ASSEMBLY AND
MAINTENANCE
INSTRUCTION
COMPLETE CONCEALED THERMOSTATIC
MIXER FOR SHOWER
412410 / 412414 / 412425 / 412427
412426 / 412428 / 412572 / 412573
412574 / 412575 / 412576 / 412577
TRACK - YOUNG - QADRA
922410 / 922414 / 922425 / 922427
922426 / 922428 / 922572 / 922573
922574 / 922575 / 922576 / 922577
MIS - WILD
962410 / 962414 / 962425 / 962427
962426 / 962428 / 962572 / 962573
962574 / 962575 / 962576 / 962577
IDROTECH - DIGIT
ASSEMBLY AND MAINTENANCE INSTRUCTIONS
BUILT-IN THERMOSTATIC MIXER COMPLETE FOR SHOWER.
INSTRUCCIONES DE MONTAJE Y MANTENIMIENTO
MEZCLADOR TERMOSTÁTICO EMPOTRADO COMPLETO PARA DUCHA.
Advertisement
Related Manuals for PALAZZANI TRACK/YOUNG/QADRA 412410
Summary of Contents for PALAZZANI TRACK/YOUNG/QADRA 412410
- Page 1 ASSEMBLY AND MAINTENANCE INSTRUCTION COMPLETE CONCEALED THERMOSTATIC MIXER FOR SHOWER 412410 / 412414 / 412425 / 412427 412426 / 412428 / 412572 / 412573 412574 / 412575 / 412576 / 412577 TRACK - YOUNG - QADRA 922410 / 922414 / 922425 / 922427 922426 / 922428 / 922572 / 922573 922574 / 922575 / 922576 / 922577 MIS - WILD...
- Page 2 TRACK/YOUNG/QADRA TRACK/YOUNG/QADRA TRACK/YOUNG/QADRA 41K04810 41K05110 - 412410 - 412414 - 412425 - 412427 - 412426 - 412428 - 412572 - 412573 - 412574 - 412575 - 412576 - 412577 TRACK/YOUNG/QADRA TRACK/YOUNG/QADRA TRACK/YOUNG/QADRA 41K04610 41K00510 41K05210...
- Page 3 MIS/WILD MIS/WILD MIS/WILD 92K05010 92K05810 - 922410 - 922414 - 922425 - 922427 - 922426 - 922428 - 922572 - 922573 - 922574 - 922575 - 922576 - 922577 MIS/WILD MIS/WILD MIS/WILD 92K07310 92K07010 92K07410...
- Page 4 IDROTECH/DIGIT IDROTECH/DIGIT IDROTECH/DIGIT 96K05310 96K06110 - 962410 - 962414 - 962425 - 962427 - 962426 - 962428 - 962572 - 962573 - 962574 - 962575 - 962576 - 962577...
- Page 5 SPARE PARTS / MONTAJE DE REFACCIONES 1 via/ 2 vie/ ways 3 vie/ ways...
- Page 6 SPARE PARTS / MONTAJE DE REFACCIONES 1 - TRACK - YOUNG - QADRA - IDROTECH - DIGIT code 991642 (155x217mm) MIS - WILD code 9916A3 (217X155mm) 2 - code 992352 1 via/way 1/2” - 3/4” code 992354 2-3 vie/ways 1/2” code 992378 2-3 vie/ways 3/4”...
- Page 7 SPARE PARTS / MONTAJE DE REFACCIONES DIVERTER CARTRIDGES/CARTUCHO DESVIADOR 1/2” 3/4” 1WAY/ VÍA 2 WAYS/ VÍAS TOLL.GEN. +/- 0.1 GUARAGNI F. NOTE NOTE FINITURA FINITURA transparent/transparente red/rojo TOLL.GEN. +/- 0.1 GUARAGNI F. 3 WAYS/ NOTE VÍAS FINITURA NOTE FINITURA transparent/transparente red/rojo GUARAGNI F.
- Page 8 SPARE PARTS / MONTAJE DE REFACCIONES SLEEVE/MANGUITO 2-3 ways/vías 1/2” 2 ways/vías 3/4” 3 ways/vías 3/4” TOLL.GEN. +/- 0.1 GUARAGNI F. NOTE FINITURA NOTE DIVERTER CARTRIDGES/CARTUCHO DESVIADOR 1 via/way 1/2” code 99191099 1 via/way 3/4” code 99192599 2 vie/ways 1/2” code 99025899 ...
- Page 9 ASSEMBLY / MONTAJE...
- Page 10 ASSEMBLY / MONTAJE Cold water Agua fría Hot water Agua caliente ...
-
Page 11: Wall Mounting
ASSEMBLY / MONTAJE WALL MOUNTING Drill the wall, paying attention to minimum and maximum deep paying attention to minimum and maximum deep measurements of the recessed measurements of the recessed, indicated on the technical sheet and on the polystyrene put on the product. Place the recessed into the wall. - Page 12 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 1 WAY EJEMPLO MEZCLADOR 1 VÍA Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Altezza consigliata miscelatore Recommended height mixer 1200 mm Pavimento / Floor Acqua calda / Hot water Acqua fredda / Cold water...
- Page 13 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 1 WAY EJEMPLO MEZCLADOR 1 VÍA Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Pavimento / Floor Acqua calda / Hot water Acqua fredda / Cold water...
- Page 14 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 2 WAYS EJEMPLO MEZCLADOR 2 VÍAS Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Altezza consigliata doccetta Recommended height 2° uscita Acqua miscelata shower exit Mixed water 1400 mm Altezza consigliata miscelatore...
- Page 15 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 2 WAYS EJEMPLO MEZCLADOR 2 VÍAS Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Altezza consigliata doccetta Recommended height 2° uscita Acqua miscelata shower exit Mixed water 1400 mm Altezza consigliata miscelatore...
- Page 16 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 3 WAYS EJEMPLO MEZCLADOR 3 VÍAS Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Altezza consigliata doccetta Recommended height 2° uscita Acqua miscelata shower exit Mixed water 1400 mm Altezza consigliata 3°...
- Page 17 ASSEMBLY / MONTAJE EXAMPLE CONCEALER 3 WAYS EJEMPLO MEZCLADOR 3 VÍAS Altezza consigliata soffione doccia Recommended height 1° uscita Acqua miscelata head shower exit Mixed water 2150 mm Altezza consigliata doccetta Recommended height 2° uscita Acqua miscelata shower exit Mixed water 1400 mm Altezza consigliata 3°...
- Page 18 ASSEMBLY / MONTAJE...
- Page 19 ASSEMBLY / MONTAJE EXTERNAL PARTS MOUNTING Insert the o-ring (1) in its respective place into the holes of the plate-rose (2). Screw manually the sleeve (3) to the concealed part. Fit the plate (2) on concealed part’s sleeve (3), paying attention not ...
- Page 20 ASSEMBLY / MONTAJE...
- Page 21 ASSEMBLY / MONTAJE INSERTION OF THE CAM TO FIX TEMPERATURE AT 38 Make sure that the references (A-B) on the thermostatic cartridge are aligned. Insert the cam making sure that 38 (C) standard signal is perfectly aligned with references (A-B) on the cartridge. Fix the thermostatic handle screwing, with the right 2,5 mm Allen ...
- Page 22 ASSEMBLY / MONTAJE CALIBRATION The mixers are tested and calibrated in our establishment, but special operating conditions might make necessary a new calibration to obtain required temperatures. Proceed according with the following indications: Let the water flow measuring the temperature with a thermometer Rotate the handle until you obtain 38 temperature.
- Page 23 MAINTENANCE / MANTENIMIENTO MAINTENANCE AND REPAIR OF THERMOSTATIC CARTRIDGE The continuous and prolonged use in time and any limestone or impurity in water supply, might cause a loss of efficiency in the thermostatic cartridge. Therefore, might be necessary its maintenance and cleaning or replace. ...
- Page 24 MAINTENANCE / MANTENIMIENTO NB: En el caso de mantenimiento, poner los cartuchos en agua y vinagre (50% + 50%) durante 12 horas favoreciendo la eliminación de calcar e impuridades. Por garantizar la funcionalidad del elemento termosensible, recomendamos pasar periódicamente de agua caliente à agua fría por eliminar residuos o incrustaciones en el alojamiento del cartucho.
- Page 25 CLEANING AND PRODUCT MAINTENANCE To clean the product, it is enough to use a wet cloth with a few soap, rinse, and wipe. It is possible to avoid limestone spot formation, wiping it after each use. It is also recommended, not to use sanding detergents or disinfectants containing alcohols, hydrochloric acid, or phosphoric acid.
- Page 26 Technical specs Hot supply index left, red color Cold supply index right, blue color Red button to stop 38 to avoid wrong moves through non desired hot water requirement. Safety device of thermosensitive element for the overheating of feeding’s hot water. Limits of use recommended by UNI EN 1111 for a good working Pressure Min = 1 bar...
- Page 27 Características técnicas índice de suministro agua caliente a la izquierda de color rojo índice de suministro agua fría a la izquierda de color azul Pulsador rojo à bloquear a 38 por evitar unos movimientos equivocados hacia el pedido de agua caliente que no se desea. Dispositivo de seguridad del elemento termosensible por el sobrecalentamiento del agua caliente de alimentación.
