Table of Content
IMPORTANT SAFETY INSTRUCTIONS ...............................................................................................1
Read before operating equipment...................................................................................................1
Compliance Information ................................................................................................................ 3
CE Conformity for European Countries...........................................................................................3
Declaration of RoHS Compliance....................................................................................................4
PREPARATION ......................................................................................................................................6
Before installation ............................................................................................................................6
Package contents ............................................................................................................................7
Installation of batteries ....................................................................................................................7
TV INSTALLATION ................................................................................................................................8
Mount the TV stand .........................................................................................................................8
TV connectors .................................................................................................................................8
Wall mounting..................................................................................................................................9
Remove the TV stand for wall mounting .........................................................................................9
Connect the device........................................................................................................................11
Rear connections ..........................................................................................................................11
Side connections ...........................................................................................................................13
Power connection ..........................................................................................................................14
Turning the LCD TV on .................................................................................................................14
First time installation......................................................................................................................15
Control panel buttons ....................................................................................................................16
Remote control functions...............................................................................................................17
Picture format ................................................................................................................................18
TV menu ...............................................................................................................................................19
OSD Settings.................................................................................................................................19
Picture ...........................................................................................................................................20
Sound ............................................................................................................................................21
TV ..................................................................................................................................................22
TV/Channels..................................................................................................................................23
Features ........................................................................................................................................24
Parental .........................................................................................................................................26
Other information ..................................................................................................................................27
Troubleshooting.............................................................................................................................27
Glossary ........................................................................................................................................28
Specifications ................................................................................................................................29

Advertisement

Table of Contents

   Also See for AOC l32wa91

   Related Manuals for AOC l32wa91

   Summary of Contents for AOC l32wa91

  • Page 1: Table Of Contents

    Table of Content IMPORTANT SAFETY INSTRUCTIONS ....................1 Read before operating equipment....................1 Compliance Information ........................ 3 CE Conformity for European Countries...................3 Declaration of RoHS Compliance....................4 PREPARATION ............................6 Before installation ..........................6 Package contents ..........................7 Installation of batteries ........................7 TV INSTALLATION ..........................8 Mount the TV stand .........................8 TV connectors ..........................8 Wall mounting..........................9 Remove the TV stand for wall mounting ..................9...
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
  • Page 4 When purchased or used in different countries, use an appropriate power cable which is compliant with local laws and regulations. To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions Do not install this equipment in a confined space such a book case or similar unit. No naked flame sources, such as lighted candles, should be placed on the apparatus.
  • Page 5: Compliance Information

    Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 6: Declaration Of Rohs Compliance

    Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...
  • Page 7 LCD panel The LCD panel used in this product is made of glass. Therefore, it can break when the product is dropped or impacted upon by other objects. The LCD panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red.
  • Page 8: Preparation

    PREPARATION Before installation Place the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. ‧ Do not cover the ventilation openings on the back cover. ‧ To prevent any unsafe situations, no naked flame sources, such as lighted candles, should ‧...
  • Page 9: Package Contents

    PREPARATION Package contents Please verify that you received the following items with your package contents: LCD TV Base Remote control with batteries User’s Manual Quick Setup Guide Power cord Installation of batteries Insert two AAA batteries into Remote control. Make sure + and – are facing the proper direction. Replace the cover.
  • Page 10: Tv Installation

    TV INSTALLATION TV Overview Mount the TV stand For 19”/22” model: For 26”/32”/42” model: Place the TV face down on a soft and flat surface to prevent any damage and scratch to the screen. Carefully align and insert the Base to the stand. Insert the screws to the bottom of the base and tighten the base to the stand.
  • Page 11: Wall Mounting

    TV INSTALLATION TV Overview Wall mounting TV screen VESA-compatible wall bracket Unit without base Screw type size (inches) (millimeters) (W x H) weight 19” 100 x 100 mm Metric 4 x 10 mm 3.7 kg 22” 100 x 100 mm Metric 4 x 10 mm 4.6 kg 26”...
  • Page 12 TV INSTALLATION TV Overview Remove the TV stand for wall mounting For 26”/32” model: Remove the screws holding your TV to the stand. Pull up the stand base from the hinge to remove the stand base from your TV. Secure the wall mount bracket to the back of your TV using the four screws. For 26”...
  • Page 13: Connect The Device

    TV INSTALLATION Connect the device Rear connections For 19”/22” model: Port Functions Connects to TV RF signals (antenna/CATV). Tuner Input SCART Full SCART, which transmits RGB, S-Video and CVBS in, and monitor out. (EXT 1) The YPbPr video signal can be used if connecting through the component video port.
  • Page 14 TV INSTALLATION Connect the device Rear connections For 26”/32”/42” model: Port Functions Connects to TV RF signals (antenna/CATV). Tuner Input EXT 1: Full SCART, which transmits RGB, S-Video and CVBS in and SCART monitor out. (EXT 1 / EXT 2) EXT 2: Half SCART, which transmits S-Video or CVBS in and monitor out.
  • Page 15: Side Connections

    TV INSTALLATION Connect the device Side connections For 19”/22”: For 26”/32”/42” Port Functions Function when PC Card or ExpressCard is in COMMON INTERFACE slot COMMON of the set. Please refer to your plug-in card manual for detail information. INTERFACE AV IN The composite audio and video provide a basic connection from the DVD (Composite player or other device.
  • Page 16: Power Connection

    TV INSTALLATION Connect the device Power connection Attach the AC power cord to the LCD TV and plug into an appropriate wall outlet. For 19”/22” model: For 26”/32”/42” model: AC 220-240V 50/60Hz Power outlets differ from region to region. Do not insert the power plug in a wall socket before all connections are firm. Turning the LCD TV on Turn on the power switch on TV as shown on page 8.
  • Page 17: First Time Installation

    TV INSTALLATION Connect the device First time installation After unpacking and plugging in your new LCD TV, please proceed with the following steps to set-up your TV. If you do not run this set-up function, your LCD TV may not operate properly. The initial setup display will appear on the screen when the TV is turned on for the first time.
  • Page 18: Control Panel Buttons

    TV INSTALLATION Control panel buttons Button Functions Use these two buttons to adjust the volume. In OSD (On-Screen Display) mode, use those two bottoms to switch the (FUNCTION < / >) selection left and right. Use these buttons to switch between programmed channels. In OSD mode, use those two buttons to switch the selection up and down.
  • Page 19: Remote Control Functions

    TV INSTALLATION Remote control functions TELETEXT RATIO (Designed for Europe Change the aspect ratio; please PAL/SECAM/DVB-T system only) refer to Picture format section. TELETEXT MENU/EXIT Press this button to activate Press to display or close the on- Teletext. Press again to turn off screen menu.
  • Page 20: Picture Format

    TV INSTALLATION Remote control functions Picture format Press the RATIO button on the remote control to select the picture format. Auto: The DTV and HDMI input will automatically display the correct format, while ATV and SCART  will be set. Normal: Displays the classic 4:3 format.
  • Page 21: Tv Menu

    TV menu Using the advanced menu OSD Settings Press the MENU button on the side of the TV or press the MENU/EXIT button on the remote control to display or close the main menu. Use the Navigation Ring to move around to select, adjust or confirm an item in the OSD (On Screen Display) menu.
  • Page 22: Picture

    TV menu Using the advanced menu Picture Menu Descriptions To set the best picture appearance to a predefined picture setting from Smart Picture Standard, Vivid, Movie, Eco, or Personal. Brightness To brighten the dark parts of the picture. Contrast To sharpen the picture quality. Colour To add or reduce colour.
  • Page 23: Sound

    TV menu Using the advanced menu Sound Menu Descriptions To set the TV to a predefined sound setting from Personal, Music, or Speech. Sound Mode To adjust the balance between left and right channels. Balance To add greater depth and dimension to the TV sound. Virtual surround To select the Digital Audio Out from Off, Dolby Digital, or PCM.
  • Page 24 TV menu Using the advanced menu Menu Descriptions To select the relevant country. This is the country you are in, or the country Country whose channels you want to receive if you live near its borders. Audio Carrier Select Stereo, Dual 1, Dual 2, or Mono for ATV channel. (ATV only) Use this function when two or more audio languages are broadcast.
  • Page 25: Tv/channels

    TV menu Using the advanced menu TV/Channels Menu Descriptions Channel scan Channel Scan will re-tune the television automatically. It is recommended to run the Channel Scan periodically to ensure that all new services are added. Update scan Search the new channels automatically that are not in the channel list. Single RF Scan (Digital Only) Enter the Single RF Scan in the Channels submenu to scan digital channels.
  • Page 26: Features

    TV menu Using the advanced menu Features Menu Descriptions To select the on-screen display menu language. Menu Language To select the available display format from Auto, Normal, Native (HDMI only), Picture Format Wide, Zoom 1, or Zoom2. Time Zone To select the time zone you are in. Time To set the time and date or select auto synchronization.
  • Page 27 TV menu Using the advanced menu Features Menu Descriptions Digital Teletext Language To select the teletext language. Teletext Language Decode Page Language To set the teletext language to the regional location. Common Interface This menu appears with your CI supplier information. Automatic Set to underscan or overscan automatically when the video signal is detected.
  • Page 28: Parental

    TV menu Using the advanced menu Parental Menu Descriptions To block certain TV channels. Channel Block To control access programs based on their age ratings. All settings apply to digital channels. Parental Guidance Note: This function operates according to information from the broadcasting station.
  • Page 29: Other Information

    Other information Troubleshooting The following table contains the common problems and the solutions to these problems. Please check this list before you contact technicians. Problems Solutions Connect power cord correctly. Turn on power. No picture Connect signal cable correctly. Press any button on the LCD TV. Abnormal colours Connect signal cable correctly.
  • Page 30: Glossary

    Other information Glossary Audio / Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options.
  • Page 31: Specifications

    Other information Specifications L19WA81 L22WA81 L26WA81 L32WA81 L42HA81 Model No. L19WA91 L22WA91 L26WA91 L32WA91 L42HA91 DISPLAY Aspect Ratio 16:9 16:9 16:9 16:9 16:9 Resolution 1360 x 768 1360 x 768 1360 x 768 1360 x 768 1920 x 1080 Bulgarian, Croatian, Czech, Danish, Dutch, English, Finnish, French, German,...
