Summary of Contents for INVENTABLES X-Carve Pro
- Page 1 X-Carve Pro Maintenance and Service Procedures 760-00021...
- Page 2 This document is intended for internal and external consumption and to be used as reference for field service issues and maintenance recommendations. Please read the X-Carve Pro Safety Manual and familiarize yourself with safe operation of the machine. Regular maintenance...
- Page 3 ● Check weekly Maintenance for linear rails and ball screws - grease The linear rails and ball screws on your X-Carve Pro come pre-greased from the factory. Generally, customers should not need to regrease the linear guides or ball screws before 6 months of regular use.
- Page 4 © Inventables, Inc. First home the machine, then move the X axis 24” to the right and the Y axis 10” to the back for easy access to the grease points. Then open the grease gun packaging and assemble the gun as shown in the picture below.
- Page 5 © Inventables, Inc. Belt Tensioning The belts used in the X-Carve Pro are synchronous belts whose tension is set at the factory; they don’t require very high tension to operate properly. New rubber belts tend to stretch and loosen during operation in the first few weeks/months, after which they will tend to operate normally at lower tensions.
- Page 6 © Inventables, Inc. ● Using a 2.5mm allen wrench take off the 3 screws that hold the X limit switch bracket in place ● Unplug the switch Molex connector ● Using a 3mm allen wrench remove the screw holding in the limit switch ●...
- Page 7 © Inventables, Inc. ● Use a 3mm allen wrench and take off the 2 screws on the top and 2 screws at the back of the Z axis plate holding the Z axis cover in place ● Use a phillips head screwdriver to remove the screw holding in the limit switch ●...
