Summary of Contents for Ironton 54130
- Page 1 Truck Winch Quick Mounting Plate Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #54130 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Safety Label ............................5 Main Parts of Product ........................... 6 Assembly Instructions .......................... 6 Operating Instructions .......................... 7 Before Each Use ............................ 8 After Each Use ............................ -
Page 4: Intended Use
Intended Use The Ironton Truck Winch Quick Mounting Plate handles most vehicle winches with a capacity up to 12000 lbs. Made of welded carbon steel construction, it fits a standard 2 inch receiver tube. This winch mount makes it easy to install a winch with your existing receiver tube. The durable carbon steel construction allows your truck to handle winches with capacities up to 12,000 lb. -
Page 5: Specific Operation Warnings
⚠WARNING PERSONAL SAFETY • Stay alert, watch what you are doing, and use common sense when operating the mounting plate. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. •... -
Page 6: Main Parts Of Product
Main Parts of Product Reference Subassembly Short Handle Long Handle Base Plate Assembly Instructions ⚠WARNING • Read the entire Important Safety Information section at the beginning of this manual including all text under subheadings therein before set up or use of this project. •... -
Page 7: Operating Instructions
Operating Instructions Attach the winch to the quick mount plate. Fasten with four bolts and nuts (Pic A). 2. Attach the roller fairlead to the side of mount plate. Fasten with bolts and nuts (Pic B). Page 7 of 11... -
Page 8: Before Each Use
3. Use the hitch pin (#2) and hitch clip (#4) to connect the winch and mount plate to the receiver hitch (Pic C). Before Each Use ⚠WARNING Always check for damaged part before every use. After Each Use ⚠WARNING • Store it in a dry, secure place out of the reach of children. -
Page 9: Parts Diagram
Parts Diagram Parts List Part Number Description Quantity Short Handle Hitch Pin Baseplate Hitch Clip Screw Bolt Flat Washer Screw Nut Long Handle Replacement Parts • For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. -
Page 10: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 11 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 11 of 11...
