- Page 1 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTIONS SCENARIO 1: CHARGING VEHICLE BATTERY Step 1: Connect alligator cable with vehicle battery Step 2: Connect alligator cable with the PWM controller...
- Page 2 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTIONS Step 3: Connect SAE cable from the PWM controller and junction box 12V SOLAR CONTROLLER 12V SOLAR CONTROLLER Solar Panel Battery Load Solar Panel Battery Load Step 4: Charging the battery and cellphone through PWM controller and solar panel...
- Page 3 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTIONS SCENARIO 2 : CHARGING POWER STATION Step 1: Connect SAE from junction box to SAE adaptor (SAE to anderson or SAE to DC cable) a) SAE to anderson connector 12V SOLAR CONTROLLER Solar Panel...
- Page 4 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTION Step 2: Connect SAE adaptor to power station 12V SOLAR CONTROLLER Battery Load Solar Panel Step 3: Charging power station, then connect the electronic devices to the power station for charging...
- Page 5 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTION SCENARIO 3: CONNECT SOLAR BRIEFCASE TO RV/CAMPER WITH PRE-WIRED SOLAR SAE SOCKET Step 1: Connect the battery to the PWM controller. Make sure the positive (+) end of alligator clip connect to positive (+) end of the battery...
- Page 6 G SERIES SOLAR PANEL BRIEFCASE CONNECTION INSTRUCTION Step 3: With suitable SAE cable, connect the bare ends of the cable to the PWM controller in the same terminals as the alligator cable SOLAR CHARGE CONTROLLER CXLH CXLH 1000V DC IP65 2.5mm²...
