Introduction
Thank you for purchasing our innovative all-in-one solution---SOHO Server
501705 appliance for your networking needs.
The SA integrates server services such as a Network Address Translator
(NAT), Virtual Private Network (VPN), SPI firewall, and networked storage
into one easy to manage device. The SOHO Server allows a group of
trusted computers and networks to connect quickly and safely. With the
SOHO Server , network managers and users can save time in establishing
some of the most common services done on servers costing thousands of
dollars.

Product Specifications

Connection Sharing
Flexible Address Space for NAT service
IP Alias
Multiple NAT
Virtual Private Network
PPTP Server / Client
Firewall
Prevent Denial of Service (DoS) Attacks
Packet/URL Filtering
Access Control, Virtual Server
System Management
Web-based Management for Configuring System
Firmware Update via HTTP
Reset To Factory Settings
Event Alert and Logs
1
© INTELLINET NETWORK SOLUTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 501705 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intellinet 501705

  • Page 1: Product Specifications

    The SA integrates server services such as a Network Address Translator (NAT), Virtual Private Network (VPN), SPI firewall, and networked storage into one easy to manage device. The SOHO Server allows a group of trusted computers and networks to connect quickly and safely. With the...
  • Page 2: Benefits And Key Features

    USB Printer Server USB Storage Sharing Personal POP E-Mail Server Benefits and Key Features Virtual Private Network With Virtual Private Networking, an enterprise can establish a dedicated tunnel among branch offices and/or mobile employees. All data is encrypted © INTELLINET NETWORK SOLUTIONS...
  • Page 3 Easy Installation In order to facilitate the use of the SOHO Server , the product comes with default settings that most network managers can install it without any modification. If the network manager needs to modify any of the settings, the SOHO Server provides an intuitive Web-based user interface.
  • Page 4 FTP Server FTP is the most secure, fastest, reliable method of transferring files. The FTP server allows you full control over who can login to the SOHO Server , which files the user can access or they could upload data.
  • Page 5 If you select ’5 mins’, the hard disk will enter standby mode once it is idle for more than five minutes. Physical Parts and Panel of the Smart Server One WAN port: 10/100 Mbps © INTELLINET NETWORK SOLUTIONS Figure 3.2a...
  • Page 6 Reset Button If you forget your password and/or IP settings, you will not be able to access the SA. You can use the Reset Button to restore the factory settings. To © INTELLINET NETWORK SOLUTIONS...
  • Page 7: Package Contents

    1 LED on Throughput 2 LEDs on Current transfer rate is >50KB/s 3 LEDs on Current transfer rate is >100KB/s 4 LEDs on Current transfer rate is >500KB/s Package Contents © INTELLINET NETWORK SOLUTIONS Default Settings <empty> Admin 172.16.1.1 Meaning...
  • Page 8 Smart Server Power Adapter and Power Cord Ethernet cable User Manual CD Quick Installation Guide © INTELLINET NETWORK SOLUTIONS...
  • Page 9: Quick Installation

    Connect the included power adapter to the power socket on the SA and then plug the power adapter into a wall outlet. Turn on the SA. If the link LED of the WAN port is not ON, switch the WAN MDI/MDIX switch to the alternate setting. © INTELLINET NETWORK SOLUTIONS...
  • Page 10: Check Your Pc First

    Select Internet protocol (TCP/IP) item and then click the Properties button. The “Internet Protocol (TCP/IP) Properties” window shows up (Figure 2.2c). Select the “Obtain an IP address automatically” radio button then click the OK button. © INTELLINET NETWORK SOLUTIONS Figure 2.2a...
  • Page 11 Figure 2.2b © INTELLINET NETWORK SOLUTIONS...
  • Page 12: Connect To The Web-Based Manager

    2. An authentication window shows up to prompt you to type the username and the password. 3. Leave the username blank and type “admin” as a password. (Figure 2.3a.) 4. Then press OK button. The default web page will appear like Figure 2.3b. © INTELLINET NETWORK SOLUTIONS Figure 2.2c Figure 2.3a...
  • Page 13: Web-Based Manager - Basic Settings

    Figure 2.3b Web-Based Manager – Basic Settings Start to configure your network environment by clicking the Basic Settings in left menu. The Basic Settings page is shown as Figure 2.4a. © INTELLINET NETWORK SOLUTIONS...
  • Page 14 You must click the apply button after you finish inputting the settings. You will see a rebooting window as Figure 2.4b. During the rebooting phase, do not turn off or unplug the SOHO Server . © INTELLINET NETWORK SOLUTIONS...
  • Page 15 For the Network Address Translation (NAT) application, the private network address should be set in the following address range reserved by the Internet Assigned Numbers Authority (IANA). Class Address Range A Class 10.0.0.0/10.255.255.255 B Class 172.16.0.0/172.31.255.255 C Class 192.168.0.0/192.168.255.255 © INTELLINET NETWORK SOLUTIONS Figure 2.4b...
  • Page 16: Domain Name Server

    Example 1: If you are connecting through a fixed IP address from the ISP. Example 2: If you are connecting through a dynamic IP address from ISP. Example 3: If you usually enter a username and password to access the Internet. Example 1: Fixed IP Address Settings © INTELLINET NETWORK SOLUTIONS...
  • Page 17 1. Select the Fixed IP Address radio button. 2. Enter the Public IP address. 3. Enter the External Gateway. 4. Enter the External Netmask. 5. Click the apply button. Example 2: DHCP Client / Cable Modem © INTELLINET NETWORK SOLUTIONS...
  • Page 18 The DHCP server will dynamically assign these fields. In general, you should choose this option if you are connecting the SOHO Server to a cable modem. Note: Cable modem users MUST disconnect the cable modem from the wall outlet for at least 2 minutes before turning it on again.
  • Page 19 3. Click the apply button to save your settings. After completing your configuration, each time the SA boots, it will try to connect with your ISP and the ISP will assign the SOHO Server an external IP address. Once successfully connected, the Status field should reflect this.
  • Page 20 4. Enter the IP address of your host in My IP Address. 5. Enter the IP address of the server in Server IP Address. In the following chapters, we will cover more details of configuring the SA. © INTELLINET NETWORK SOLUTIONS...
  • Page 21: Configuration Hierarchy

    Configuration Hierarchy This chapter gives you an overview of all the configuration options available. The SOHO Server is a multifunction product. The section3.1 explains the corresponding settings for each function. And in section3.2, we describe the power management in detail.
  • Page 22 Overview of Configuration Menu Figure 3.1...
  • Page 23: Network Settings

    Network Settings When you select Network Settings in the left menu of the web page, five configuration options appear: DHCP Server, IP Alias, Multiple NAT, Route Settings and DDNS. Please refer to the corresponding section for these configurations. DHCP Server In DHCP Server settings, we assign the rage of the virtual IP addresses for the four LAN ports of SA.
  • Page 24 Under DHCP server settings, the SA defaults to assigning IPs 172.16.1.2 through 172.16.1.250...So depending on how many fixed IP devices they have, they can assign their device to an IP of 172.16.1.251 (through 254) as these IPs will not be handed out by the SA. If they have more devices or want a different IP range, then all they need to do is modify the range that the SA hands out so it does not hand out an IP in that range.
  • Page 25 To Disable the DHCP Server If you already have a DHCP server on your network, 1. Select Disable radio button 2. Click the apply button. Or you do not have DHCP server on your network, but you would like to assign a static IP address to each device connected to the LAN port of SA.
  • Page 26: Multiple Nat

    Please follow the steps to add another network: 1. Enter “192.168.1.1” in IP Alias 1. 2. Enter “255.255.255.0” in Netmask of IP Alias 1. 3. Click the apply button. Note that the IP Alias 1, 192.168.1.1 is assigned to SA and the network is “192.168.1.x”.
  • Page 27: Route Settings

    packets from always sending on the same IP address and the other IP address to sit idle. Multiple NAT solves this and allows you to increase the bandwidth. Multiple NAT allows you to dispatch your network packets evenly to these IP addresses provided by ISP. 1.
  • Page 28 (Routing Information Protocol). If the router supports RIP, it will automatically exchange routing information with SA and it is not necessary to set a static route. Please refer the steps and figures to set a static route. 1. Select Enable radio button in Routing Setup. 2.
  • Page 29 Internet. DDNS provides a simple, and in most cases free, solution. The Internet uses DNS servers to lookup domain names and translates then into IP addresses. Domain names, such as www.yahoo.com, are just easy to remember aliases for IP addresses. A dynamic DNS service provides a means of updating your IP address so that you listing will be current when your IP address changes.
  • Page 30: Firewall Settings

    3. Enter the User name. The user name you log in DDNS service. 4. Enter the password. The password you log in DDNS service. 5. Enter the Host name. The host name you register in DDNS service. 6. Click the apply button. Every time your public IP changes, the SA will tell the DDNS server what your new IP address is.
  • Page 31: Virtual Server Settings

    Virtual Server Settings The virtual server service is a way to simulate multiple servers on the intranet. You have several IP addresses within your LAN. These IPs are not visible to the users from the Internet. When servers are installed in the office that need to be seen from the Internet, we establish some forwarding rules to deal with the packet from the Internet users and direct the SA to forward the specific packets to the specific IP address.
  • Page 32: Url Filter Setup

    or enter “0” in each field for none. 6. Click the apply button. URL Filter Setup The URL Filter function is used to restrict internal hosts from accessing specific URL locations. You deny any access to the URL location specified in the Site1, Site2 …Site10 fields.
  • Page 33: Ip Filter Setup

    IP Filter Setup The IP filter function is similar to URL Filter. It provides further restrictions in access permission. URL Filtering only blocks port number 80 (HTTP). In IP filtering, you can assign a group of IP to be restricted. You can block four individual ports or a range of ports in the same time.
  • Page 34: Denial Of Service

    Denial of Service It is highly recommended that the DoS Protection feature be enabled to prevent attacks on the network. However, if you allow someone to manage the router from outside or are running a web server, e-mail server, or FTP server, you should either disable Detect SYN Flood Attack or increase the TCP flow.
  • Page 35: Pptp Settings

    PPTP Settings For most companies, the PPTP server creates a secure connection that a remote user can access a host within the company. The remote user has to run a PPTP client and connect to the PPTP server. The PPTP server has to validate the remote user as being in the User List in section 9.1.
  • Page 36: System Management

    System Management When you select the System Management item in the left menu, four configuration items appear including; Administrator Settings, Event Report Settings, Firmware Update, Time Settings and SNMP. Please refer the corresponding section for these configuration details.
  • Page 37: Administrator Settings

    Administrator Settings In Administrator settings you will find the basic administrator functions. The settings are easily modified and managed by the administrator. They are described as below: 1. New Password: the administrator could change the administrator password here. Please enter the new password you would like to change to.
  • Page 38: Event Report Settings

    6. Restart device: This function reboots the SOHO Server . Select the enable radio button to restart SA. The default setting of the function is disabled. 7. Clear event log: This function is used to clean the system history that is listed in Event Report (section 8.2).
  • Page 39: Firmware Update

    Firmware Update Updates and functionality can be added via this function. Please check the web for the latest firmware if you are having any issues. In general, no update should be needed unless it is recommended by technical support. Note: Do not do a firmware update over a wireless connection or power the unit down during a firmware update.
  • Page 40: Time Settings

    Though it is not generally necessary, you should Restore factory default to make sure that new features and settings are implemented. Note: You must re-initialize the hard drive if you do this. Time Settings The NAS’s built-in clock should be adjusted to the current local time. This will insure accurate time reporting in the logs and file records.
  • Page 41 SNMP The SNMP agent allows users with SNMP client applications to conveniently inspect the network status of SA. Please follow the steps below to setup the SNMP agent. 1. Select the Enable radio button in the SNMP Agent field. 2. Enter the Community Name. Note that the agent side and the client side must use the same community name.
  • Page 42: System Reports

    System Reports When you select System Reports in the left menu of the web page, four configuration items appear including; System Information, System Log, URL Log, and DHCP Lease Report. Please refer to the corresponding section for these configuration items.
  • Page 43: System Information

    System Information The System Information displays some useful information about the system. It shows the firmware version, the system up time and the internal and external network connections. On SA, We have one WAN port and four LAN ports. The WAN port belongs to the external network interface and the LAN port belongs to the internal network interface.
  • Page 44: System Log

    If your external connection is not set to a fixed IP address, you can check whether the SOHO Server has obtained an IP address after booting. If there is no external IP address, you should check your network connection or environment settings.
  • Page 45 URL Log The URL Log function records the recent connections for each client. If you would like to view what the user is browsing, you can click the corresponding Destination URL in the rightmost column.
  • Page 46: Dhcp Lease Report

    DHCP Lease Report The DHCP Lease Report function reports all leased IP provided by DHCP server. From this page, you can find out which host was assigned to which IP address. You can clear all the records through administrator settings. Please refer to the section 7.1, Clear DHCP Lease.
  • Page 47 Users For file sharing to work, we have to allow users and/or groups. We create the user accounts here. The admin and guest accounts are in the system by default and cannot be removed. The admin account is different than the one used to access the UI and can be modified.
  • Page 48 Groups After creating the users, you can categorize the users into different groups to make assignment easier. Click on Add to create a new group name. Enter the group name Highlight the user(s) on the right side and click on the button to assign the user(s) to the group.
  • Page 49: Nas Management

    NAS Management Manage the main functions of the shared storage from this menu. HD Initialization Wizard The first time you use the NAS, you may have to initialize the hard disk. The wizard provides an easy way to initialize the hard disk. By enabling SMART, the NAS will report...
  • Page 50 Enter the workgroup name, description and initial share folder name. The workgroup name should be the same one that the computers accessing the NAS are on. Windows 2000/XP users can use a different workgroup name if desired. Click Next to continue. You can find your workgroup name by right clicking on My Computer and selecting...
  • Page 51 The progress of the initialization will be displayed. You can also view the progress by returning to the main wizard screen. Once the initialization is complete, the status will change to Ready. USB HD Information Each of formatted partitions (FAT32, EXT2 and EXT3) on the attached USB storage drive will be shown in the USB HD information page.
  • Page 52: Advanced Settings

    Advanced Settings All the file protocols settings are located here. Disable any protocols not in use by the computers on the network to increase performance. Most users will not need to change any of the settings. Make sure to click on Apply after making any changes.
  • Page 53: File Sharing

    Enter the Remote UID, IP, netmask and the local mapping user. Once complete, mount the share on the Linux machine. A typical mount command line: # mount <IP address>:/<share folder> /<local directory> File Sharing For file sharing, you must create users and groups first. Use this to organize the data on the NAS.
  • Page 54 Highlight the share folder and click on Remove or Modify to delete or edit the shared folder properties. USB Storage Sharing As mentioned above, each partition of the attached USB storage will be presented to one shared folder. So, if one USB storage device be plugged into A port and it have 2 partitions.
  • Page 55 FTP Server If you want to access files stored on your NAS from a remote location, the included FTP server is the easiest way. Here is a typical setup: Connection Diagram: Work PC<-->Internet<-->DSL/Modem<-->Router<-->NAS To access files from the NAS from a remote location, a static IP and/or a DNS name is required.
  • Page 56: Personal Web Server

    Now from the remote location, type into a browser (or FTP application) ftp://<DDNS Name> and it will take you to your NAS unit. If you cannot see anything on your browser, make sure you have the 'View FTP Folders' option turned on in your browser settings.
  • Page 57 Web page design You must have an 'index.html' file as that is what the web server will look for as the first page of your website. You are free to make folders under the ‘www’ directory to help organize your website. All references to those directories can be called on from any page.
  • Page 58: E-Mail Server

    E-mail Server The E-mail Server settings are located under Nas Management->E-mail Server. Getting started In order to use the e-mail server, you must have a domain name or have registered with a DDNS service provider. E-mail requires a domain name and will not work with just an IP address.
  • Page 59: Windows Usb Printer Server

    Windows includes MS Outlook Express as a standard application. Start Outlook. Under Tools->Mail, you want to ADD a mail account. Enter a display name, the formal name you want your e-mails to appear to come from (Usually your full name). In the e-mail address field, enter your new e-mail address.
  • Page 60 Connect a USB Printer to the USB port on the back of the NAS and turn it on. Locate the NAS device in My Network Places and select it by double clicking on the icon. Enter a valid user name and password when prompted.
  • Page 61 PPTP VPN (W2K and XP only) Important: Make sure that the subnet of your Appliance is different the network you are trying to connect from. For example: User’s office IP addresses are 192.168.1.x, set your Appliance to 192.168.2.1 Netmask 255.255.255.0. Make sure that you have created a user account and password on the Appliance for the users that you want to allow VPN access.
  • Page 62 desktop. Click Finish when done. 7. Use the user name and password on your Appliance to log in. You should be able to see the Appliance in your network neighborhood now. You must initiate the VPN connection each time unless you selected otherwise.
  • Page 63 Searching the Network for the NAS If you are not able to locate the NAS in the Network Neighborhood or My Network Places, you can try to search for it. Click Search under My Network Places. Enter the name of the NAS or the Fixed IP address if configured that way and click Search Now.
