- Page 1 Operating Manual Model 75-800 & 75-800-AR Noble Gas Purifier 75-800: 120 V, 50/60 Hz 75-802: 230 V, 50/60 Hz 75-800-AR: 120 V, 50/60 Hz 75-802-AR: 230 V, 50/60 Hz May 2019 Rev. 7 READ INSTRUCTIONS BEFORE OPERATING 277 Brodhead Rd., Bethlehem, PA 18017-8600 U.S.A. Tel: (610) 954-9000...
- Page 2 GOW-MAC Instrument Co.
- Page 3 Follow the instructions in this manual or contact GOW- MAC at (610) 954-9000 for assistance. Models Affected 75-800 75-800-1 75-800-2 75-800-ADD 75-800-AR 75-800-EP 75-800-PRXR 75-800-R 75-802 75-802-AR 75-802-EP 75-802-KIT Model 75-800 & 75-800-AR Noble Gas Purifier Rev. 7 05/19...
- Page 4 GOW-MAC Instrument Co.
- Page 5 (e.g., by a large amount of H O, or CH ), and it is important to maintain hydrogen levels in the ppb range in the purified gas, then the hydrogen capacity can be recovered by raising the purifier temperature to 450 - 500 °C for at least one hour, thereby driving off the previously absorbed hydrogen. UltraPure™ is a registered trademark of UltraPure Systems Inc. Model 75-800 & 75-800-AR Noble Gas Purifier Rev. 7 05/19...
- Page 6 75-800-1 0-500 mL/min. 2-10 mL/min. Standard Fittings: 1/4" VCR ***Lifetime Using He/Ar: 1 yr. @ 200 ml/min (75-800) 1 yr. @ 5 ml/min. (75-800-1) Maximum Power Requirements: 500 Watts, 115V CAUTION IN ORDER TO MAINTAIN PROPER PURIFICATION EFFICIENCY, DO NOT EXCEED ESTIMATED LIFETIME BEFORE REPLACING PURIFIER CARTRIDGE.
-
Page 7: Installation
11 3/4”D x 13”W x 15"H Installation A. Attach clean, 1/8" stainless steel tubing to a tank of Zero Grade Helium for Model 75-800 or Zero Grade Argon for Model 75-800-AR. Attach the other end of tubing to "INLET" on the back of the Purifier, using the provided VCR fitting. B. Attach the provided piece of clean, 1/8" stainless steel with VCR fittings on both ends from the back of the Purifier ("OUTLET") to "CARRIER IN"... - Page 8 Advance Key: Advances Infinity Key: Press to back up through parameter prompts. once level, or press and hold for two seconds to return to the Home page. From the Home page can clear alarms and errors if clearable. GOW-MAC Instrument Co.
- Page 9 Initial Start-Up A. The purifier should be purged with an inert gas (minimum purity 99.99%) before activating the material (He, Ne, Ar, Kr, Xe). B. Start a flow through the unit for at least 10 minutes. Use a minimum of 10% - 20% of specified flow rate for the unit. Use a continuous purge flow during activation. CAUTION THE PURIFIER MATERIAL SHOULD NEVER BE HEATED ABOVE 150°C IN AIR. Model 75-800 & 75-800-AR Noble Gas Purifier Rev. 7 05/19...
- Page 10 Once the unit has been exposed to the atmosphere, Steps A - E should be repeated. WARNING THIS UNIT IS INTENDED FOR THE PURIFICATION OF INERT GASES. UNDER NO CIRCUMSTANCES SHOULD THIS UNIT BE USED FOR THE PURIFICATION OF OXYGEN, HYDROGEN, AIR OR OTHER REACTIVE GASES. GOW-MAC Instrument Co.
-
Page 11: Operation
Temperature Controller, Watlow EZ-Zone 126-184 Terminal Block, 5-position 127-407 Cord, 7' 6", detachable 129-345 Receptacle with power switch and fuse holder 141-452 Feet 180-542 Mini-purifier with 1/4" VCR fittings (for all models except 75-800-AR & 75-802-AR) 180-542-AR Mini-purifier with 1/4" VCR fittings (only for models 75-800-AR & 75-802-AR) Model 75-800 & 75-800-AR Noble Gas Purifier Rev. 7 05/19... - Page 12 Contact GOW-MAC for replacement parts: GOW-MAC Instrument Co. 277 Brodhead Road Bethlehem, PA 18017 U.S.A. Tel: (610) 954-9000 Fax: (610) 954-0599 E-mail: sales@gow-mac.com URL: www.gow-mac.com GOW-MAC Instrument Co.
-
Page 13: Warranty
Filaments of thermal conductivity detectors are not covered by this warranty. All requests for service or repair under this warranty must be received within the warranty period by GOW-MAC or its authorized representative. All repairs are made at GOW-MAC plants or at the offi ce of ® authorized representatives. - Page 14 GOW-MAC Instrument Co.
- Page 15 City: State/Country: Zip : E-mail address: BEFORE item can be shipped, fax completed form to: (610) 954-0599 or e-mail it to: repairs@gow-mac.com For GOW-MAC Use Only: Signed: Date Passed Safety Inspection. OK to proceed to Repair Dept. Chemical Safety Officer...
- Page 16 GOW-MAC Instrument Co.
