- Page 1 Computer Wheel Balancer Operation Instructions with Maintenance Instructions READ these instructions before placing unit in service KEEP these and other materials delivered with the unit in a binder near the machine for ease of reference by supervisors and operators.
-
Page 2: Table Of Contents
Table of Contents Before You Begin Receiving ................................4 Specifications ..............................4 Electrical Requirements ............................4 Features ................................4 Standard Accessories ............................4 Assembly and Setup Floor and Space Requirements ......................... 5 Unpacking the Unit .............................. 5 Remove Balancer from Pallet ..........................5 Connecting to Power ............................ - Page 3 1. Read all instructions 2. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged – until it has been examined by a qualified serviceman. 3. Do not let cord hang over edge of table, bench, or counter, or come in contact with hot manifolds or moving fan blades.
- Page 4 Definitions of Hazard Levels Owner’s Responsibility Identify the hazard levels used in this manual To maintain machine and user safety, the with the following definitions and signal words: responsibility of the owner is to read and follow DANGER these instructions: Watch for this symbol: •...
-
Page 5: Before You Begin
Before You Begin Features Receiving • Balances Most Automotive Wheels The shipment should be thoroughly inspected • Vertical Wheel Mounting as soon as it is received. The signed bill of • Back Cone and Front Cone Mounting lading is acknowledgement, by the carrier, of •... -
Page 6: Assembly And Setup
Connecting to Power Assembly and Setup Floor and Space Requirements Consult a licensed electrical contractor for Floor must be solid and flat concrete. The proper connection that meets local electrical codes. Power outlets must be located in a balancer need to be bolted to the floor in normal floor raceway or overhead drop if pedestrians service. -
Page 7: Control Panel And Display
(F)＋(STOP), Lower down the cover, the machine Control panel and display starts automatically. Loose set after the power is turned off. (F)＋(b＋), MM / INCH SELECTION “b” SETTING / WHEEL WIDTH (F)＋(d－), MM / INCH SELECTION “d” SETTING / WHEEL DIAMETER Balancing mode selection key Press (F) key to change from Dynamic... -
Page 8: Operating The Balancer
Operating the Balancer When the deformation of the outside of the Switch on the main switch on the left side of the wheel, adopt this method to positioning to machine，the display will display “ ” A-8.0 grantee the accurate positioning of the steel rim inner hole and main shaft. -
Page 9: Entering Wheel Measurements
Entering Wheel Measurements BALANCE MODE SELECT This wheel balancer 'S Default model is clamp weigh for rim it not be show on the Control panel .please learned of the matte. After input three value and ratate the wheel you can Select the balance mode according to the weight adding position and the balance mode. -
Page 10: Balance The Wheel
Balance the Wheel When power starts, push the wheel by hands to assist starting which will extend motor’s life. Make sure the wheel value is correct. Make sure the rim structure is suitable for the balancing mode Make sure the quick nut is well tightened As the balance is over, unload the tyre, pay attention to handling with care , don’t strike the 1. -
Page 11: Opt Balancing
Optimize Balancing Function (OPT) This function is recommended only when the weight displayed to balance the wheel is over 30 grams (1. 06 oz). Use the following procedure to adjust the tire and wheel so that less weight is needed to complete the process. To begin, the tire should be mounted with the Remove the wheel from the Balancer and Hood down after completing a cycle. -
Page 12: Maintenance And Service
Rotate the wheel counterclockwise, slowly Maintenance And Servicing by hand, until the Control Board display flashes as shown above. Make a mark at the top of the Self-calibration tire (12 0’clock position), and label “P-tire”. Self calibration has been finished in the factory. If you use for a period of time or change part inside or the result of the balance is not correct, you can self correct it again.( Choose one... -
Page 13: Accessories
◎ Well–balanced tire will show “100”-“00” (±4g ) Accessories after self calibration. 100g counterbalance is rightly under main shaft when outside lamps are all on ( 4°error is allowed), this proves phase angle is correct. Two key elements to judge if self calibration is accurate or not 1.
