LIGHT MY BRICKS LEGO HOGWARTS EXPRESS COLLECTORS EDITION Installation Manual
  1. Manuals
  2. Brands
  3. LIGHT MY BRICKS Manuals
  4. Lighting Equipment
  5. LEGO HOGWARTS EXPRESS COLLECTORS EDITION
  6. Installation manual

LIGHT MY BRICKS LEGO HOGWARTS EXPRESS COLLECTORS EDITION Installation Manual

Light kit
Hide thumbs

Advertisement

Quick Links

Download this manual
LEGO
HOGWARTS EXPRESS
®
COLLECTORS' EDITION #76405
LIGHT KIT
INSTALLATION GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the LEGO HOGWARTS EXPRESS COLLECTORS EDITION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LIGHT MY BRICKS LEGO HOGWARTS EXPRESS COLLECTORS EDITION

Summary of Contents for LIGHT MY BRICKS LEGO HOGWARTS EXPRESS COLLECTORS EDITION

  • Page 1 LEGO HOGWARTS EXPRESS ® COLLECTORS’ EDITION #76405 LIGHT KIT INSTALLATION GUIDE...
  • Page 2 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Light My Bricks LEGO HOGWARTS EXPRESS - COLLECTORS’ ® EDITION 76405 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO ® Hogwarts Express - Collectors’ Edition 76405 Light Kit.
  • Page 3 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® PACKAGE CONTENTS: ASSORTED BRICKS: • 6 x Plate 2x2 W Rounded Bottom - Trans Clear • 1 x Round Plate 1x1 - Trans Yellow 15 x White 30cm Bit Light* •...

  • Page 4: Table Of Contents

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO bricks, plates, and tiles providing ®...
  • Page 6 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO ® pieces, ensure they are placed the correct way up (Yellow LED component exposed). You can either place them directly on top of LEGO studs or in between.
  • Page 8 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Before You Begin The Symbols Used In This Guide Connect Turn/ Flip When going through the following guide you will Used when you need to Will be found in the top left come across symbols and formats that will assist connect a LEGO piece or LMB corner when the set needs to...
  • Page 9 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Before You Begin General Note Repeat Step NOTE This is a sample note that is Repeat the previous step eg. used anywhere in this guide. It Make a spotlight, then make a Take the 5cm Connecting Cable will explain a difficult section from the 4-Port Micro Expansion...

  • Page 10: Blueprint

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® BLUEPRINT BLUEPRINT...
  • Page 11 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® BLUEPRINT BLUEPRINT...

  • Page 12: Instructions

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 13 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 14 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Warm White 30cm Large Bit Light NOTE Use the LEGO Removal Tool to assist in disconnecting pieces Plate 2x2 W/ Rounded Bottom - Trans Clear INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 15 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Use the LEGO Removal Tool to assist in slightly disconnecting the floor so there is a small gap. White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 16 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Plate 2x2 W/ Rounded Bottom - Trans Clear NOTE Use the LEGO Removal Tool to assist in slightly disconnecting the floor so there is a small gap. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT...
  • Page 17 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light NOTE Ensure all the studs are reconnected in a secure manner. Plate 2x2 W/ Rounded Bottom - 6-Port Expansion Board Trans Clear 15cm Connecting Cable 8-Port Expansion Board INSTRUCTIONS DISCONNECT...
  • Page 18 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 19 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 Open Stud - Black Warm White 30cm Large Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 20 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Repeat Step 7. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 21 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Use the LEGO Removal Tool to assist in disconnecting pieces INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 22 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2 x Plate 1x1 Mod Rounded W/ Handle - Black Round Plate 1x1 Open Stud - Black Warm White 30cm Large Bit Light Arm Skeleton, Bent W/ Clips Horizontal Grip - Black INSTRUCTIONS DISCONNECT...
  • Page 23 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 24 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 Open Stud - Black Warm White 30cm Large Bit Light Tile 1x1 W/ Clip Round Edges - Black Plate 1x1 Mod Rounded W/ Handle - Black INSTRUCTIONS DISCONNECT POWER ON TEST...
  • Page 25 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2 x Tile 1x2 - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 26 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 27 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® USB Power Cable NOTE Hold the 6-Port Expansion Board in the following position while twisting the cables. This will allow enough slack for the Expansion Board to be positioned momentarily.
  • Page 28 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Disconnect the USB Power Cable (w/ Power Source). Warm White 30cm Large Bit Light Plate 2x2 W/ Rounded Bottom - Trans Clear INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 29 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 30 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 31 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light Round Plate 1x1 Open Stud - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 32 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 33 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board 30cm Connecting Cable INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 34 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 35 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 36 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Disconnect the USB Power Cable (w/ Power Source). 30cm Connecting Cable NOTE Hold any cable on the right side in the following position before securing it down with the Plate 3x3 - Black.
  • Page 37 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 38 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 39 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 40 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Red 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 41 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 8-Port Expansion Board 50cm Connecting Cable NOTE Hold the Expansion Board in the following position. This will allow cable slack on the 50cm Connecting Cable. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 42 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Ensure the Expansion Board can still be held in the following position. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 43 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Run the 50cm Connecting Cable from the left side of the carriage to the right side - ensuring the cable goes inbetween the black and red tiles. INSTRUCTIONS DISCONNECT POWER ON TEST...
  • Page 44 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 8-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 45 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 Open Stud - Black White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 46 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE To reconnect the window pieces, you may need to push the wall slightly back. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 47 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 48 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 49 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 50 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Red 30cm Bit Light 30cm Connecting Cable INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 51 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Hold the Expansion Board in the following position. This will allow 30cm Connecting Cable slack. NOTE Ensure the Expansion Board can still be held in the following position.
  • Page 52 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 53 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Take the two cables from the middle. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 54 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 55 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Twist the circled section of the bundled cables. NOTE Pull the Red 30cm Bit Light around the following stud. NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) INSTRUCTIONS...
  • Page 56 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Warm White 30cm Large Bit Light Plate 2x2 W/ Rounded Bottom - Trans Clear NOTE Disconnect the USB Power Cable (w/ Power Source). INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 57 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 58 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 59 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 60 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 - Trans Yellow NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL...
  • Page 61 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Warm White 30cm Large Bit Light Plate 2x2 W/ Rounded Bottom - Trans Clear NOTE Disconnect the USB Power Cable (w/ Power Source). INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 62 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Pull the Red 30cm Bit Light around the following stud. 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 63 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Return all three sliding doors by removing the Brown 1x8 Plates as shown. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 64 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 65 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 Open Stud - Black Warm White 30cm Large Bit Light Arm Skeleton, Bent W/ Clips Horizontal Grip - Black 2 x Plate 1x1 Mod Rounded W/ Handle - Black INSTRUCTIONS DISCONNECT...
  • Page 66 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 67 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board 50cm Connecting Cable NOTE Exclude the 50cm Connecting Cable from the twisting but instead, thread the cable through the Technic hole on the right side. 2x Adhesive Square INSTRUCTIONS DISCONNECT...
  • Page 68 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 69 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Round Plate 1x1 Open Stud - Black Warm White 30cm Large Bit Light Arm Skeleton, Bent W/ Clips Horizontal Grip - Black 2 x Plate 1x1 Mod Rounded W/ Handle - Black INSTRUCTIONS DISCONNECT...
  • Page 70 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board 50cm Connecting Cable 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 71 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Exclude the 50cm Connecting Cable from the twisting but instead, thread the cable through the Technic hole on the left side. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP...
  • Page 72 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2-Port Expansion Board 15cm Connecting Cable NOTE Connect the USB Power Cable to both 6-Port Expansion Boards indivdually beneath the track to test the lights. NOTE Connect the shorter Connecting Cable from the middle of the track to the 2-Port Expansion Board...
  • Page 73 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Disconnect the USB Power Cable (w/ Power Source). INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 74 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 75 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 8-Port Expansion Board NOTE Before reconnecting all the setions, it may be ideal to place the train track in your preferred displayable location. 50cm Connecting Cable NOTE Keep the 8-Port Expansion Board postioned in the middle of the coal carriage while puling through the 50cm...
  • Page 76 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® 2-Port Expansion Board 50cm Connecting Cable NOTE Ensure the 8-Port Expansion Board is still postioned towards the middle of the carriage. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID...
  • Page 77 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 78 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Pull all the cables tightly towards the Expansion Board. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 79 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 80 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® NOTE Connect the USB Power Cable to the 2-Port Expansion Board behind the train NOTE Connect the 50cm Connecting Cable to the 6-Port Expansion Board on the Station Platform. NOTE You should have these parts left over that were removed...

  • Page 81: Final Product

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO Hogwarts Express - Collectors’ Edition 76405 Light Kit. ® FINAL PRODUCT...

  • Page 82: Troubleshooting

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very we highly recommend that...
  • Page 83 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Troubleshooting Firstly, ensure that the Check for AA batteries batteries have power using a using the AA battery pack battery charge gauge. Inside the battery pack are symbols indicating which direction the AA battery If the batteries have no power, should be inserted.
  • Page 84 HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO bricks, the light will not operate.
  • Page 85 LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit, Effects Board Ports DISCONNECT POWER IMMEDIATELY Batteries can fail, catch fire, or even...

  • Page 86: Contact

    LEGO HOGWARTS EXPRESS - COLLECTORS’ EDITION 76405 LIGHT KIT INSTALL GUIDE ® CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
