Ferei HL40AAII User Manual

HL40AAII

FEATURES

Focusing LED headlamp.
1
2 Zoom-able head for spot and flood beam.
Cool or neutral white LED version available.
3
IPX4 Water resistant.
4
1000 lumens for 16 hours.
5
8 Selectable brightness levels from 10% to 80%.
6
4 selectable blinking modes: police blinking, slow blinking, quick
7
blinking, and SOS.
8 Smart IC motherboard provides multiple brightness settings,
and prevents overheat, over discharge or damages caused by polar
reversing.
Battery level indicating at 20% capacity.
9
Elastic bungee headband capable of length adjustment, providing
10
best fit and comfort for user.
11 Optional Diffuser and USB cable charger available.
12 Optional BP2836B, BP4836B and BP6836B for longest runtime each
8.6 hours, 17.2 hours and 25.8 hours on High.

GENERAL USAGE

1 Briefly press the rubber switch to turn the HL40AAII on/off.
2 The HL40AAII provides three lighting options:
Maximum brightness: 100% output.
•
Custom brightness: eight selectable modes ranging from 10% to
•
80% output.
• Strobe / SOS: police strobe, slow strobe, rapid strobe and SOS.
Operating Instruction
3
• To turn the HL40AAII on, briefly press the rubber switch. The default
setting is maximum brightness (100% output).
To access custom brightness mode: with the HL40AAII turned on
•
(in either max or custom mode), hold the switch down for more than
2 seconds and the HL40AAII will cycle through 8 levels of output.
When a desired output is displayed simply release the button to set
the brightness.
• The HL40AAII has 3 hidden strobe modes and 1 SOS mode. To access
these modes simply hold down the power button for 2 seconds with
the unit turned off and release. To cycle to the next strobe / SOS
mode once again hold for 2 seconds and release. To exit strobe /
SOS mode simply press the switch once (turns the HL40AAII off ).
The brightness level of strobe / SOS mode is determined by the
brightness set in custom mode.
4 50% battery warning: When battery capacity reaches 50%, the
HL40AAII will blink twice quickly to indicate battery status.
Low battery warning: When the battery capacity gets very low
5
(approx. 20%), the HL40AAII will emit 10 successive blinks in 8 seconds.
This is a reminder that the battery should be recharged or replaced.
Reverse polarity protection: When a battery is inserted incorrectly,
6
a special protection circuit will activate and automatically prevent
operation to ensure the safety of the HL40AAII and its user.
The HL40AAII is also designed with intelligent over-discharge
7
detection. If battery voltage reaches a critical lower limit, the HL40AAII
will automatically turn off, at which time the battery should be
recharged as soon as possible. Over-discharge of 18650 cells can cause
irreversible damage to the battery and in extreme cases, cause the
battery to inflate and / or emit a harmful gas. It is for this reason that
the HL40AAII is designed to operate only with 18650 batteries that are
above the lowest acceptable voltage limit.
Focusing
LED Headlamp
STRETCH THE ROTATION HEAD PART TO ADJUST THE BEAM SIZE AND FOCUS SPOT
DIAGRAM
5.5 DC PLUG CABLE

AA BATTERY BOX INSTRUCTIONS

UNSCREW THE NUT
INSET 3PCS 1.5V AA BATTERY
WITH THE CORRECT POLAR IN AA
BATTERY BOX

INSTALL AND REMOVE THE BATTERY BOX

THE DIRECTION OF DC JACK FOR
AA BATTERY BOX SHOULD BE TO
SWITCH BOX OF HEADLAMP
USER MANUAL
ZOOM IN
*
PHOTOS ARE FOR REFERENCE ONLY, PRODUCTS IN KIND PREVAIL!
BATTERY BOX 3*AA ADJUSTMENT BUCKLE
SWITCH
BOTH NUTS ARE UNSCREW
PUT THE SCREW CASE IN THE RIGHT
DIRECTION
PUT THE AA BOX THRU THE RUBBER
BELT
CONNECT THE 5.5DC PLUG OF HEADLAMP AND THE 5.5 DC JACK
OF AA BOX, AND THEN SCREW UP THE HOLDER
ZOOM OUT
NYLON ELASTIC BAND
ADJUSTMENT
DIRECTION
LED
HEAD
REMOVE THE SCREW CASE FROM
BATTERY BOX
SCREW UP BOTH NUTS ON AA BOX
TWO RUBBER BELTS TO TIGHTEN
ON AA BOX
