- Page 1 10311001/10311002/10311003 Zephyrus Series Diaphragm Pump User Manual...
-
Page 2: Table Of Contents
Disclaimer & Warranty ....................3 LIMITED WARRANTY & DISCLAIMER ..................3 LIMITATION OF LIABILITY ....................... 5 Safety ..........................7 Zephyrus Series Diaphragm Pump – Introduction ............8 III. Main Features ......................8 Proper Use ........................9 IV. Zephyrus Series Diaphragm Pump Overview ..............10 V. -
Page 3: Disclaimer & Warranty
User Manual I. Disclaimer & Warranty • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 4 User Manual include biohazard decontamination procedures and other product-specific handling instructions, then, if applicable, Buyer may return the defective Products to the Company with all costs prepaid by Buyer. Replacement parts may be new or refurbished, at the election of the Company. All replaced parts shall become the property of the Company.
-
Page 5: Limitation Of Liability
User Manual WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE OR USE. THE COMPANY DOES NOT WARRANT THAT THE PRODUCTS ARE ERROR-FREE OR WILL ACCOMPLISH ANY PARTICULAR RESULT. NOTHING IN THIS MANUAL OR IN THE TERMS AND AGREEMENT AGREED TO AT THE TIME OF PURCHASE SHALL BE CONSTRUED TO PROVIDE FOR THE TRANSFER, ASSIGNMENT OR ALIENATION OF THE LIMITED WARRANTIES PROVIDED BY THE COMPANY HEREIN TO ANY OTHER PARTY OTHER THAN BUYER, INCLUDING BUT NOT... - Page 6 User Manual AMOUNT EQUAL TO THE LESSER OF (A) THE TOTAL PURCHASE PRICE THERETOFORE PAID BY BUYER TO THE COMPANY WITH RESPECT TO THE PRODUCT(S) GIVING RISE TO SUCH LIABILITY OR (B) ONE HUNDRED THOUSAND DOLLARS ($100,000), WHICHEVER IS LESS. With respect to any software products incorporated in or forming a part of the Product hereunder Buyer intends and agrees that such software products are being licensed and not sold, and that the words "purchase", "sell"...
-
Page 7: Safety
User Manual Safety IMPORTANT Safety Items to be Observed. Safety Warnings ! Dangerous (may result in serious loss of property or casualties) The instrument must be grounded and away from sources of electromagnetic interference. Before use, please confirm the voltage and frequency of the power supply match the instruments’... -
Page 8: Zephyrus Series Diaphragm Pump - Introduction
Main Features 3.1.1 Strong Chemical Corrosion Resistance The Zephyrus series corrosion-resistant pump uses a PTFE to coat all surfaces that in contact with the processed gas/liquids. These include the specially designed PTFE coated diaphragm and pump head, joint fixtures, and pipelines. Additionally, all electrical components and chassis are also solid PTFE or PTFE coated. -
Page 9: Proper Use
User Manual Proper Use The Zephyrus series are designed for non-residential use e.g. in schools, laboratories or factories and to be used in conjunction only with accessories recommended within this manual and by the manufacturer After Sales Support If problems are encountered or technical assistance support is required, when installing or using the instrument, please immediately contact the service department. -
Page 10: Zephyrus Series Diaphragm Pump Overview
User Manual IV. Zephyrus Series Diaphragm Pump Overview 4.1 Zephyrus Mini Diaphragm Pump 1. Suction Side 2. Discharge Side 3. Working Pump Body 4. Connection Pipe 5. Power Switch 4.2 Zephyrus Diaphragm Pump 1. Suction Side 2. Discharge Side 3. Working Pump Body 4. -
Page 11: Technical Specifications
User Manual V. Technical Specifications Product Name Zephyrus Mini Zephyrus Zephyrus Max Parameters Model 10311001 10311002 10311003 Rated Voltage / 110 V±10%/60 Hz Frequency rated power 240 W 400 W 400 W Pump Head Type Ultimate Vacuum, Two-Stage Pump Ultimate Vacuum 6～8 mbar Maximum Operating 1 bar... -
Page 12: Standards And Conformity
User Manual Standards and Conformity Construction in Accordance with the following Safety Standards: EN 61010-1 CSA C22.2#61010-1-12:2012 Construction in Accordance with the following EMC Standards: EN 61326-1... -
Page 13: Inspection
User Manual VII. Inspection Packing List Unpack the equipment carefully and check for any damage which may have arisen during transport. In the event of identified damage, please contact the supplier / manufacturer for technical support. • Carefully unpack the shipping container. •... -
Page 14: Installation Instructions
User Manual VIII Installation instructions 8.1 Unpacking inspection • Carefully unpack the shipping container. • Remove the diaphragm pump and accessories and make sure everything on the packing list is included. If anything is missing or damaged, please contact the service department as soon as possible to order a replacement. -
Page 15: Operating Instructions
The suction port of the pump should never be connected to any high-pressure sources such as pressurized argon or nitrogen tanks. If the Zephyrus series diaphragm pump fails to power on after being properly connected to the wall outlet, turn the power switch to ‘OFF’ and then ‘ON’. if the pump does not work after repeating this ‘OFF’/’ON’... -
Page 16: Fault Diagnosis
User Manual X. Fault Diagnosis Problems Possible Causes Possible Solution Check that the power supply and Instrument is not connected connection are correct and the power to a power supply switched ‘ON’. Open the base plate and check the power No power Fuse blown or wall circuit fuse and replace if necessary. -
Page 17: Maintenance And Cleaning
The inlet and outlet port connections of the pump must be sealed with a special corrosion resistant glue. It is recommended that the Zephyrus series diaphragm pump be stored in a dry and clean area after routine operations. The external surface of the Zephyrus series diaphragm pump should be cleaned after the power is disconnected using a non-abrasive cleanser.
