- Page 1 ONLINE UPS Installation and Operating Instructions a-TroniX UPS Edition One 6kVA, 10kVA Model Capacity (VA) Article number a-TroniX UPS Edition One 6kVA 6000 9885107 a-TroniX UPS Edition One 10kVA 10000 9885108 06/2021 Seite 1...
- Page 2 With the a-Tronix Series Edition One, your installations are safely protected from power supply problems and the functionality of your equipment is maintained. Read carefully before use Read this manual carefully before installation.
-
Page 3: Table Of Contents
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA Table of Contents Page 1. Important safety instructions 1.1 Symbols used in this guide 2. Product Introduction 2.1 Product view (UPS 6-10 kVA) 2.2 The principle of the product 2.3 Product Category 3. -
Page 4: Important Safety Instructions
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 1. Important safety instructions Be sure to observe all warnings and operating instructions in this manual. Keep this manual in a safe place and read the following instructions carefully before installing and operating the unit. - Page 5 Installation and Operating Instructions UPS Edition One 6kVA, 10kVA When changing batteries, always insert the same number and type of ■ batteries. Batteries or their connections can cause electric shocks. ■ If short circuits occur on batteries, touching the live parts can cause severe ■...
-
Page 6: Symbols Used In This Guide
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 1.1 Symbols used in this guide In these operating instructions, the abbreviation UPS stands for: Uninterruptible Power Supply. Accumulators are usually used as energy storage for a UPS system. These are also colloquially referred to as accumulators or batteries. -
Page 7: Product Introduction
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 2. Product Introduction 2.1 Product view (UPS 6–10 kVA) 6/10kVA Front Panel view 6/10kVA Rear Panel view (without maintenance) 1) USB (to connect the UPS to a PC) 2) EPO (for emergency shutdown) 3) Parallel port 1 4) Parallel port 2 5) Intelligent slot... - Page 8 Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 6/10kVA Rear Panel view (with maintenance) 1) USB (to connect the UPS to a PC) 2) EPO (for emergency shutdown) 3) Parallel port 1 4) Parallel port 2 5) Intelligent slot 6) RS232 7) Input switch 8) Terminals (covered)
-
Page 9: The Principle Of The Product
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 2.2 The principle of the product UPS Principle Diagram 1. Mains input 2. Rectifier 3. Inverter 4. Bypass switch 5. Bypass 6. Charger 7. Battery bank 8. Extended Battery Pack (optional) 9. -
Page 10: Installation
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 3. Installation 3.1 Unpacking and inspection Do not tip the UPS when removing it from the packaging. A general risk of tipping ■ always exists with units that have a high centre of gravity. Check whether the UPS has been damaged during transport and do not switch on the ■... -
Page 11: Ups Input And Output Connection
Remove the terminal cover on the back panel of the UPS and connect the cables. ■ It is recommended to use a cable of at least 6mm² for the a-TroniX UPS Edition One ■ 6kVA and a cable of at least 10mm² for the 10kVA. -
Page 12: Communication Cable Connection
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA It is recommended to charge the batteries for 24 hours before use. Turn the input disconnect switch to „ON“ after connection; the UPS will charge the batteries automatically. You can also start using the UPS immediately without charging the batteries first, but the backup period may be shorter. -
Page 13: Panel Display, Operation And Running
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4. Panel display, operation and running 4.1 Start up and turn off UPS 4.1.1 Start up operation Before switching on, check all connections of the UPS and whether all loads are correctly connected. -
Page 14: Faceplate Display
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.2 Faceplate display 4.2.1 Faceplate display illumination 1 2 3 4 DOWN ENTER / ON Overview of the operating panel of the UPS (1) INVERTER LED (2) BATTERY LED (3) BYPASS LED (4) ALARM LED (5) LCD display (6) UP button... -
Page 15: Lcd Display
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.2.2 LCD display NOTE: The display offers more functions than described in this manual. The following parameters are available in the LCD display: ITEM Interface Description Content Displayed Input Voltage & Frequency Output Voltage &... - Page 16 Installation and Operating Instructions UPS Edition One 6kVA, 10kVA (2) Press the „DOWN“ button and the UPS goes to the next page each time, as shown below: (2) Input voltage (3) Output voltage (4) Bat + voltage (positive) (5) Bat–voltage (negative) (6) Load (7) Ambient temperature (8) Bus voltage...
-
Page 17: Parameter Settings
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3 Parameter settings The setting function is controlled by 4 keys (ENTER/ON, ESC/OFF, UP, DOWN): ENTER/ON – goes to the setting page and value setting; ■ UP & DOWN – to select different pages. ■... -
Page 18: Output Voltage Class Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.2 Output voltage class setting Output voltage setting (NOTE: Inside the broken-line is the flashing part) If you press the DOWN key under the mode setting or the UP key under the frequency setting, you will reach the output voltage setting. -
Page 19: Battery Capacity Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.4 Battery capacity setting Battery capacity setting (NOTE: Inside the broken-line is the flashing part) If you press the DOWN key under the frequency setting or the UP key under the battery quantity setting, you will reach the battery capacity setting. -
Page 20: Bypass Volt-Hi Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.6 Bypass Volt-Hi setting Bypass voltage upper limit setting (NOTE: Inside the broken-line is the flashing part) Pressing the DOWN button under the battery quantity setting or the UP button under the bypass voltage setting will take you to the bypass upper limit setting. -
Page 21: Buzzer Mute Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.8 Buzzer Mute Setting Buzzers mute setting (NOTE: Inside the broken-line is the flashing part) Press DOWN under the bypass voltage lower limit setting or press UP under the battery self-test setting to access the buzzer setting. Now the setting status flashes as shown in the figure. - Page 22 Installation and Operating Instructions UPS Edition One 6kVA, 10kVA If you select ON1, the UPS can automatically switch to battery mode every 30 days. The battery self-test time is 10 seconds. If you select ON2, the UPS can automatically switch to battery mode every 30 days. The battery self-test time is 10 minutes.
-
Page 23: Parallel Id Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.10 Parallel ID setting Parallel ID setting (NOTE: Inside the broken-line is the flashing part) If you are in the battery self-test setting, press DOWN or press UP if you are in the parallel quantity setting. -
Page 24: Parallel Redundancy Quantity Setting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 4.3.12 Parallel redundancy quantity setting Parallel redundancy quantity setting (NOTE: Inside the broken-line is the flashing part) If you press the DOWN key under the parallel quantity setting, you will get to the parallel redundancy quantity setting. - Page 25 Installation and Operating Instructions UPS Edition One 6kVA, 10kVA Item USV Alarm Warning Buzz Rectifier Over Temperature Twice per second Fault LED lit Inverter Over temperature Twice per second Fault LED lit Reserve Twice per second Fault LED lit Battery reverse Twice per second Fault LED lit Cable connection error...
-
Page 26: Maintenance
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 5. Maintenance UPS systems operate with dangerous voltages. Repairs and maintenance may therefore only be carried out by qualified personnel who are sufficiently familiar with accumulators and the necessary precautions. Unauthorised persons must be kept away from the accumulators. -
Page 27: Troubleshooting
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 6. Troubleshooting If the UPS system is not working properly, please solve the problem using the following troubleshooting table. If you need help with this, please contact our service department. The following information should be provided for analysis: UPS MODEL and serial number ■... -
Page 28: Specification
Installation and Operating Instructions UPS Edition One 6kVA, 10kVA 7. Spezification UPS Edition One Model 6 kVA 10 kVA Capacity Phases Capacity (KVA) Capacity (W) 6000 10000 Power factor output (cos phi) Transfer Time (ms) Mains mode to battery mode: 0 ms Inverter mode to bypass mode: 5 ms Input Rated voltage (V AC)
