OWNER'S MANUAL
MOTOR BOAT
CORSIVA 475 NEW AGE
Manufacturer
Corsiva Yachting
http:// corsiva.pl/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 475 NEW AGE and is the answer not in the manual?

Questions and answers

Summary of Contents for Corsiva Yachting 475 NEW AGE

  • Page 1 OWNER'S MANUAL MOTOR BOAT CORSIVA 475 NEW AGE Manufacturer Corsiva Yachting http:// corsiva.pl/...
  • Page 2: Table Of Contents

    CORSIVA YACHTING INDEX 1. INTRODUCTION ............................. 2 2. STAGE OF DANGER ............................3 3. GENERAL SAFTY RULES ........................... 4 3.1. Safety ................................4 3.2. Passengers on board ........................... 4 3.3. Life-saving equipment ..........................5 4. IDENTIFICATION OF BOAT ..........................6 4.1.
  • Page 3: Introduction

    The Owner’s manual, which you received together with a boat, will help you to operate your motor boat CORSIVA 475 NEW AGE safely and appropriately so you may use it with a pleasure. Manual contains the description of the boat, its equipment and installation systems as well as practical information about their use and maintenance.
  • Page 4: Stage Of Danger

    CORSIVA YACHTING 2. STAGE OF DANGER The manual contains three kinds of sign, which are supposed to turn your attention to the actions and situations which may cause danger for health or life if not realized. Following: DANGER The sign warns before appearing the highest danger, which can cause the durable damage of body or death unless the appropriate safety actions are taken.
  • Page 5: General Safty Rules

    CORSIVA YACHTING 3. GENERAL SAFTY RULES 3.1. Safety Even if it all planned the safety of the sailing remains heavily dependent on the weather, sea conditions and the experience and knowledge of the crew. Always check to-date weather forecast before leaving and see that the circumstances should be expected to the category of construction of the boat.
  • Page 6: Life-Saving Equipment

    CORSIVA YACHTING 3.3. Life-saving equipment On the yacht should be appropriate safety equipment (life jackets, safety harnesses, etc.) as appropriate to the type of boat, weather conditions, etc. In some countries it is Required equipment. Carefully read the manual of a life raft.
  • Page 7: Identification Of Boat

    The boat CORSIVA 475 NEW AGE was manufactured by CORSIVA according to applicable requirements of Annex I to Recreational Craft Directive 2013/53/UE. The boat CORSIVA 475 NEW AGE was put to the test by Polish Register of Shipping according with applicable requirements of Annex I to Recreational Craft Directive 2013/53/UE for design category C and D.
  • Page 8: Builder's Plate

    CORSIVA YACHTING 4.2. Builder's plate In the cockpit of CORSIVA 475 NEW AGE there is placed the builder’s plate. The builder’s plate includes: Boat design category – „INSHORE”. Boat design category – SHALTERED WATERS. Max. number of people and personal equipment which cannot max.
  • Page 9: Stability And Buoyancy

    CORSIVA YACHTING 5. STABILITY AND BUOYANCY...
  • Page 10 CORSIVA YACHTING DANGER Information about stability and freeboard, floatation and buoyancy is fulfilled only when: The weight of empty boat with equipment does not exceed 360 kg, The maximum power of engine does not exceed 22,4 kW Remember: any change in arrangement of the masses on the side (eg. The addition of a fishing tower, a change in the engine etc.) can significantly affect the stability, trim and behavior of the...
  • Page 11: Weight Of Boat And Maximum Capacity

    (4 / 5 persons + personal + equipment + inventories) CAUTION Never cross the safety limit definite by constructor in reference to the maximum load of boat. CORSIVA 475 NEW AGE can accommodate maximum 4 / 5 people + fuel, equipment, gear, outboard engine maximum 465 / 550 kg.
  • Page 12: Description Of Boat

    CORSIVA YACHTING 6. DESCRIPTION OF BOAT The yacht is made of durable glass-reinforced laminate as a monolithic construction and of high class materials, guaranteeing trouble-free use of boat for years. CORSIVA products are applied with such technical solutions which allow to get the optimal stability, reliability and control at the swerves as well as safety at overcoming waves.
  • Page 13: Engine

    CORSIVA YACHTING 7. ENGINE If a customer wishes, the boat is sold with outboard engine placed in the well in cockpit. In other cases, the manufacturer leaves routed wiring in the engine sump to the customer in the future he could connect the motor (photo).
  • Page 14: Steering System

    CORSIVA YACHTING 8. STEERING SYSTEM 8.1. System of steering the boat System of steering the boat’s rudder by the steering-wheel. Steering with an engine is regulated with the engine throttle, which is placed on the right side in cockpit. The throttle changes the speed and the direction of driving screw.
  • Page 15 CORSIVA YACHTING Navigational aids. Current receiver. Engine switch on and off Engine switch of The emergency switch which stop the engine in moment of danger, for example: in moment of overboard the helmsman. You cannot it use in normal stop of the engine.
  • Page 16: System Of Steering

    CORSIVA YACHTING 8.2. System of steering CORSIVA 475 NEW AGE boat is equipped with a mechanical control boat. It consists of: steering wheel, gear, steering system, steering links. CAUTION The control system requires periodic inspection, especially pay attention to: proper conduct of steering links, safe connection to the steering wheel.
  • Page 17: Fuel System

    CORSIVA YACHTING 9. FUEL SYSTEM The boat is equipped with a portable fuel tank made of plastic with capacity of 25L, which is placed in the aft locker. The fuel tank has a fuel gauge in his cap. Every fuel of tank is made according to PN EN ISO 10088 and have sign CE.
  • Page 18: Electric Installation

    CORSIVA YACHTING 10. ELECTRIC INSTALLATION The boat is equipped with electric installation of direct current = 12V. The main source of the boat is the battery with a capacity of 30 Ah to 72 Ah. battery located compartments. Before cruise, check the battery level.
  • Page 19 CORSIVA YACHTING CAUTION Never: work on the live electric installation, modify the craft’s electric system or relevant schemes; any modifications and maintenance should be performed by a qualified marine electric technician, leave the boat unattended with the working electric system.
  • Page 20 CORSIVA YACHTING...
  • Page 21: Sanitary System

    CORSIVA YACHTING 11. SANITARY SYSTEM On the boat is provided a chemical toilet in bow compartment. The rules of its use and maintenance are described in the manual book of WC manufacturer CAUTION Before using the toilet make sure it is open water intake valve.
  • Page 22: Bilge Instalation

    CORSIVA YACHTING 12. BILGE INSTALATION The bilge system is installed in the galley under the floor. Bilge pump suction nozzle Hand bilge pump inside engine compartment 1. Electric bilge pump, 2. Bilge pump suction nozzle, 3. Bilge houses, 4. Bilge pump outlet, On the boat is equipped with two automatic bilge pumps and one manual bilge pump.
  • Page 23: Bottom, Side Sea Openings

    CORSIVA YACHTING 13. BOTTOM, SIDE SEA OPENINGS The openings in deck, bottom and side may pose a danger as water can get into the boat. Sea valves are served manually, therefore they should be controlled. 1 The outlet of anchor lockers...
  • Page 24 CORSIVA YACHTING 4 The outflow from the engine compartment DANGER Never: leave the unattended yacht with open valves, change the construction of valves connection.
  • Page 25: Fire Protection

    CORSIVA YACHTING 14. FIRE PROTECTION The main source of fire on the boat is open fire such as a lighter or candle. WARNING Before using you should: get to know with manufacturer’s instruction in detail equip the boat with fire extinguisher and extinguishing blanket, pay attention to the usage of evacuation exits.
  • Page 26: Sundeck

    CORSIVA YACHTING 15. SUNDECK According with customer's wish the boat of superstructure can stand the place to sunbathing for crew. You should turn the special attention on behaviors of principles of safety and proper care of mattresses. DANGER Forbidding of transport the children's less 5 years old on stern sundeck and juvenile without lifejackets and parents or the guardians control.
  • Page 27: Upholstery

    CORSIVA YACHTING 15.1. Upholstery upholstery should installed according to the scheme as pictured. Each pillow mattresses has its own designation - it will help you to replacement of individual cushions, when it will be destroyed. Upholstery marked with the letter E -...
  • Page 28: Maintenance, Painting, Cleaning

    CORSIVA YACHTING 16. MAINTENANCE, PAINTING, CLEANING Your boat – the deck, hull and some interior parts were made of fiberglass. To keep the boat in good condition, wash the fiberglass regularly. Wash the boat with clean water with soft detergents, e.g. water with soap.
  • Page 29: Stainless Steel

    CORSIVA YACHTING 16.1. Stainless steel Constructions of bow and stern railings, as well as other metal elements were made of corrosion resistant steel, which means polished stainless steel. WARNIG If you want to keep stainless steel fitting in good state,...
  • Page 30: Trailering

    CORSIVA YACHTING 17. TRAILERING During the boat transportation it is very important to keep the boat in the horizontal position. Lifting belts should be in the places appointed with the red triangle on a hull according to the following drawing.
  • Page 31: Anchoring, Mooring And Towing

    CORSIVA YACHTING 18. ANCHORING, MOORING AND TOWING The owner of a boat / helmsman is responsible for equipping the boat with an anchor, anchor chain / anchor rope, mooring and towing lines ready to use. Anchorahe eguipment Place the anchor in the anchor compartment. Anchor rope is secured to the cleats.
  • Page 32: Environmental Protection

    CORSIVA YACHTING 19. ENVIRONMENTAL PROTECTION The chapter contains the indispensable information how you should protect the natural environment during sailing, as well from the crew as from the boat side. There are strict requirements concerning the respect of natural environment not only in many parts of Europe but also all over the world.
  • Page 33: Removing Failures

    CORSIVA YACHTING WARNING If the bilge water are dirty avoid the the work of automatic bilge pump, do not remove the illegal plants. Do not remove the contaminated bilge water overboard. WARNING In case if you lack the place for storing waste on the boat, you can remove only organic waste to water.
  • Page 34: Warranty

    8. Guarantee period becomes prolonged about time of possible guarantee repairs. 9. CORSIVA YACHTING Arthur Grugel it does not bear no responsibility for possible financial losses or different legal after-effect, caused pronouncement defect in complaint boat.
  • Page 35 CORSIVA YACHTING 10. Warranty does not include materials and maintenance, belonging to the normal operational service, eg. cleaning, maintenance, inspection, etc. 11. These warranties only include damage and defects resulting from causes inherent in the sold boat. Warranty does not include damage caused as a result of external factors, such as, for example.
  • Page 36 CORSIVA YACHTING Records warranty. Date Note about repair Date Guarantee Date, raising the realization signature and claim the repair prolonged stamp...
