- Page 1 Aqua Line Hot water radiant panels Installation Guide FIVE YEAR WARRANTY...
- Page 2 Read this document before installing the appliance Warning Incorrect installation, adjustment, alteration, repair or maintenance work may lead to material damage or injury. All work must be carried out by certified, qualified professionals. If the appliance is not positioned in accordance with the instructions, the warranty shall be rendered void.
- Page 3 Key table [7] 2.0 Selection and design advice [5] = water return temperature in °C = minimum mass flow of water per pipe in kg/h In order to heat the room evenly, it is important to follow the steps below. These calculations Key table [9] determine the type of panel, the panel length, distributors and the pressure drop.
-
Page 4: Mounting Instructions
Determine the upper temperature: 10. Determine the pressure drop on the water side [2]: Single side Sit.A ∆P = (Lb x R1) + (Lb x R2) + Z k = ————— – T Single side Sit.A ∆P = (Lb x R1) + (Lb x R2) + Z Single side Sit.A ∆P = (Lb x R1) + (Lb x R2) + Z Single side Sit.A... -
Page 5: Order Of Installation
= Expansion in mm = Section length mm α = Linear expansion coefficient of steel => 11.7x10 = Average water temperature. w gem = Temperature in the room. Determine the expansion of 1 section length: x (1 + α x (T –... - Page 6 0650285 0650265 0650273 1419113 0650267 0650275 0650287 0650263 0650252 0650261 0650283 1419111 1419112 1419114 1419113...
- Page 8 Watt/m to EN 14037 1-3 Medium Medium kg/h overtemp overtemp ° 1428 1904 1354 1806 1282 1709 1210 1613 1139 1518 1068 1424 1331 1239 1148 1058 1040 1022 1004...
- Page 10 [10] [12] [11] U(mm) (mm) 10.000 20.000 30.000 40.000 50.000 (˚C) 10,5 14,0 17,6 11,7 17,6 23,4 29,3 16,4 24,6 32,8 40,9 18,7 28,1 37,4 46,8 10,5 21,1 31,6 42,1 52,7...
- Page 11 MHS Radiators Limited, 3 Juniper West, Fenton Way, Southfields Business Park, Basildon, Essex SS15 6SJ Tel: 0345 521 5666 Fax: 01268 888260 orders@mhsradiators.co.uk enquiries@mhsradiators.co.uk www.mhsradiators.co.uk SALES OFFICE - 0345 521 5666...
