- Page 1 Сертифицировано Русским Регистром www.serrashop.it DACHNAYA STRELKA-3 PREMIUM cellular polycarbonate greenhouse width 3,0 m any length multiple to 2 m Technical certificate page 2-6 Installation manual page 7-22...
- Page 2 Technical certifi cate Perform installation and operation of the greenhouse in strict accordance with the manual and operating rules stated in the technical certifi cate. Please keep this technical certifi cate for further reference. DESCRIPTION DACHNAYA-STRELKA-3 greenhouse is designed for creation of microclimate favorable for growing garden crops on cottage and household plots.
- Page 3 Technical certifi cate Dachnaya-Strelka-3 detailed parts list Table 4 marking name quantity (pcs) 1st package (balks and straight elements) balk door diagonal door diagonal cover plate small window horizontal element small window vertical element hooks 2nd package (arc elements) 4н bottom arc 4в...
- Page 4 Technical certificate Vstavka insert detailed parts list Table 5 1st package balk 2nd package support stand 4н bottom arc 4в top arc horizontal strainer side brace brace strut liner stiffening boom 3rd package ridge profile 4th package angle ridge cover plate bottom wire bandage top wire bandage screw M5x10...
- Page 5 Technical certifi cate Operating rules Before use of greenhouse, assemble When installing the greenhouse by and install it in accordance with the third parties, buyer should supervise compliance of installation with the manual. manual. In winter, coverage of greenhouse should not be removed provided that Do not install greenhouse close to snow load is limited.
- Page 6 Technical certificate Warranty Warranty 1. Manufacturer is responsible for full completing frame elements of greenhouse. 2. Manufacturer is responsible for assemblability of the greenhouse in accordance with the manual. 3. Manufacturer is responsible for durability of the greenhouse under specified values of weather impact.
- Page 7 Manual Dachnaya Strelka-3 greenhouse installation manual Introduction General view of frame is represented in Fig. 1. Mount details in such a way to make side shelves facing coverage. Assemble the frame from numbered elements. Legend: Some elements have free - arrow indicates installation holes resulted from elements’...
- Page 8 Manual General view of DACHNAYA-STRELKA greenhouse frame Fig. 1 4в А 4в Д 4н В 4н Б 6к 6к Е Г 4Н 4В 4В 4Н 4Н 6к ridge cover angle angle А (outside view) Б (inside view) В (inside view) 4В...
- Page 9 Manual General view of DACHNAYA-STRELKA-3 greenhouse frame Fig. 2 General view of Vstavka insert for Dachnaya Strelka-3 greenhouse. Each insert extends greenhouse length by 2 m. Fig. 3 Dachnaya Strelka-3 extended by any number of inserts 3000 1071 Fig. 4 Greenhouse foundation support layout plan.
- Page 10 Manual Installation sequence Perform the installation close to location of the greenhouse. Install greenhouse in accordance with photographs of installation stages and units represented in Fig. 5…12. The fi gures show installation of greenhouse of 4 m length. Required length is reached using attachment of appropriate number of Vstavka insert packages.
- Page 11 Manual Assembling stages 4в Connect arcs 4н to arcs 4в 4в from one side of 4в 4н 4н greenhouse. 4в 4н 4в 4н 4в 4н Fig. 7 4н 4н 4н Connect balks 2 to arcs 4н 4н 4н 4н 4н Fig.
- Page 12 Manual Assembling stages В А Г Д Е Б Fig. 11 А Б В 4н 4в Г 4в Д 4н Install side braces 10 on each arc inside of greenhouse frame. Assemble side brace assembled from two elements 10. Mount side brace liner 11 on the joint of elements 10 and connect it to arc 4н.
- Page 13 Manual Assembled door and end small window Assemble door and end small window from elements 12, 13, 14, 15 (Fig.12) Small window А А Door Б Б Fig. 12...
- Page 14 Manual Cutting and fastening of coverage CUT POLYCARBONATE SHEET STRICTLY IN ACCORDANCE WITH Fig. 13(а) or 13(б) CUT POLYCARBONATE SHEET STRICTLY IN ACCORDANCE WITH и Fig. 14 2100 x 600 mm cellular polycarbonate sheet Be careful! In windy weather, load polycarbonate sheet edges with burdens. 1110 Left end side...
- Page 15 Manual elements 7 and 8, and top edge at 30 mm above bottom edge of element 5. Cut a stencil. Mark the rest of sheet using the stencil in accordance with cutting scheme (Fig. 13а or 13б). Mount cellular polycarbonate strictly facing sun with a side having protective layer (by all means, clarify it under purchase or before mounting).
- Page 16 Manual Раскрой и крепление покрытия торца Cutting and fastening of coverage Cut ridge coverage pieces located above the door at the place of installation from remaining pieces. Mark marking 4в coverage by elements 4в with allowance aligning bottom edge of the sheet with bottom edge of element 5 (Fig. 15).
- Page 17 Manual Cutting and fastening of coverage door sealer Fig.18 hinge adhesive coverage tape coverage hinge sealer adhesive handle door sealer tape door sealer hinge sealer washer adhesive tape coverage hinge coverage handle washer angle coverage screwМ5х14 hinge Fig.19 adhesive adhesive adhesive tape tape...
- Page 18 Manual Cutting and fastening of coverage Mount end cover plate 16 on end coverage and fasten it on element 5 through coverage (Fig. 20 and 24). Joint of end coverage pieces is under element 16. Fig.21 Fig.20 ridge panel screw element 19 small window...
- Page 19 Manual Cutting and fastening of coverage 8. Install end washers and hooks in accordance with Fig.24. washer screw М4х10 angle end coverage screw М5х35 hook washer ground level angle Fig.24 Install tubular reinforcing elements of door opening in accordance with Fig. 25 tubular reinforcing element Fig.25...
- Page 20 Manual Cutting and fastening of coverage cutting edges. (Fig. 26). edges. Remove protective 9. For top coverage, fi lm from polycarbonate cut 6x2.1 m sheets in without violation of relative halves per 3x2.1 m pieces position of sheet halves. keeping right angle of Cover polycarbonate cutting line to sheet side cellular with adhesive tape...
- Page 21 Manual Cutting and fastening of coverage tape on frame from the sheets of polycarbonate in bandage using angles and screws M5x50 (Fig. 28). end and mount them with a similar way and mount equal overlapping the them with overlapping arc edge. If side edges previous sheet.
- Page 22 Manual Cutting and fastening of coverage Fasten coverage over all bottom elements 2 in accordance with Fig.29 - washers Fig.29 12. . by hand into opposite outside of the greenhouse. Insert wire rotator direction (Fig. 31). Mount for door closing in free elastic headers on the holes (against the stop) rotator (Fig.
