OULOO-Electric Moped
https://www.ouloobikes.com/
Notice:
Do not use the electric bicycle before carefully reading the
instruction manual and understand the performance of the
electric bicycle, and please keep the instruction manual
properly.
Dear user friends:
Thank you for choosing to purchase "far-reaching" products. Our company and all staff extend
our sincere welcome and heartfelt thanks for your choice.
This "Instruction Manual" introduces you to the safety precautions, main performance
parameters, vehicle structure, pre-driving inspection, inspection, maintenance and repair, fault
phenomenon and elimination, after-sales service, and warranty coverage, so that you can
operate easily and freely This product, to ensure your safe driving on the road.
In order to effectively protect your car and make it as convenient as possible to use your car,
when you find a problem that cannot be solved by yourself or need to replace parts, please
contact the after-sales maintenance department of the dealer or purchase the original parts from
our company. In addition, when you purchase the company's products, please fill in the "User
Warranty Card" completely and clearly, keep the "User Stub Copies" properly, and deliver the
other two copies to the dealer so that we can contact and serve you in time.
The appearance, configuration, and color of the product shown in this "Instruction Manual" are
for reference only, and the actual product shall prevail.
Dear users, for the safety of you and your family and to prevent accidents, please be sure to read
and abide by the following safety precautions and relevant laws and regulations:
WARNING: Personal injury may result if this warning is ignored, and special warnings about what
to do or what not to do.
NOTICE: Failure to follow this instruction could result in damage to the vehicle and its equipment
or malfunction.
Intelligent electric bicycle
User's Manual
Preface
Safety Precautions
info@ouloobikes.com
Advertisement
Table of Contents
Related Manuals for OULOO F60
Summary of Contents for OULOO F60
- Page 1 OULOO-Electric Moped info@ouloobikes.com https://www.ouloobikes.com/ Intelligent electric bicycle User's Manual Notice: Do not use the electric bicycle before carefully reading the instruction manual and understand the performance of the electric bicycle, and please keep the instruction manual properly. Preface Dear user friends: Thank you for choosing to purchase "far-reaching"...
-
Page 2: Driving Safety
Driving Safety Please read this book carefully before using the vehicle "Instruction Manual", does a good job of inspection before driving to ensure the safety of riders. 1. It is strictly forbidden for persons under the age of 16 to drive electric bicycles on the road. 2. - Page 3 replaced with the battery model. 5. Before washing the electric bicycle, you should understand the contents of "Washing Precautions" in the manual. 6. When adjusting the handlebars or saddles, care should be taken not to expose the safety line markings of the handlebars and saddles (if applicable). 7.
- Page 4 17. During the charging process, if there is an odor, the temperature is too high, the indicator light of the charger still does not turn green after charging for more than 10 hours, or the battery is bulging, please stop charging immediately, and send it to the dealer or after-sales maintenance department.
-
Page 5: Product Parameters
DS81 Notice The company reserves the right to change the appearance, accessories and dimensions of the vehicle. Please understand that any relevant parameters will be adjusted without prior notice. Product Parameters... - Page 6 Electric bicycle key technical figures model name Appearance size 1660*680*1035 (length*width*height) Front/rear wheel center 1200 distance Vehicle weight ≤60 Top design speed KM/H technical Cruising distance 30～80 figures 100KM power consumption KW.H/100KM 2.01 Carrying capacity Battery type Volume 15～30 technical Voltage specification 60/72 figures...
- Page 7 batteries Motor mode Rated rotation speed R/MIN Motor Output standard main Voltage specification 48/60 to skills Overvoltage protection 42±1 Controll value er Key Overcurrent protection 23±2 Technica value l Values Electric bicycle key technical figures Model name Appearance size 1710*700*1055 (length*width*height) Front/rear wheel center 1220...
- Page 8 Use of the instrument A power display instrument panel is installed above the handlebar, which can instantly display the current remaining power. In order to ensure the life of the battery, please charge it in time when the power indicator reaches the red area or the power indicator flashes. Type F6 Instrument Panel seagull-type Dashboard Dashboard Type S1...
- Page 9 Left combination switch Instructions...
- Page 10 Instructions Right combination switch Front brake lever Headlight switch Speed control handle Turn on the headlights: push the 1st gear left to turn on the position light, push the 2nd gear left to turn on the headlights; push the right to turn off the headlights Turn on the light Turn on the headlights Turn off the headlights...
-
Page 11: Charging Method
Cruise control (if any) After the normal driving speed is stable, press and hold the cruise button for 3-5 seconds to enter the constant speed state. Charging Method The vehicle can be charged directly on the vehicle Charging location Please turn off the power and remove the key. Open the protective cover of the charging hole, insert the output end of the charger into the charging socket, and insert the input end into the 220v power socket. -
Page 12: Inspection Before Driving
Inspection Before Driving Warn 1. It is strictly forbidden to use conductors or limbs to touch the electrodes of the charging port to avoid harming the human body. 2. It is strictly forbidden for the charging port of the battery to enter the water, so as to avoid short-circuit damage to the battery or the whole vehicle. -
Page 13: Inspection, Maintenance And Repair
whether the headlights and taillights are on, and whether the headlights are normal. 2. Check the front and rear brake levers respectively to see if the power is off and whether the rear brake lights are on. 3. Operate the turn signal switch and check whether the turn indicator is working normally. Warn Lighting will affect the observation of road conditions and pedestrians at night, as well as the observation of oncoming vehicles. - Page 14 used. 2. Check whether the license plate is installed firmly, whether the number is clear, and whether there is dirt or damage. Handlebar Steering Inspection 1. Shake the handlebar to check for any abnormal noise, and check the handlebar, front fork, and shock absorber for deformation, bending, cracks, and other abnormal phenomena.
- Page 15 Inspection Before Driving Tire inspection When the tire is cooled, check whether the tire pressure is appropriate, whether there are sharp objects such as nails, glass, etc. on the tire surface, and whether there is a large area of cracks or wear.
-
Page 16: Daily Maintenance
Daily Maintenance Lubrication part and cycle Lubricatio Lubricatio Recommended n part n cycle lubricating oil Front fork one year Butter (calcium based joint grease) Front and one year Butter (calcium based rear axles grease) central one year Butter (calcium based axis grease) Pedal... - Page 17 the power first, then unplug the battery. 6. When the green light is on, the power supply should be cut off in time. It is forbidden to connect the charger to the AC power supply with no load for a long time without charging. 7.
- Page 18 Use and Maintenance of Controller and Motor Use and maintenance of the controller 1. Regularly check whether the fixing screws and wiring of the controller are loose. 2. Regularly clean the dust on the surface of the controller, which is conducive to heat dissipation. It is forbidden to wash electrical components with water, so as to avoid the danger of electrical short-circuit failure.
- Page 19 Unit: N.M Parts serial number Tightening torque front wheel wheel rear wheel Front fork lock nut front fork rear fork Rear fork lock nut front shock Front shock lock nut rear shock Front shock shaft tightening nut Schematic Diagram of Battery Installation How to install battery 1.
- Page 20 Troubleshooting and troubleshooting · Fault phenomenon · cause of issue · Method of exclusion · Turn on the power, the · Fuse open · · Poor contact between the · Find out the cause and replace the fuse instrument has no display and the speed regulation power plug and the ·...
