- Page 1 KW-M27DBT MONITOR WITH RECEIVER INSTRUCTION MANUAL • Updated information (the latest Instruction Manual, etc.) is available from <https://www.jvc.net/cs/car/>. Model name indication position See “Removing the trim plate” (P.25) Trim plate © 2021 JVCKENWOOD Corporation B5A-3199-02 EN (E)
-
Page 2: Table Of Contents
Ñ Precautions on using this unit USB ....................10 • When you purchase optional accessories, check Preparation .......................10 with your JVC dealer to make sure that they work Playback operations ...................10 with your model and in your area. iPod/iPhone ................12 • The Radio Data System or Radio Broadcast Data Preparation .......................12... -
Page 3: Getting Started
Getting Started [Screen] Turn the ignition key of your car to ACC. [Dimmer] The unit is turned on. Select the dimmer mode. Press the < > button. “High” (Default) / “Mid” / “Low” Touch [ ]. [Demo] Select the demonstration mode. Default is “ON”. [Information] Displays the software version of this unit. -
Page 4: Basics
Basics Basics Functions of the Buttons on the Common operations Front Panel Ñ Turning on the power Press the < > button. Ñ Turning off the power Press and hold the < > button. 1 Remote Sensor • Receives the remote control signal. (HOME) Ñ... -
Page 5: Home Screen Descriptions
• When iPod/iPhone is connected. [Mirroring] Displays the Mirroring screen. (P.14) • When android device with “Mirroring OB for JVC” application installed is connected. 4 Switches to an external component connected to the AV-IN input terminal. (P.15) 5 Displays the Hands Free screen. (P.18) 6 Plays a Bluetooth audio player. -
Page 6: Digital Radio
Digital Radio Digital Radio Ñ Store a services Digital Radio Basic Operation You can store the current receiving service in Press the < > button. memory. Touch [Digital Radio]. Tune in to a service you want to preset. Ñ Source control screen Touch and hold [#] (#:1-5) in which you want to store the service. -
Page 7: Digital Radio Setup
Digital Radio Ñ Announcement setup Digital Radio Setup When the service for which ON is selected starts, Touch [ ]. switches from any source to Announcement to receive it. Set each item as follows. Touch [Announcement Select] in the DAB SETUP screen. -
Page 8: Tuner
Tuner Tuner Ñ Auto memory Tuner Basic Operation You can preset 6 stations for the current band (FM1/ Press the < > button. FM2/FM3/AM1/AM2). Touch [Tuner]. Touch [FM] or [AM] to select the band. Ñ Source control screen Touch [ ]. -
Page 9: Tuner Setup
Tuner Tuner Setup Touch [ ]. Set each item as follows. [Auto Store] Automatically searches and stores the 6 stations with the strongest signals for the selected band. “Auto Store” appears. [Area] “Europe”: For Europe, AM/FM intervals: 9 kHz/50 kHz. [Local Seek] Tunes in only to the stations with sufficient signal strength. -
Page 10: Usb
Preparation Playback operations Ñ Connecting a USB device Ñ Control the music you are listening to on the source control screen. Remove the cap of the USB terminal. Connect the USB device with the USB cable. The unit reads the device and playback starts. Ñ... - Page 11 Ñ For Video playback Ñ Selecting a track in a list (Searches file) When the operation buttons are not displayed Touch [1]. on the screen, touch the display. Select whether you search by audio files [ ], video files [ ].
-
Page 12: Ipod/Iphone
iPod/iPhone iPod/iPhone Preparation Playback operations Ñ Connecting iPod/iPhone Ñ Control the music you are listening to on the source control screen. • For Lightning connector models: Use USB Audio cable for iPod/iPhone—KS-U62 (optional accessory). • For details about connecting iPod/iPhone, see page 27 . - Page 13 iPod/iPhone Ñ Selecting a content in a list Touch [1]. Touch desired item. When you touch a category its contents are displayed. Touch desired item from the content list. Playback starts. • Touch [6] to moves to the upper hierarchy. ✎...
-
Page 14: Mirroring
Press the < > button. Download Mirroring App from Google Play. Install the latest version of the Mirroring application “Mirroring OB for JVC” on your Android. Remove the cap of the USB terminal. • HOME screen appears. Connect the Android smartphone. (P.27) Launch Mirroring App on your Android Smartphone. -
Page 15: External Components
External Components External Components Using external audio/video players Rear view camera To use a rear view camera, the REVERSE lead Ñ Starting playback connection is required. For connecting a rear view camera. (P.26) Connect an external component to the AV-IN input terminal. - Page 16 External Components Ñ To adjust the parking guidelines ✎ NOTE • Install the rear view camera in the appropriate position according to the instruction manual supplied with the rear view camera. • When adjusting the parking guidelines, make sure to apply the parking brake to prevent the car from moving.
-
Page 17: Bluetooth
• A new device cannot be registered if there are 8 registered Bluetooth units. Delete unnecessary registration. (P.17) Turn on the Bluetooth function on your smartphone/cell-phone. Search the unit (“KW-M27DBT”) from your smartphone/cell-phone. If a PIN code is required, enter the PIN code (“0000”). •... -
Page 18: Receive A Phone Call
Bluetooth Receive a phone call Make a phone call Touch [Û]. Press the < > button. Touch [Phone]. See the table below for each operation method. • [Ý] : Reject an incoming call. Ñ Operations during a call Call by entering a phone number 1) Enter a phone number with number keys. -
Page 19: Playing Bluetooth Audio Device
Bluetooth Call by voice ✎ NOTE You can make a voice call using the voice • Operations and display indications may differ recognition function of the Bluetooth smartphone. according to their availability on the connected 1) Touch [ device. 2) Say the name registered in the Bluetooth * You can access the voice recognition function smartphone. -
Page 20: Controlling Audio
Controlling Audio Controlling Audio Equalizer Control You can adjust various settings such as audio balance or subwoofer level. Press the <EQ> button. Press the <EQ> button. Touch [Equalizer]. See the below for each operation method. Set each item as follows. Controlling General Audio 1 You can select frequency bar and adjust its level. -
Page 21: Speaker / X'over Setup
Controlling Audio Speaker / X’Over setup Listening Position / DTA Press the <EQ> button. Press the <EQ> button. Touch [Speaker / X’Over]. Touch [Position / DTA]. Touch the speaker to set up. Touch [Delay]. Touch [T] or [U] to adjust the delay time of the selected speaker. -
Page 22: Remote Control
Remote control This unit can be operated using the remote control. Functions of the Remote control The remote control RM-RK258 (optional accessory) Buttons can be used. • Aim the remote control directly at the remote sensor #WARNING on the faceplate. •... -
Page 23: Installation
Installation Installation Before Installation • Connect the speaker wires correctly to the terminals to which they correspond. The unit may be Before installation of this unit, please note the damaged or fail to work if you share the ¤ wires or following precautions. -
Page 24: Installing The Unit
Installation Ñ Supplied accessories for installation Installing the unit Ñ Non-Japanese cars (3 m) (2 m) Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. Ñ Installation procedure ✎ NOTE 1) To prevent a short circuit, remove the key from •... - Page 25 Installation Ñ Microphone unit Ñ Removing the unit 1) Check the installation position of the microphone 1) Remove the trim plate by referring to step 1 in (accessory 4). “Removing the trim plate”. 2) Clean the installation surface. 2) Insert the extraction key (accessory 2) deeply into 3) Remove the separator of the microphone the slot as shown.
- Page 26 Installation Ñ Connecting wires to terminals Light Blue/Yellow (Steering remote control wire) To steering remote To use the steering wheel remote control feature, you need an exclusive remote adapter (not supplied) matched to your car. Accessory 4: Light Green (Parking sensor wire) Bluetooth Microphone Accessory 5: Extension cable For best safety, be sure to...
- Page 27 (0.8 m) • Make sure that the pin assignment of the connector 5V = 1.0A matches with the JVC unit. • Take extra notice of the power wire. • In case battery wire and ignition wire are not corresponding then change them accordingly.
-
Page 28: About This Unit
About this Unit About this Unit More information Troubleshooting What appears to be trouble is not always serious. Ñ Playable Audio files Check the following points before calling a service Audio format Bit rate/ Sampling center. (Bit count) frequency • For operations with the external components, refer also to the instructions supplied with the adapters MP3 (.mp3) 16 –... - Page 29 About this Unit Ñ Tuner Automatic presetting does not work. • Store stations manually. (P.8) Static noise while listening to the radio. • Connect the antenna firmly. Ñ AV-IN No picture appears on the screen. • Turn on the video component if it is not on. •...
-
Page 30: Specifications
About this Unit Ñ Bluetooth section Specifications Technology Ñ Monitor section : Bluetooth Ver.5.0 Frequency Picture Size : 2.402 – 2.480 GHz : 6.75 inches (diagonal) wide : 151.8 mm (W) × 79.7 mm (H) Output Power : +8 dBm (AVE), Power Class1 Display System : Transparent TN LCD panel Maximum Communication range... - Page 31 About this Unit Ñ AM tuner section Ñ General Frequency Range (step) Operating Voltage : 531 – 1611 kHz (9 kHz) : 12V DC car battery Usable Sensitivity Installation Dimensions (W × H × D) : 99 μV (40 dBμ) : 182 ×...
-
Page 32: Copyrights
About this Unit – Redistributions in binary form must reproduce the Copyrights above copyright notice, this list of conditions and the • The Bluetooth word mark and logos are registered following disclaimer in the documentation and/or trademarks owned by the Bluetooth SIG, Inc. and any other materials provided with the distribution. - Page 33 First Floor, Gleneagles, the Belfry, Colonial Way, Watford, Hertfordshire WD24 4WH, UNITED KINGDOM Hereby, JVCKENWOOD declares that the radio equipment “KW-M27DBT” is in compliance with the relevant statutory requirements. The full text of the declaration of conformity is available at the following internet address: For Israel URL: https://www.jvc.net/cs/car/eudoc/...
- Page 34 JVCKENWOOD julistaa täten, että radiolaite KW-M27DBT on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutus löytyy kokonaisuudessaan seuraavasta internet-osoitteesta: Slovensko S tem JVCKENWOOD izjavlja, da je radijska oprema KW-M27DBT v skladu z Direktivo 2014/53/EU. Celotno besedilo direktive EU o skladnosti je dostopno na tem spletnem naslovu: URL: https://www.jvc.net/cs/car/eudoc/...
- Page 35 Direktiv 2014/53/EU. EU- overensstemmelseserklæringens fulde ordlyd er tilgængelig på følgende internetadresse: Norsk JVCKENWOOD erklærer herved at radioutstyret KW-M27DBT er i samsvar med Direktiv 2014/53/EU. Den fullstendige teksten til EU-konformitetserklæringen er tilgjengelig på følgende internettaddresse: Ελληνικά Με το παρόν, η JVCKENWOOD δηλώνει ότι ο ραδιοεξοπλισμός KW-M27DBT συμμορφώνεται...
