Enjoy Your
USE AND CARE GUIDE
Assembly, Care And Use Instructions
Read Carefully Important:Retain These
Instructions For Future Reference.
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
E02GR004
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
Thank you for choosing Captiva Desings!
h
This appliance is for Household use only.
This is not a commercial appliance.
THANK YOU
inually create

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E02GR004 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Captiva Designs E02GR004

Summary of Contents for Captiva Designs E02GR004

  • Page 1 Enjoy Your USE AND CARE GUIDE E02GR004 This appliance is for Household use only. Assembly, Care And Use Instructions This is not a commercial appliance. Read Carefully Important:Retain These Instructions For Future Reference. Questions, problems, missing parts? Before returning to the store, please contact our Customer Service service@alphamarts.com...

  • Page 2: Table Of Contents

    Table of Contents Safety Information Curing your smoker 11-12 General Operating Instructions 12-15 Warning Cleaning and Maintenance Preparation Environmental Protection & Disposal Components Warranty Assembly Instructions 7-10 Safety Information Assembler/Installer This instruction manual contains important information necessary for the proper assembly and safe use of this appliance.

  • Page 3: Warning

    Warning WARNING: Risk of burning! • Make sure that the smoker is standing on a at and reproof surface that is not made of glass or plastic. WARNING: This smoker will become very hot, do not move it during operation! •...

  • Page 4: Preparation

    Preparation Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. Estimated Assembly Time: 20 minutes.
  • Page 5 Components 1. Lid 2. Body 3. Cooking Grate 1a: Lid – 1pc 1b: Air vent – 1pc Qty:1 Qty:2 4. Charcoal Grate 5. Charcoal Bowl 6. Water Bowl Qty:1 Qty:1 Qty:1 7. Handle 8. Short Grate Bracket 9. Long Grate Bracket Qty:3 Qty:3 Qty:3...
  • Page 6 Components...

  • Page 7: Assembly Instructions

    Assembly Instructions Please read the assembly instructions carefully and follow the safety precautions. Allow suf cient time for assembly. Before starting assembly, clear an area measuring approximately two to three square meters. Remove the item from the packaging. Lay out all of the parts and any necessary tools so that they are within easy reach.
  • Page 8 Assembly Instructions...
  • Page 9 Assembly Instructions – D This wing nut is pre-assembled on the thermometer...
  • Page 10 Assembly Instructions...

  • Page 11: Curing Your Smoker

    Curing Your Smoker Prior to your rst use of the smoker, follow the instructions below carefully to cure your smoker. Curing your smoker will minimize damage to the exterior nish as well as rid the smoker of paint odor that can impart unnatural avors to the rst meal prepared on the smoker.

  • Page 12: General Operating Instructions

    Curing Your Smoker Step5 With charcoal burning strong, close the lid. Allow the temperature to reach 225°F (107°C) on temperature gauge. Maintain this temperature for 2 hours. Step6 Increase the temperature to 400°F(205°C) on temperature gauge. This can be achieved by adding more charcoal and / or wood .
  • Page 13 General Operating Instructions Step3 Saturate charcoal with lighting uid. With lid open, wait 2 to 3 minutes to allow lighting uid to soak into charcoal. Store lighting uid a safe distance from the smoker. Step4 With smoker lid open, stand back and carefully light charcoal. Allow to burn until covered with a light ash (approximately 20 minutes).
  • Page 14 General Operating Instructions WATER SMOKING Step1 Put the charcoal in the charcoal bowl and light it up, carefully following the instructions on building a re that are listed on pages 11-13 Step2 Once unit is lit, position water bowl so rim is resting securely on notched out step of all support brackets.
  • Page 15 General Operating Instructions GRILLING Step1 Remove the cooking grates, water bowl and charcoal bowl with grate. Replace the cooking grate on middle bracket. Make sure the rim is resting securely on notched out step of lowest support brackets. Step2 Put the charcoal bowl on the charcoal grate on the middle cooking grate.

  • Page 16: Cleaning And Maintenance

    Cleaning and Maintenance WARNING: Risk of burning! Allow the smoker to cool down completely before cleaning it. Never use water to quench the hot smoker. This could result in burning or scalding. Occasional cleaning is necessary to preserve the beautiful appearance of the smoker. Do not use any scouring agents.

  • Page 17: Warranty

    Warranty LIMITED WARRANTY This warranty is a limited warranty, and applies to the original purchase is required. This is a residential warranty and does not applyto commercial use. This collection carries a (1) year limited warranty and is valid from original date of purchase to the original owner (proof of purchase required). HAT IS COVERED We warrant the frame to be free of Manufacturing defects to the original purchaser for one year.
