KELISS T162A Instruction Manual

Specification
Rated power
Power cord length
Rear wash
Water
volume
Bidet wash
Swing
Cleaning
Massage
Water volume
/nozzle position
Outlet temperature range
Safety device
Drying temperature control
Drying
Safety device
Surface temperature 4 levels adjustable （ close option included） room temperature-about 107°F
Seat
Safety device
Antibacterial seat/nozzle
Self-cleaning
Automatic nozzle cleaning
Pre-wetting
Deodorization
Activated carbon deodorant
method
nominal water consumption
Bidet toilet Drainage method
Ceramic pit distance
Rated 1100W
Water supply
39°F-95°F Ambient temperature
temperature
Dimension About 680 * 400 * 465mm Water supply pressure
※1:Rated power: Set the water volume, seat temperature and water temperature to the highest level under the conditions of
ambient temperature 68°F±41°F, inlet water static pressure 0.18MPa±0.02MPa, and inlet water temperature 59°F±33°F.
Turn on the bidet function, and test the average power within 60 seconds after the temperature of the outlet water stabilizes.
※2:Maximum power: Set the water volume, seat temperature, and water temperature to the highest level under the conditions
of an ambient temperature of 73°F±35°F, an inlet static pressure of 0.18MPa±0.02MPa, and an inlet temperature of
41°F±33°F. Turn on the bidet function and continue to work stably at the maximum power for a cleaning cycle.
※3:Test method of nominal water consumption needs to correctly install the water-saving piece in the accessory kit on the angle
valve according to the requirements of the installation instructions, and then perform the test according to the water
consumption test standard.(Test the consumption three times for each, in which the pressure of water hose is at a static
pressure of 0.24Mpa and 0.55Mpa. Total get six value, the sum is divided by six and the average is the nominal water
consumption)
※4:Standby mode: About one minute after turning off the seat temperature, the machine enters the standby state, only the
indicator light is on ( if with microwave induction function, also need to be turned off).

Parts name

Power-off flush
Knob
Power indicator Seat temp status indicator
Water temp indicator
Water temp indicator
Instruction Manual
T162A without water tank
52211773-01 V1.0
100-130V~ 50/60Hz
About 1.5m
About 0.5-0.7L/min
(water pressure 0.2MPa） （ 3 levels adjustable）
Oscillating cleaning forward and backward
Two options: press once for interval cleaning,
press twice for continuous cleaning
3 levels adjustable
About 68°F-107°F （4 levels adjustable）
Temperature limit circuit, thermostat, thermal fuse
About 89°F-134°F （ 3 levels adjustable）
bimetallic thermostat, thermal fuse
Thermal fuse
Antibacterial material/stainless steel nozzle
Self-cleaning
Wash a circle of water After sitting
flip/loop Remote control, foot sensor
4.8 L
Siphon jet flushing
305mm/400mm
Maximum power 1600W Waterproof level
37°F-104°F Net weight
Minimum necessary water pressure:
0.15 MPa (over 17L/min when flowing)
Maximum water pressure:
0.75 MPa (static pressure)
sor
sen
Flushing status indicator
Seat temp indicator
Seat temp indicator
To avoid the damage and asset losing to user and other people, please strictly follow up the safety warming
and noting list. Please ensure to carefully read through the user manual before the assembly, and strictly
follow up the user manual to do the assembly, please keep the user manual after reading.
· When using in shower room, please install air exchange equipment to ensure the airy and drying in the shower room. This
product is electric products, it is not allowed to install it in the place that is easy high wet, easy split by water,otherwise it might
trigger electric shock or fire.
· Please ensure to cut off the electric power before washing this product, do not use water to directly wash this product, otherwise
it might trigger the electric shock or fire.
· Please put and use this product in the shadow, must not put directly beneath the sun, otherwise it might cause the color-fading,
or let the sunlight burn the surface of product due to the instability of temperature.
· Do not use industrial water, wastewater, seawater, reclaimed water and other sewage, otherwise it may cause skin inflammation
and other problems.
· Persons (including children) with physical, perceptual, intellectual disabilities or lack of experience and common sense need to
use the product under the guidance or supervision of someone else, or they may cause electric shock,injury or fire.
· Please notice the assembly location of electric wiring plug, electric plug should be the water-proof plug. assembly location of
electric plug must be over 0.5m above the floor, and far away from shower, bathtub, otherwise it might cause electricity leakage.
· When installing this product, please remove the old hose assemblies owned by users and install them with new hose assemblies.
Do not reuse the old hose assemblies to avoid related safety problems.
· The grounding wire of this product must conform to the stipulated construction mode, and the three-level grounding structure
must be grounded, otherwise the use of this product is prohibited.
· Electric plug need to plug in the electric with air switch.
· In the same room where this product is installed, a switch of water inlet angle valve needs to be installed at a location within
reach. It is used in emergency situations to cut off the waterway of this product without the aid of tools; otherwise, unexpected
failures of this product may occur and it will cause user loss.
· If you have not used this product for a long time, please close the angle valve, press the water release button to drain the water of
ceramic itself and cut off the power; When using the product again,please wash first to prevent water quality problems and skin
diseases.
· When the outside air temperature is lower than 0°C, in order to prevent water leakage caused by external filter and other
accessories likely freezing, please be sure to close the water inlet valve and drain the left water; If pipe has been frozen, please
raise the room temperature and wait for pipe normal then use the toilet, otherwise the product may not be used normally.
· It is not allowed to continue using if the product has some breakdown:
product heat abnormally
Product has smoking
Product has abnormal sound and smell
Product has leakage, breaking or damage
Toilet pan is blocked, etc.
When the breakdown happens, if it do not handle in time and continue using,it might trigger the problems like electric shock,
injury, firing or water penetration inside the room etc.
· Banana water, gasoline, putty-powder, nylon brush or other (non-neutral)detergent is not allowed to clean the plastic parts like
toilet seat cover, otherwise it might trigger chemical reaction or leakage, damage the product and cause people injury.
· Loosen electric outlet is not allowed as it might trigger electric shock or firing.
IPX4
· It is not allowed to pull out and plug in the electric plug by wet hand as it might trigger electric shock or firing.
· It is not allowed to touch the electric plug when it is thundering and lighting as it might trigger electric shock.
About 37.3kg
· It is not allowed to use other electric resource, the load of using electric outlet could not be too big, as it might trigger firing due
to over-heat.
· Detergent, water, wash detergent or urine is not allowed to spot into body and electric outlet, as it might trigger electric shock or
firing.
· It is not allowed to let child standing or put heavy goods on the seat and cover, toilet pan or seat body, heavy hitting or knocking
is not allowed.
· It is not allowed to disassemble, repair this product, (it must go for professional repair person service if it is necessary to repair),
otherwise, it might cause the damage to this product.
· Do not randomly damage the electric plug and electric line, if the electric line,electric plug is damaging, please do not use it any
longer or change by oneself, it must be changed by professional person, otherwise, it might trigger short-circuit, electric shock,
firing.
· If the power cord is not long enough, please do not use a extension cord.
· The stove or lighted cigarette is not allowed to be placed next to the toilet pan, cigarette butt etc is not allowed to be thrown into
toilet pan.
· Do not block the airopenings of the product. Keep the air openings free of lint, hair, and the like.
· Do not use while bathing.
1. Install the water inlet valve
Clean the ground and dry the water before
installation. Mark the central lines of the
Lid
draining outlet, and install the inlet valve on the
wall.
Connect to grounded
outlet
Seat
Rear wash hole
Bidet wash hole
2. Mark the curve of ceramics
Align the drain hole of ceramic with the central
Drying baffle
line (there are two dimensions, 305mm and
400mm). mark the curve of ceramics for later
Nozzle baffle
installation.
Nozzle
wall
Ceramic toilet
Foot sensor
3.Sealing ring installation
①Gently tilt the toilet sideways until it rests on
the side surface.
②Install the sealing ring evenly along the outlet,
and the small end of the sealing ring facing the
toilet.
Sealing ring
Draining
hose
Tips:
※The above pictures are for reference only, the actual product shall prevail.
※Please don't hit the ceramic during installation, it may cause personal injury, water leakage and other
consequences after the ceramic breaks.
※The installation must be carried out in accordance with the instructions, otherwise it may cause malfunction
or water leakage.

Safety precautions

Cautions
Warning

Product installation

4.Toilet (ceramic) installation
Lift the toilet, take the floor drain as a reference,
align the ceramic body of the toilet with the
ceramic contour line drawn on the ground, and
slowly put the ceramic on the ground so that
the two marks overlap. After overlapping, press
Caution electric
shock! the ceramic down (can be pressed by the
weight of the human body) so that the sealing
GFCI outlet
ring fully contacts the ground.
※Do not move the ceramic or shake it left and
right after the marks are overlapped, otherwise
the seal produced by the sealing ring may be
3 0 5
/ 4 0
0 m damaged and cause water leakage.
m
m
0 m
3 0
Drain outlet
center mark line
5. Connection of water inlet valve
Connect the water inlet braided pipe to the
water inlet angle valve; if the water pressure is
high, you can install a water-saving piece or
adjust the position of the angle valve to achieve
305/400mm
the best flushing effect.
G1/2
Inlet angle valve
NOTE:
water-saving
tablets
If the water pressure is less than
0.24Mpa （ static pressure） , remove
the water-saving tablets.
G3/4
