Cellular polycarbonate Greenhouse
2,1 м
3 м
ALFA
VOLCAN
model 2020
Technical certificate
Assembly manual
4,0м
p. 2-8
p. 9-39
Advertisement
Related Manuals for Madelux VOLCAN
Summary of Contents for Madelux VOLCAN
- Page 1 Quality management system (QMS) of LLC «Volya» is certified for compliance with standard of ISO 9001:2008 Certified by Russian Registry ALFA VOLCAN model 2020 Cellular polycarbonate Greenhouse 2,1 м 3 м 4,0м Technical certificate p. 2-8 p. 9-39 Assembly manual...
-
Page 2: Warranty
Technical certificate/GREENHOUSE «ALFA» Technical certificate/GREENHOUSE «ALFA» Cleaning and washing polycarbonate panels The assembly and operation of the «ALFA» greenhouse should be carried out strictly in accordance with the Assembly manual and operating rules 1. Rinse the panel with warm water. set forth in the technical certificate. - Page 3 STANDARD SUPPLY SET 4 PACKAGE 1 PACKAGE № denomination q-ty, pcs marking № denomination q-ty, pcs marking 4Н Lower arch 4НТ Lower end wall arch right End wall leg 4НТ-1 Lower end wall arch left Purlin 5 PACKAGE 2 PACKAGE №...
- Page 4 3 INSERT PACKAGE № denomination q-ty, pcs marking № denomination q-ty, pcs marking M4x35 screw Support M5x30 screw Inner clamp M6x16 screw Outer clamp 4.8x19 self drilling screw M4x12 screw 4.8x11 sharp-tipped screw М4х35 screw 32x4 washer M4 nut M4 nut 32x4 washer M5 nut 4.8x19 self drilling screw...
- Page 5 If the greenhouse is mounted on a foundation (see para.27), the elements are not assembled and are not mounted in the subsequent assembly. №1 from №2 from «1 package ALFA» «1 package ALFA» р.12-13 р.9 р.10 р.11 1 pc. 1 pc. №31 from «5 package ALFA»...
- Page 6 Inner side of the door. Perforation on the №41 from №13 from Inner side of the window. elements from the backside: «5 package ALFA» «2 package ALFA» 13-1 Perforation on the elements from the backside: 1 pc. 1 pc. №10 from «2 package ALFA»...
- Page 7 №17 from «3 package ALFA» Inner side of the end wall. Perforation on the elements from the backside: 1 pc. 4ВТ 4ВТ 4ВТ 4НТ-1 4НТ №40 from «5 package ALFA» 4НТ-1 2 pc. 4НТ №46 from «5 package ALFA» №20 from №21 from №27 from №42 from...
- Page 8 №43 from Inner side «5 package ALFA» 4ВТ 1 pc. 4ВТ 4ВТ №8 from «2 package ALFA» 1 pc. №43 from 4НТ-1 «5 package ALFA» 1 pc. №47 from «5 package ALFA» №47 from 1 pc. «5 package ALFA» 4НТ №42 from 1 pc.
- Page 9 №47 from №47 from Inner side «5 package ALFA» «5 package ALFA» 4НТ-1 1 pc. 1 pc. 4ВТ №27 from 4НТ «5 package ALFA» №27 from «5 package ALFA» 2 pc. 2 pc. 4Т 4НТ 4Т №41 from 4НТ-1 «5 package ALFA» №16 from №41 from «3 package ALFA»...
- Page 10 4ВТ №24 from Outer side «5 package ALFA» 1 pc. 4НТ-1 4ВТ 4Т 4Т 4НТ 4НТ/ 4ВТ 4НТ-1 х2 №42 from «5 package ALFA» 1 pc. №40 from «5 package ALFA» №24 from 4НТ/ «5 package ALFA» 4ВТ 2 pc. 4НТ-1 1 pc.
- Page 11 Cellular polycarbonate panels are installed with a certain surface, which has a protective layer, outside (towards the sun). The protective layer usually has a side with the inscriptions on the transportation film. The other side of the film is transparent. Mark the protective side of the sheet in each panel because after removing the transportation film, the sides of the panel do not visually differ.
- Page 12 In case the decorative steel lining (seal) from the additional kit is installed on the doors and windows see para.28 №42 from «5 package ALFA» №42 from 14 pc. «5 package ALFA» 18 pc.
- Page 13 In case the decorative steel lining (seal) from the additional kit is installed on the doors and windows see para.28 №42 from №42 from «5 package ALFA» «5 package ALFA» 29 pc. 19 pc.
- Page 14 №18 from «3 package ALFA» 4В 1 pc. №19 from «4 package ALFA» 1 pc. №19 from «4 package ALFA» 1 pc. 4Н 4Н х3 4Н 4Н №42 from №42 from «5 package ALFA» «5 package ALFA» 1 pc. 1 pc.
- Page 15 4В №22 from «5 package ALFA» 1 pc. №22 from «5 package ALFA» №22 from «5 package ALFA» 1 pc. 4В 1 pc. 4В 4В х3 4Н №42 from 4Н «5 package ALFA» 4Н 1 pc. №42 from «5 package ALFA» №42 from 1 pc.
- Page 16 4В 4Н №3 from «1 package ALFA» 5 pc. 4Н №23 from «5 package ALFA» 1 pc. №45 из «5 package ALFA» 4В 1 pc. №45 from «5 package ALFA» 4В 1 pc. 4ВТ 4Н 4Н №38 from «5 package ALFA» 1 pc.
- Page 17 LENGTHENING OF THE BASE WITH THE INSERT №51 from №50 from №49 from «2 package INSERT «2 package INSERT «1 package INSERT ALFA» ALFA» ALFA» №3 from 1 pc. 2 pc. 10 pc. «1 package ALFA» 5 pc. 4В 4В 4Н...
- Page 18 Cellular polycarbonate panels are installed with a certain surface, which has a protective layer, outside (towards the sun). The protective layer usually has a side with the inscriptions on the transportation film. The other side of the film is transparent. Mark the protective side of the sheet in each panel because after removing the transportation film, the sides of the panel do not visually differ.
- Page 19 MOUNTING ON THE FOUNDATION L1=L2 4020 1000 1000 №45 from «5 package ALFA» х8 1 pc. х24 №44 from «5 package ALFA» 1 pc. №42 from «5 package ALFA» №39 from 1 pc. «5 package ALFA» 1 pc.
- Page 20 Mounting of decorative steel lining on the doors and windows (seal). №42 from Additional kit (purchase separately). «5 package ALFA» 26 pc. №60,№61,№62,№63 №64,№65, from additional №66,№67 package of steel lining №42 from from the additional package of steel «5 package ALFA» lining 17 pc.
