- Page 1 VOLYA COMPANY G R E E N H O U S E P R O D U C T I O N DACHNAYA DVUSHKA COMPACT honeycomb polycarbonate greenhouse height 2.2 m length 2.0; 4.0; 6.0 m width 2.0 m...
- Page 2 Technical certificate Perform assembling and operation of the greenhouse in strict accordance with the manual and operating rules stated in the technical certificate. Please keep this technical certificate for further reference. Description Dachnaya Dvushka greenhouse if designed for creation of microclimate favorable for growing garden crops on cottage and household plots.
- Page 3 Technical certificate Dachnaya Dvuska detailed parts list Table 3 marking name quantity (pcs.) 1st package stand 2к end balk 2кк ridge balk supports foundation stand 2nd package 4ВК top end arcs 4В top arc 4Н bottom arcs 3rd package end connecting elements (bottom) 9-1л...
- Page 4 Technical certificate Dachnaya Dvuska detailed parts list marking name quantity (pcs.) 4th package hinge for door and small window hook arm screw M4 х 8 screw M4 х 14 screw M4 х 25 screw M4 х 40 nut M4 washer special wrench adhesive tape lock blank part (rotator with 2 elastic headers)
-
Page 5: Operating Rules
Technical certificate Operating rules The greenhouse is designed for no more than 30 m/s wind speed and 240 kg/m2 snow load that correspond approximately to 0.6 m packed snow layer. Before use of the greenhouse, assemble and install it on the ground in accordance with the manual. -
Page 6: Warranty
Technical certificate Warranty Warranty 1. Manufacturer is responsible for full completing frame elements of greenhouse. 2. Manufacturer is responsible for assemblability of the greenhouse in accordance with the manual. 3. Manufacturer is responsible for durability of the greenhouse under specified values of weather impact. 4. - Page 7 Manual Dachnaya Dvushka greenhouse installation manual Introduction General view of frame is represented in Figure 1. Install details in such a way to make profile side shelves facing coverage. Frame is constructed from numbered elements. Some elements are composed of several parts having equal number but different index. Indices: К...
- Page 8 Manual General view of Dachnaya Dvushka greenhouse frame 4ВК 4В 2кк В 2К 4Н 2К А 4Н Е 2к Г Д Fig. 1 Б elements 4 - see. Fig.4 elements 2 - see. Fig .5 elements 12...14 (door and small window) - see. Fig.13,14 2к...
- Page 9 Manual General view of greenhouse frame extended by inserts Fig. 2 One VSTAVKA insert extends greenhouse by 2 m Two VSTAVKA inserts extend greenhouse by 4 m 2-к 2к Г Д Е (outside view) (outside view) (outside view)
-
Page 10: Installation Sequence
Manual Installation sequence Perform assembling close to location of the greenhouse. Assemble greenhouse in accordance with photographs of assembling stages and units represented in Fig. 6…14. Use support layout plan to install the greenhouse on a foundation (Fig.3). When installing on the ground, dig a trench by the frame perimeter at a depth of shovel blade on the site selected for greenhouse installation. - Page 11 Manual Layout of frame arcs and longitudinal connecting elements of greenhouse extended by inserts 4Н 4Н 4Н 4Н 4Н Fig. 4 4ВК 4В 4В 4В 4ВК 4Н 4Н 4Н 4Н 4Н One Vstavka insert Two Vstavka inserts extends greenhouse by 2 m extend greenhouse by 4 m 2к...
- Page 12 Manual Assembling stages 4В 1 STAGE 4Н А В Б Б А Fig. 6 4Н Assemble one load-bearing arc (or required number of load-bearing arcs depending on number of inserts) from elements 1, 3, 4В, 4Н, 22, 23, 24, 25, 26 using screws M4x8, nuts M4.
- Page 13 Manual Assembling stages 4 STAGE А В А В Connect end arc to the section assembled at stage 3. Fig. 9 4Н 5 STAGE Д А А Б В 2к 4Н 2к Г Б Fig. 10 В Г Connect balks in accordance with Fig. 4В...
- Page 14 Manual Assembling stages 6 STAGE 2кк А 4В 2кк 2кк А Connect the second end arc. If greenhouse length is more than two meters, connect required number of inserts sequentially increasing balks Fig. 11 and then connect end arc. Assemble end elements. 7 STAGE В...
- Page 15 Manual Manual Assembled door and small window А Б А Б 13м 13м 13м 14м 14м 12фл 12фл 12фп 12фп 12фл В Г 13м 12фп 14м В Г 13м Fig. 13 13м Small window - outside view Д Ж Д Ж...
- Page 16 Manual Strip Allowance for ground penetration Door Left end Right end side side Small window Fig. 15 Scheme of cutting of honeycomb polycarbonate for installation on a foundation. When installing on the ground, Cutting extend sides line Ridge panel Small window Right end Left end Door...
- Page 17 Manual Cutting and fastening of coverage Cutting layout for greenhouse installation on a foundation is given in Fig. 15. If the greenhouse is installed on the ground, it is recommended to extend bottom end sides for 200 mm for appropriate penetration of polycarbonate in the ground.
- Page 18 Manual Fastening of coverage Join elements 9-3 and 9-4 (Fig. 17) and mount them in accordance with Fig. 19. Press polycarbonate pieces by edges on the side of door and small window by cover plates 9-3, 9- 4 (Fig. 19) leaving holes for rotators. pieces coverage installation above door openings and...
- Page 19 Manual Fastening of coverage Mount end washers and clamps in accordance with Fig. 21. Б А Rotator Short Long clamp clamp Rotator Cover plate Washer Б А Fig. 21 Fasten the coverage using screws washers Fig. 22 accordance with Fig. 22. Some elements still have free holes.
- Page 20 Manual Fastening of coverage Before mounting a sheet, make sure to cover edges with adhesive tape to protect from getting dust, moisture and insects. Cover the top of Dachnaya Dvushka greenhouse of 2 m length with one 6 x 2.1 m sheet and each extending insert with one sheet.
- Page 21 Manual Fastening of coverage Insert a wire rotator for locking of doors and small windows into holes of door opening stands with straight end against the stop. Use the tube to bend the straight end upward by hand (Fig. 25). Such a construction provides elastic tightness of the door in closed position both from inside and outside of the greenhouse.
- Page 22 Manual Installation of sealing from additional 5th package 5th package (sealing profile) consists of 3.5 m door profile, 3.6 m hinge profile and 12 m end profile. Mount sealing profiles by door and small window contour in accordance with Figures 27...31. element 9-1, 9-2 hinge sealer element 12...
- Page 23 VOLYA COMPANY FILM AND HONEYCOMB POLYCARBONATE GREENHOUSE PRODUCTION 1. DACHNAYA STRELKA 2. DACHNAYA-2DUM 3. DACHNAYA-EKO 4. PERCHINA-M /polycarbonate/ /polycarbonate/ /polycarbonate/ /polycarbonate/ width height length width height length width height length width height length 2.6 m 2.5 m multiple to 2 m 3.0 m 2.0 m 4 m/6 m/8 m 3.0 m...
