 R4161 NC/390 OHM 1/10W D4151 R4166 C4151 100UF 16V NC/220 OHM 1/10W C4153 Q4150 100N 50V R4165 180K 1/10W...
  • Page 65 AMP24V VCC33_AMP R688 NC 3.4KOHM +-1% 1/10W R6003 47uH L651 10K 1/10W R662 D655 LL4148 PD_MUTE C657 2.1 MODE R689 R690 C691 R691 R664 C6014 100N 50V C658 NC 3.4KOHM +-1% 1/10W NC 0.47UF 50V Q652 NC 22 OHM 1/4W 22 OHM AMP_SD MMBT3904...
  • Page 66 3.3V 3.3V_PHY FB7001 3.3V_PHY NC/120R/3000mA L0603 FB7002 NC/120R/600mA R7001 Pull-up Resistors should close to PHY chip ( <400 mil ) NC/10K CN703 NC/couplier assembly NC/10uF 6.3V NC/100N 16V C7006 C7007 C7008 C7001 C7002 NC/100N 16V NC/100N 16V NC/10uF 6.3V C7009 C7005 R7002 R7003...
  • Page 67 USB_5V MEMC_5V1 FB1101 120R/3000mA L0603 USB_5V MEMC_5V1 R1105 NC/0R051/8W 220UF 16V TH1101 C1111 PTCR 120R/3000mA FB1103 L1102 10uH 4A C1110 D1101 100N 16V R1108 C1112 120K 1/10W 1% SJPW-T4VL C1104 G5655P12U 10U 16V 10uF 10V U110 U1101 R1110 C1101 R1102 M5VSW C1103 C1102...
  • Page 68 UART_VDD UART_VDD EJTAG(Core MIPS) 3.3V 3VSB 3.3V R4122 R4125 0.05R R4100 R4101 R4102 R4103 R4104 CN405 4.7K 1/16W 4.7K 1/16W 4.7K 1/16W 4.7K 1/16W NC 4.7K 1/16W UART_VDD R4106 R4107 R4108 R4105 CN412 JTAG_TDI NC/4.7K 1/16W NC/4.7K 1/16W JTAG_RSTN 4.7K 1/16W 4.7K 1/16W JTAG_TMS UART_TX...
  • Page 69: Power Board

    9.2 Power Board 715G4088P01W30003H (LC32D1320) D904 C907 IN5408 FB901 FB902 D902 R948 FMY -1106S 0.1 ohm R993 T901 BEAD BEAD R991 100K 1/4W POWER X'FMR L906 100K 1/4W R950 D907 C925 C932 47 OHM 1/4W 310uH C910 C920 10NF1KV 0.1NF2KV...
  • Page 70 715G3885P03W30003S (LC42D1320) BD901 FB906 B+_1 D909 1N5408-P FB902 BEAD R950 42" : TS10P06G 0.47 OHM 1W T901 46" : TS15P06G POWER X'FMR D901 BEAD R951 R952 C946 D911 C931 FMXA-1106S C933 C934 100K /4W 100K /4W 0.1NF2KV SBT15006JST BD901 1uF/520V C932 C905 120uF 450V...
  • Page 71: Key Board

    9.3 Key Board 715G3814K01003004S NONE KEY ~1.2V SW01 VOL+ TACT SW FWRD H1.5MM ~0.9015V 20K 1/10W VOL- ~0.6059V TACT SW FWRD H1.5MM 6.8KOHM +-1% 1/10W ~0.3045V TACT SW FWRD H1.5MM 3K3 1/10W 1% PWR-SW FUNC_KEY FUNC_KEY ~0.0118V 100R 1/10W 1% TACT SW FWRD H1.5MM CONN 33T3802 4H...
  • Page 72: Ir Board

    9.4 IR Board 715G3821R01000004M LED01 BLUE ZD03 RLZ5.6B(NC) RLZ5.6B ZD04 LED_B CN01 14 24 EL RLZ5.6B LED_R ZD02 IRRV VOUT R001 15K 1/10W CONN KSM-603TM2M 33G8032 5F HR 100N 50V NC/4.7uF/16V GND1 R102 NC 1K 1/10W R105 NC 360 OHM 1/8W R107 NC 270R 1/8W 5% R106...
  • Page 73: Daughter Board

    9.5 Daughter Board (Only for LC32D1320) 715G4417T01001004K CN4002 CN4008 CH1_3+ CH1_3- CH1_3+ CH1_3- CH1_CLK+ CH1_CLK- CH1_CLK+ CH1_CLK- CH1_2+ CH1_2+ CH1_2- CH1_2- CH1_1+ CH1_1- CH1_0+ CH1_0- CH1_1+ LVDS_SEL CH1_1- CH1_0+ CH1_0- LVDS_SEL Panel VCC Panel VCC Panel VCC Panel VCC CONN...
  • Page 74: Exploded View

    10. Exploded View LC32D1320...
  • Page 75 LC42D1320...
  • Page 76 LC32D1320 Item Description BEZEL Key cover Key button KEY BOARD PCB LENS IR POWER LENS IR BOARD PCB SPEAKER PANEL DAUGHTER BOARD PCB BKT-PANEL-SUPPORT-TOP BKT_VESA BKT_PCB_MAINBD_L BKT_PANEL_L BKT_PANEL_BTM BKT_PCB_MAINBD_L BKT_PCB_MAINBD_R Item Part No. Description MAIN BOARD PCB 0Q1G1030 6120 SCREW(IR BOARD)
  • Page 77 LC42D1320 Item Description BEZEL Key cover Key button KEY BOARD IE Lens Led Lens IR BOARD SPEAKER PANEL BKT-PANEL-TOP 42-bkt-pb BKT-MB-L Item Part No. Description BKT-MB-R 0Q1G 930 8 47 CR3 SCREW(REAR COVER-IO) BKT-STAND 0Q1G1030 6120 SCREW(IR BOARD) POWER BOARD 001G6021 1 screw(SPEAKER) MAIN BOARD...
  • Page 78: Bom List
