- Page 1 Español P. 14 All-IN-ONE 304 STAINLESS STEEL UTILITY SINK WITH FAUCET AND DRAIN Owners Manual AF2421CS...
-
Page 2: Safety Information
If any part is missing or damaged do not attempt to assemble the product and contact AFA Stainless customer service for assistance. WARNING • Follow the installation instructions carefully. Proper installation is the installer’s responsibility. -
Page 3: Parts List
PARTS LIST Faucet A-1 Faucet Body A-2 Mounting Stud A-3 Gasket A-4 Mounting Nut A-5 Hot & Cold Supply Line A-6 3/16" (5 mm) Set Screw A-11 A-10 A-7 Diverter Handle A-8 Decorative Collar A-9 Retainer Nut A-10 Cartridge A-11 Aerator Utility Sink B-1 Sink B-2 Backsplash... - Page 4 Recommended Tools for Installation: T-1 (Included) T-2 (Included) T-3 (Included) Plumber’s Tape 3/32" (2,5 mm) Allen Wrench 5/32" (8 mm) Allen Wrench Phillips Screwdriver 1/4 Inch Bit Drill Bit Flathead Screwdriver Plumber Putty Phillips screwdriverbit Adjustable Wrench T-10 T-11 Channel Lock Wrench Hammer Pencil Important Information...
- Page 5 CAUTION: Shut off water supply prior to installation. Connect Connection pipe (B-7) Lay Sink (B-1) upside-down. Tighten screws on each Leg Collar Insert Legs (B-5) into Leg with 3 Way L Shape Connectors (B-9), with Allen Wrench (T-2). Collars (B-3). and put into the pre-installed legs.
- Page 6 Prepare strainer for installation. Place the Bottom gasket (D-3) on Open the faucet box and check all parts. Loosen the Lock nut (D-5) , check to the underside of the Strainer bowl (D-2). Place Top gasket (D-4) on ensure that all parts are complete. top of Lock nut (D-5) and tighten to Strainer bowl (D-2) using Channel lock wrench (T-9).
- Page 7 3/8" (10mm) Slightly lift sink and hook flange Connect the P-trap (Not included) Wrap the water on/off valve threads of sink over Bracket(B-4). Adjust to the drain. with one complete revolution of Feet Levelers (B-6) to ensure sink Plumber’s tape (T-1). Attach cold & is stable and level.
- Page 8 3 / 4 " B-13 Connect the garden hose to 3/4" adapter. And connect the water supplies to 3/8" adapter.
- Page 9 CLEANING AND CARE OF AERATOR A-11 Remove the Aerator (A-11), use a Flush the Aerator (A-11). Install the Aerator (A-11). soft cloth in the joint of Adjustable Use a soft cloth in the joint of the Wrench (T-8) to loosen if needed. Adjustable Wrench (T-8) and Be careful not to scratch the tighten Aerator (A-11).
-
Page 10: Helpful Tools
CARE AND REPLACEMENT OF CERAMIC CARTRIDGE AFA Stainless is committed to producing the finest Solid Stainless Steel Faucet on the planet. A major component that is a secret to AFA’s success, has been the long standing relationship with German manufactured Fluhs, the worlds most advanced leader of high quality, technologically suburb ceramic cartridges guaranteed for life. - Page 11 3/32" (2,5 mm) Using 3/32" (2,5 mm) Allen wrench Remove Diverter handle (A-7) Remove Decorative collar (A-8) (T-2 Included) carefully loosen and set aside. and set aside. Set screw (A-6) inside diverter. (Do not remove screw). A-10 Use Adjustable wrench (T-8) and Remove Cartridge (A-10).
-
Page 12: Cleaning And Care Instructions
Cold A-10 Install new Cartridge (A-10). Turn on hot and cold water supply Reassemble faucet by reversing valve(s) counter clockwise. Run steps. water and check for leaks. CLEANING AND CARE INSTRUCTIONS – Please ensure that the surface of your AFA product has cooled down before cleaning (clean at room temperature). –...
