Page 1
CUSTOM ULTRASONICS, INC. ONFIDENTIAL FFECTIVE # MAN 009 OCUMENT EVISION 15, 2008 PRIL # 20015 DCO: 115 AGE 1 of 7 20000 E ODEL NDOSCOPE TORAGE ABINET ’ PERATOR ANUAL USTOM LTRASONICS 144 R , PA 18974 AILROAD RIVE VYLAND...
Page 2
ABINET HYSICAL ESCRIPTION Model 20000 Endoscope Storage Cabinet continuously purges each of the endoscopes’ channels with forced air during storage. It is fabricated of painted steel to provide an environment for endoscope storage that is free of water-absorbent materials [e.g.: laminated wood] to minimize the risk of endoscope bacterial and/or fungal growth.
Page 3
SHEET REVISION 20000 E ODEL NDOSCOPE CUSTOM ULTRASONICS, INC. 3 OF 7 TORAGE ABINET ’ PERATOR ANUAL NSTALLATION Secure the cabinet to the wall using the brackets located along the top of the rear wall of the cabinet. When mounting your cabinet to the wall, do not drill holes through the interior walls of the cabinet.
Page 4
Remove any adapters that are not attached to an endoscope, making sure to always leave at least one adapter plugged into the manifold at all times. Model 20000 Endoscope Storage Cabinet Custom For the manifold attachments, contact Ultrasonics, Inc.
Page 5
When the indicator card shows that the desiccant bags need to be changed, remove the six (6) bags of desiccant from their holding compartment. Follow instructions on the desiccant bag for the re- activation procedure or contact Custom Ultrasonics, Inc. at 215-364-1477 for further information or to order new bags.
Page 6
SHEET REVISION 20000 E ODEL NDOSCOPE CUSTOM ULTRASONICS, INC. 6 OF 7 TORAGE ABINET ’ PERATOR ANUAL i. Cabinet is located flush to desired wall. ii. The provided mounting holes are used. iii. Mounting materials (bolts, etc.) suitable to facility’s structure and all building code are used.
Page 7
SHEET REVISION 20000 E ODEL NDOSCOPE CUSTOM ULTRASONICS, INC. 7 OF 7 TORAGE ABINET ’ PERATOR ANUAL Operator Use or Misuse related to potential hazards may become humid and failure to: a. Inspect the desiccant bags and humidity indicator cards daily i.
