TS-1800 Site Preparation
Revision 1.1
July, 2020
Twine Solutions Ltd
www.twine-s.com
© 2019 Twine Solutions Ltd. All rights reserved.
This document and the information contained herein is CONFIDENTIAL to TWINE Solutions Ltd, and shall not be used,
published, disclosed, or disseminated outside TWINE in whole or in part without TWINE's consent. This document
contains TWINE trade secrets. Reverse engineering based on any of the information in this document is prohibited.
This copyright notice does not imply publication of this document.
This document shall not be circulated in part or whole outside TWINE.
Advertisement
Table of Contents
Related Manuals for Twine TS-1800
Summary of Contents for Twine TS-1800
- Page 1 © 2019 Twine Solutions Ltd. All rights reserved. This document and the information contained herein is CONFIDENTIAL to TWINE Solutions Ltd, and shall not be used, published, disclosed, or disseminated outside TWINE in whole or in part without TWINE's consent. This document contains TWINE trade secrets.
-
Page 2: Table Of Contents
Contents About This Guide ................... 3 Terms and Abbreviations ................4 Physical Description ..................5 Size and Weight ......................5 Shipping and Delivery ..................7 Shipping Pallet ......................7 Pallet Lifting Equipment ................... 7 Unpacking area ......................7 Transporting the System in a Building ..............7 Installation Area .................... -
Page 3: About This Guide
About This Guide The information and requirements provided in this document ensure proper installation and operation of the Twine TS-1800 Digital Thread Dyeing system. The customer is responsible for: Preparing the site as described in this document. Complying with all applicable local regulations. -
Page 4: Terms And Abbreviations
The following terms and abbreviations are used throughout this document: Term / Abbreviation Definition Ampere Alternating Current Above Sea Level °C degrees Celsius or Centigrade °F degrees Fahrenheit feet kilograms pounds TS-1800 Digital Thread Dyeing system Volts Alternating Current TS-1800 Site Preparation Guide Page 4... -
Page 5: Physical Description
Physical Description The TS-1800 comprises a single stand-alone unit, as shown in the figure below. Figure 1 TS-1800 Digital Thread Dying System Size and Weight The TS-1800 has the following main dimensions and weight: Length (L) 2.0 meters (79 inches) ... - Page 6 Figure 2 TS-1800 dimensions definition TS-1800 Site Preparation Guide Page 6...
-
Page 7: Shipping And Delivery
Shipping and Delivery Shipping Pallet The approximate size and weight of the TS-1800 system when mounted on a pallet is as follows: Length (L) 2.25 meters (89 inches) Width (W) 0.89 meters (35 inches) Height (H) 1.74 meters (69 inches) ... -
Page 8: Installation Area
Installation Area IMPORTANT! If the TS-1800 is going to be located in an area that is not on ground floor level, it is important that you take note of the weight and dimensions of the machine. You must ensure that you are able use existing elevators to get the system to a higher floor level. If existing elevators are not suitable, you will need to make special arrangements to ensure that the TS-1800 can be lifted to the required floor level. -
Page 9: Floor Plan
Floor Plan A sample floor plan is shown below, with the TS-1800 placed in a likely operating area. The dimensions shown in the figure are minimum clearance requirements. Note The floor where the machine is located should be non-carpet and easy to clean. -
Page 10: Electrical Requirements
The customer is responsible for ensuring that all tasks described in this section are performed by qualified personnel. Power A stable, reliable source of power is necessary. Power to the TS-1800 is supplied via a standard wall socket. TS-1800 power rating: Total power consumption is 3KW. -
Page 11: Residual Current Or Earth Leakage Device
The Power cable cord that supply with the machine, is without power plug in order to made worldwide compatibility, the local plug assembly should preform by local Electrician according the safety regulation at your country. TS-1800 Site Preparation Guide Page 11... -
Page 12: Network
Network Network Connections The TS-1800 should be located in an area with access to a strong Wi-Fi signal, and connected to the network via a LAN communication connection. Min. Internet Speed 40mb Port 80,1080 and Port 443 must be open(outside) in order to enable SW upgrades and online support. -
Page 13: Environmental Conditions
Operating altitude must be ≤3000m ASL. Air Quality The TS-1800 should be located in a room with adequate ventilation. Typically, this means locating the TS-1800 in an airconditioned area where the air is replaced at least four (4) times per hour. System Environmental Specifications Indoor use ... -
Page 14: Accessories And Utilities
Accessories and Utilities Start-Up Kit The TS-1800 comes supplied with a start-up kit which includes tools and accessories. Make sure that your start-up kit is available during installation and operation. Fire Safety Equipment Use only gas-based fire extinguishers in case of fire. -
Page 15: Materials Handling And Storage
Ink cartridges may be used only up to the expiration date specified on the cartridge. 10.2 Waste Cartridges It is recommended that waste cartridges are stored separate from ink cartridges. Dispose of waste cartridges in accordance with local laws and regulations. TS-1800 Site Preparation Guide Page 15... -
Page 16: Customer Information
Customer Information Please fill in the information requested below and send it to your Twine representative. When your Twine representative approves your checklist, he will schedule the system installation. If you have any questions, consult your Twine representative. 11.1 Customer Details... - Page 17 Item Meets Requirements Notes Ventilation Fire extinguisher I understand that non-compliance with the requirements specified in this document may result in additional installation charges. Full name: Company signature: Date: TS-1800 Site Preparation Guide Page 17...
