- Page 1 HDC OWNER'S MANUAL INFORMATION FOR OWNERS AND USERS Liftgate CANTILEVERS 79255TL - HDC Owner's Manual, 2022-04-22 Must be kept in the vehicle on which the Liftgate is installed...
-
Page 3: Table Of Contents
Table of Contents Important information ................5 Technical support ..................5 Spare parts & accessories ................. 6 Service ......................6 Product discontinuation ................6 Warranty...................... 6 Information concerning the clause on remote diagnostics ....10 Privacy ...................... 10 Attention! ....................11 Safety rules ..................12 General ...................... - Page 4 Operation....................28 General ...................... 28 Max load ....................29 Operator working position ............... 30 Working on the platform ................31 Loading and unloading with the platform on ground ......33 Loading and unloading with the platform on a loading dock ....34 Loading/unloading at loading dock with the platform under the loading dock ..................
-
Page 5: Important Information
Important information Important information Before using the Waltco Liftgate, you must read and understand the contents of this manu- al and especially the sections describing safety. The owner’s manual is primarily intended to inform you about the Liftgate’s functions and characteristics and how to use it in the best way. -
Page 6: Spare Parts & Accessories
Important information Spare parts & accessories If spare parts or accessories are required, contact your nearest service provider. Service If service is required, contact your nearest service provider. Product discontinuation For information on product discontinuation, see section “8 Product discontinuation” on page 60. Warranty 1.5.1 Warranty period... - Page 7 65. • The annual service was carried out according to Waltco’s instructions and by a Walt- co-approved service provider. Service must be noted in the service record. See section “9 Service record” on page 61.
- Page 8 Liftgate seller or installer, or to the service provider that installed the spare part. • External equipment: Damage caused by external equipment or materials not approved by Waltco. For ex- ample, equipment connected to the Liftgate electrical system. Parts that have previ- ously been repaired without Waltco approval. •...
- Page 9 Important information • External costs: Emergency actions, on-call, travel expenses, rental, lost income, damage to goods. • Missing parts: If multiple parts are submitted with a claim application, parts that have no identified defects covered by the warranty will not be replaced. Example: A valve is found to be faulty and the valve and solenoid are both submitted; however, only the part that has a defect covered by the warranty is replaced.
-
Page 10: Information Concerning The Clause On Remote Diagnostics
Important information Information concerning the clause on remote diagnostics Waltco, or a third party designated by Waltco, shall at all times have the right to (i) install, maintain and dismantle a remote diagnostics device in and from the products; and (ii) -
Page 11: Attention
Important information Attention! The Instructions for use contain the following warning signs. They are intended to alert you to conditions that could cause problems, incidents, injury, and/or damage to the product, etc. WARNING! WARNING indicates a potential hazard, which if ignored may lead to serious, life-threatening injury. -
Page 12: Safety Rules
Liftgate and the vehicle to which it is fitted. NOTE! Waltco is not liable for any injury to persons or damage to property that may result from failure of the operator or other person to comply with the recommendations, warnings and instruc- tions set forth in these instructions for use. -
Page 13: Max Permissible Load
Safety rules Max permissible load Under no circumstances may the lift be burdened with more weight than the specified maximum load. Under no circumstances may the max load centre be placed further out on the platform than the load centre distance specified for the Liftgate. Information about the max permissible platform load and the load centre distance for max load is shown on decals affixed to the Liftgate or vehicle. WARNING! Under no circumstances is it permitted to load the platform with loads greater than those specified on the decals. Excessive load can cause structural damage. Risk of material damage... -
Page 14: Maintenance, Repairs And Service
When working on the Liftgate, switch off the main power supply. Use only spare parts and accessories approved or recommended by Waltco. Any other use may lead to changes that impair Liftgate function and safety. This may also render your Liftgate warranty invalid. -
Page 15: Operation
Risk of material damage and life-threatening injury. CAUTION! Waltco is not liable for any injury to persons or damage to property that may result from failure of the operator or other person to comply with the recommendations, warnings and instruc- tions set forth in these instructions for use. - Page 16 To reduce the risk of foot injuries, wear safety shoes with protective steel toe-caps when work- ing on the platform. Even though the platform has a non-slip surface, take care when transfer- ring goods. Waltco recommends the use of anti-slip safety shoes with protective toecaps in accordance with EN ISO 20345. Risk of injury.
-
Page 17: Intended Use
Safety rules Intended use WARNING! The Liftgate may only be used for its intended purpose, i.e. the loading and unloading of goods, and then only in accordance with the regulations contained in this owner's manual. No other type of use is permitted as this may damage the Liftgate and give rise to dangerous situations. Risk of material damage and life-threatening injury. -
Page 18: Work Area
Safety rules Work area The operator must make sure that the working area around the Liftgate is free from persons and any object when the Liftgate is used. The operator must also pay attention to the surroundings beyond the working area to have good forewarning of approaching persons or objects that may cause a hazardous situation. -
Page 19: Operator Working Position
Safety rules 2.10 Operator working position Always position the vehicle to allow Liftgate operation without danger from passing traffic. Also make sure the work area is clear. WARNING! The vehicle must be positioned to allow Liftgate operation without danger from passing traffic. Risk of material damage and life-threatening injury. CAUTION! Always make sure the work area is clear during platform operation. Risk of injury. -
Page 20: Design And Function
Design and Function General The Waltco Liftgate consists of a number of main components, namely the frame, lift arms, platform and chassis bracket. The Liftgate is operated electro-hydraulically. A hydraulic pump powered by the vehicle's ordinary battery supplies hydraulic oil to the actuating hydraulic cylinders. -
Page 21: Lift Arm
The electric lowering valve also acts as a locking device during transport. Control system Waltco Liftgates may be fitted with advanced types of control systems adapted to the specific product. The control system controls the hydraulic system and thus the Liftgate’s various functions. The system interprets the operator's pushbutton commands as well as signals from various sensors in the Liftgate structure. -
Page 22: Cab Switch
Design and Function Cab switch The Liftgate can be fitted with a cab switch to switch control power On/Off. When the con- trol circuit is switched off, the lift is ‘locked’. The cab switch should always be in the OFF position during transport and whenever the Liftgate is not in use. Typical cab switch... -
Page 23: Safety Devices
Design and Function Safety devices 3.9.1 Limiting to a single operator The Liftgate may only be operated by one person at a time. The control system has a safety feature that prevents two people from operating the Liftgate simultaneously from different control devices. -
Page 24: Controllers
Design and Function 3.10 Controllers All Liftgate functions are controlled by one or more control devices. The lift can be operated by several different types of fixed, hardwired control devices and remote (radio) control devices. One of the control devices is the primary control device, which means it includes all pos- sible functions for the Liftgate concerned. The remaining control devices are secondary, which may mean the number of functions is limited for safety reasons. - Page 25 Location of fixed control device The Liftgate is fitted with one or more control devices. Only control devices approved by Waltco may be used. Fixed control devices are installed on the vehicle superstructure or on brackets below the superstructure. The control devices must be positioned according to applicable regulations, with a certain distance from the crush hazard area between the platform and the superstructure, but without restricting the operator’s clear view of the...
-
Page 26: Electric Autotilt
Design and Function 3.11 Electric autotilt The electric autotilt feature simplifies Liftgate operation. Autotilt-down is enabled automatically when the Down function is used and when the platform rests on the ground. This function automatically tilts the tip of the platform down towards the ground. In autotilt down, the tilt function is driven solely by gravity. For fastest operation, the plat- form should first be tilted manually to the horizontal position before enabling autotilt. -
Page 27: Overheating Protection
Design and Function 3.12 Overheating protection The hydraulic system is equipped with a thermostat which cuts control circuit power and reduces the risk of damage to the motor if it overheats, which may occur during e.g. contin- uous, intensive use. The amount of continuous work the Liftgate is able to perform is influenced by ambient temperature and the load the Liftgate is exposed to. -
Page 28: Operation
Waltco is not liable for any injury to persons or damage to property that may result from failure of the operator or other person to comply with the recommendations, warnings and instructions set forth in this owner’s manual. -
Page 29: Max Load
2850 Ibs Max. 60 inches 78971TL Max. 4400 Ibs 4.2.1 Working in the dark CAUTION! Make sure the necessary and appropriate lighting is available when working in the dark. Waltco recommends fitting the Liftgate with warning lights for working in poorly lit areas. Risk of inches injury. 4400 Ibs Max. 40 inches 3500 Ibs Max. -
Page 30: Operator Working Position
Operation Operator working position Always position the vehicle to allow Liftgate operation without danger from passing traffic. Also make sure the work area is clear. WARNING! The vehicle must be positioned to allow Liftgate operation without danger from passing traffic. Risk of material damage and life-threatening injury. CAUTION! Always make sure the work area is clear during platform operation. Risk of injury. -
Page 31: Working On The Platform
To reduce the risk of foot injuries, wear safety shoes with protective steel toe-caps when work- ing on the platform. Even though the platform has a non-slip surface, take care when transfer- ring goods. Waltco recommends the use of anti-slip safety shoes with protective toecaps in accordance with EN ISO 20345. Risk of injury. - Page 32 Operation CAUTION! if possible, always stand inboard of the load when rolling it onto the platform. If necessary, turn the load and hand pallet truck around on the vehicle floor before rolling them out. Standing outboard of the load when rolling it onto the platform increases the risk of tripping and falling over the edge. Risk of injury and material damage.
-
Page 33: Loading And Unloading With The Platform On Ground
Operation Loading and unloading with the platform on ground IMPORTANT It is only permitted to drive a forklift on the platform when the platform is resting fully on the ground. Otherwise, the load on the Liftgate will be too great. Risk of material damage. During loading, the vehicle will get lower and the ground pressure on the Liftgate will in- crease by a weight equivalent to the total weight loaded in to the vehicle. -
Page 34: Loading And Unloading With The Platform On A Loading Dock
Operation Loading and unloading with the platform on a loading dock IMPORTANT Maximum load = Liftgate load capacity x 0.5. Exceeding Liftgate load capacity may cause material damage. It is forbidden to drive forklifts onto the platform as the load on the Liftgate would be too great. Risk of material damage. - Page 35 Operation 4.6.1 Adapt the platform to the dock As the vehicle is unloaded, the platform will rise relative to the loading dock. Tilt the plat- form down at regular intervals. Check that the platform has sufficient overlap (min 6’’) and that it rests safely and stably on the dock. 6” min. 150 mm 4.6.2 Maximum tilt-down angle It is forbidden to tilt the platform down more than 10º...
-
Page 36: Loading/Unloading At Loading Dock With The Platform Under The Loading Dock
Operation Loading/unloading at loading dock with the platform under the loading dock WARNING Overloading the lift may cause material damage. Always make sure there is sufficient space for the platform under the loading dock. As loading/unloading takes place, the vehicle height will rise/drop. If the platform is resting on a fixed point under the dock when unloading or lowered onto the surface when loading, a load corresponding to the weight removed from the vehicle will be applied to the lift, or added to the vehicle. -
Page 37: Moving Load From One Vehicle To Another
Operation Moving load from one vehicle to another IMPORTANT Maximum overrunning weight = Liftgate load capacity x 0.5. Exceeding Liftgate load capacity may cause material damage. It is forbidden to drive forklifts onto the platform as the load on the Liftgate would be too great. -
Page 38: After Use
Operation After use • Move the Liftgate into transport position. Refer to the relevant control device section for detailed information. • Lock the Liftgate On Liftgates with cab switches, switch off control power by setting the cab switch to Off. On Liftgates without cab switches, switch off the main power supply by setting the main switch to Off. -
Page 39: Fixed Control Devices, Standard Lift (Cd1)
Operation 4.10 Fixed control devices, standard lift (CD1) The control device governs all Liftgate functions. The control device is fitted with dead- man's buttons; when a button is released, Liftgate movement stops immediately. 1. Up 2. Tilt 3. Down... - Page 40 Operation Tilt down Press and hold the Tilt (2) and Down (3) buttons in that order. The platform is then tilted down at an even pace. Tilt down Down Press and hold the Down button (3). The platform is lowered at an even pace. Down...
- Page 41 Operation Depress and hold down the Up button (1). The platform is raised at an even pace. Tilt up Press and hold down the Tilt (2) and Up (1) buttons in that order. The platform is then tilted up at an even pace. Tilt up NOTE! Always lift the platform towards the top stop before tilting it to transport position.
-
Page 42: Operating With The Coiled Cable Control Device (Cd9)
Operation 4.11 Operating with the coiled cable control device (CD9) The control device is used when the Liftgate is in the working position and to control the Up, Down and Tilt functions. The control device is fitted with dead-man's buttons; when a button is released, Liftgate movement stops immediately. FUNCTIONS Tilt Down... - Page 43 Operation 4.11.1 Operation This procedure describes how to operate the Liftgate with the fixed control device (CD 10). Depress and hold down the ‘Up’ button (1). The platform is then raised at an even pace. Down Depress and hold down the ‘Down’ button (3). The platform is lowered at an even pace. Down...
- Page 44 Operation Tilting down Depress and hold down the ‘Tilt’ (2) and ‘Down’ (3) buttons in that order. The platform is then tilted down at an even pace. Tilt down Tilting up Depress and hold down the ‘Tilt’ (2) and ‘Up’ (1) buttons in that order. The platform is then tilted up at an even pace.
-
Page 45: Operating With The Coiled Cable Control Device (Cd10)
Operation 4.12 Operating with the coiled cable control device (CD10) The control device is used to control the Up and Down functions. The control device is fitted with dead-man's buttons; when a button is released, Liftgate movement stops immediately. FUNCTIONS Down... - Page 46 Operation 4.12.1 Operation This procedure describes how to operate the Liftgate with the fixed control device (CD 10). Depress and hold down the ‘Up’ button (1). The platform is raised at an even pace. Down Depress and hold down the ‘Down’ button (2). The platform is lowered at an even pace. Down...
-
Page 47: Service And Maintenance
5.6 Service Hydraulic oil If the hydraulic oil needs to be replenished, only the oil recommended by Waltco is permit- ted to be used. Waltco ships and recommends all liftgates use Shell Tellus 15 or equiva- lent. Recommended all year round. -
Page 48: Before Starting Work
Service and maintenance Before starting work IMPORTANT Carry out the following before starting any service or maintenance: • Lower and tilt the platform down so that it rests on the ground to reduce pressure in the hydraulic system to a minimum. •... -
Page 49: Daily Checks
Visually inspect all Liftgate components for cracks and deformations. Contact a quali- fied service engineer for troubleshooting or repair. Check that the platform is clean and safe to access. Remove any snow, mud, dirt, rubbish or slippery fluids. Waltco recommends the use of anti-slip safety shoes with protective toecaps to reduce the risk of injury. -
Page 50: Weekly Checks
Service and maintenance Weekly checks Carry out the following checks: Test all Liftgate functions using all control devices. Contact a qualified service engi- neer for troubleshooting or repair. Check hoses, connections and cylinders for cracks and leaks. Contact a qualified service engineer for troubleshooting or repair. Check the hydraulic cylinder boots for damage and secure fit. Contact a qualified ser- vice engineer for troubleshooting or repair. Check operation of the cab switch. Their function is described in section “3.8 Cab switch” on page 22. Contact a qualified service engineer for troubleshooting or repair. -
Page 51: Lubrication
Interval At a minimum, lubrication must be done every 3 months. More frequent intervals may be necessary when driving in aggressive surroundings or the lift is washed often. Contact Waltco for advice. 5.5.3 Before lubrication Before lubricating, clean the lift, especially the lubrication points and grease zerks. -
Page 52: Service
Service the lift regularly to keep maintenance costs low, safety high and product life long. An annual service must be carried out by a Waltco approved provider for the warranty to remain valid. For information about the nearest provider, visit the Waltco website or contact your distributor. -
Page 53: Decal
Decal Decal Below is an overview showing the location of the different decals. Decal illustrations and other information can be found under the relevant subheadings in the following pages. www.hiab.co 2020-03-04 55057TL... -
Page 54: Maximum Load Rating
Decal Maximum load rating The Decal shows the max permissible load on the platform. The Liftgate must never be laden with weights higher than permitted by the decal. Max permissible load only applies at a specific distance from the vehicle body (load centre distance). Behind this point, max permissible load is reduced. Refer to the decal on the platform or vehicle. -
Page 55: Identification Plate
To be used SERIAL NUMBER when ordering parts or of liftgate. To be used Date of manufacture DATE OF when contacting Waltco when ordering parts or Month/year MANUFACTURE for service or warranty when contacting Waltco Month / Year... -
Page 56: Control Device Sticker
Decal Control device sticker The control device sticker is affixed next to or on the relevant control device depending on its type. The decals are available in standard versions and in a latterally reversed version (option) for affixing on the opposite side of the vehicle. Control device sticker for CD 3 Control device sticker for CD1, CD 9 and CD18. The sticker comprises two parts. The narrow strip is only use with control device CD1. - Page 57 Decal 6.5.1 Additional Autotilt sticker There is an additional sticker affixed next to the control device sticker on Liftgates fitted with autotilt. The decals are available in standard versions and in a latterally reversed version (option) for affixing on the opposite side of the Additional Autotilt sticker for CD 3 vehicle. Additional Autotilt sticker for CD1, CD 9 and CD18. 2021-09-16 78922TL Additional autotilt sticker for CD 19...
-
Page 58: Danger Area
Decal Danger area The sticker is affixed on the inside of the superstructure next to the manual control device where fitted. The sticker informs of the hazards area between the vehicle floor and platform where the risk of crush injuries is especially great when operating the Liftgate. Danger area Warning flags Warning flags are mounted near the tip of the platform and the left and right edges to improve conspicuity when the platform is in the horizontal position. -
Page 59: Troubleshooting
Troubleshooting Troubleshooting The table below provides information about the most common problems and suggests steps to resolve them. If this simple guide does not help or in case of doubt, contact a qualified service engineer. Problem Probable cause Action Set the cab switch and/or main switch Cab switch and/or in the On position. -
Page 60: Product Discontinuation
Product discontinuation Product discontinuation General Liftgate disassembly must be carried out by personnel with the necessary knowledge and experience to ensure no dangerous incidents or environmental impact can occur due to igno- rance. Applicable regulations and legislation When disassembling and/or recycling, comply with local and national regulations and guidelines. 8.2.1 Before disassembly Before disassembly, drain the hydraulic oil tank, hoses and cylinders. -
Page 61: Service Record
Year 1 Service record Service Protocol L-Service (annual) Customer: Vehicle: Reg.No: Lift model: Prod.No: C=Check R=Replace L=Lubrication * If the lift has the equipment See instructions for Service points Information Comments resp. lift models Mecanics (Visual inspection of any cracks and / or damage) IE-0110 IE-0105 / IE-0104 1.1 Mounting bracket... - Page 62 If there are remarks concerning any of the service items, indicate any action below: Service checks (in the table below, confirm actions have been carried out for each service item. Service Remark/Action item Checks and actions have been carried out: ........................... Date Signature Company stamp...
-
Page 63: Own Remarks
Own remarks ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................... - Page 64 ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
-
Page 65: Declaration Of Conformity During Assembly
Company details/stamp Certificate of registration, delivery card The delivery card must be registered in C-Care for the warranty to be valid. The Owner is responsible for registering the delivery card by contacting Waltco at 330-633- 9191 or registering it in C-Care (www.c-office.com). User name and password are required to log in. There is no need to file the attached paper copy of the delivery card supplied with the Liftgate documentation after registration in C-Care. - Page 66 Waltco.com BUILT TO PERFORM Waltco, Del and Waltco are Hiab Liftgate brands. Hiab is a world-leading supplier of equipment, intel- ligent services and digital solutions for on-road load handling. As an industry pioneer, our company commitment is to increase the efficiency of our customers' operations and to shape the future of...
