- Page 1 User Manual 4x4 HDMI 2.0 Matrix Coaxial audio output 4K@60 4:4:4 8bit IP/RS232/IR Control It’s easy, Just cool ！...
- Page 2 Overview This EZ-MX44HA is a 4 in 4 out HDMI Matrix with Ultra HD up to 4k60 4:4:4 8bit, HDR and HDCP2.2. It reliably distributes four HDMI source signal to four HDMI displays. EZ-MX44HA also provide audio de- embedded via coaxial port for each HDMI port.
- Page 3 INTRODUCTION FEATURES Distributes four HDMI sources signal to four HDMI displays. HDMI2.0 with 4K@60 4:4:4 8bit and HDCP 2.2 compliant Support HDR 10 and HDR Dolby version. Support remote control, button, RS232, IP control Support Audio DE-embed, coaxial audio out without display. Support 3D, Support deep color 30bit, 36bit Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC.
-
Page 4: Specifications
length, output up to 25metres AWG24 cable length No driver required, Plug and play, Installs in minutes SPECIFICATIONS: 1) HDMI version………………………….. HDMI 2.0 2) HDCP version…………………………..HDCP2.2 3) HDMI resolution….…..24/50/60fs/4K*2K/1080p /1080i/720p/576p/576i/480p/480i 4) Support video format ..24bit/30bit,36bit deep color 5) Support audio format…………………….DTS-HD/ Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD/Dolby Atoms 6) Max bandwidth……………………………..600MHz 7) Max baud rate.……………………………..6Gbps... - Page 5 12) Max working current……………………..200mA 13.Power adapter format..Input: …………...AC (50HZ , 60HZ) :100V-240V; Output: DC5V/2A 14) Operatin2g Temperature range…… (-15 to +55 ℃ ) 15) Operating Humidity range…………….5 to 90%RH (No Condensation) 16) Dimension (L x W x H)…………162*94*20(mm) 17) Weight…..………………….…..………………380g Operating and Connecting：...
- Page 7 Setting RS232 control Advanced user may need to control the matrix via RS232, connect a PC or control system. Professional rs232 serial interface software (e.g. UART Assist) may be needed as well. Before executing API commands through RS232, ensure the RS232 port of the matrix and control PC are set correctly.
- Page 8 EZS CAS EN Set Cascade Mode Enable (Turn OFF HDCP) EZS CAS DIS Set Cascade Mode Disable (Turn ON HDCP) EZS OUTx VS INy Set Output x To Input y {x=[0~4](0=ALL), y=[1~4]} EZS OUTx EXA EN Set Ex-Audio Output Enable {x=[0~4](0=ALL)} EZS OUTx EXA DIS Set Ex-Audio Output Disable {x=[0~4](0=ALL)} EZS OUTx STREAM ON...
- Page 9 Audio Setting, turn on/off audio breakout...
- Page 10 EDID Manage, select EDID for each input, there are more than 40 kinds of EDID options. System setting, set IP address and alias name.
- Page 11 Packing List: 1. HDMI Matrix x1 2. Power supply x1 3. Mount ear x2 4.Reusable Cable Ties x2 5. product manual x1 6. IR remote Notes: Please use the machine as the instruction listed to keep the long use lifetime of the machine.
