Page 1 Supra-5000 Digital Cinema and Secured Media Projection System Installation Manual February 22 , 2022 Before installing and operating the projector unit, please read this Installation Manual thoroughly...
Page 2: Table Of Contents
Installation of the Espedeo Supra-5000 ............28 Requirements for the Installation Environment ............. 28 Transport passageway and preparation of machine space ..............28 Environmental Requirements ......................28 Supra-5000 Digital Cinema and Secured Media Projection System - 2 - February 22 , 2022...
Page 3 Network Setup (for Cinema users) ................. 36 Powering Up the Espedeo Supra-5000 ............37 Starting the Projector ....................37 Controlling and Operating the Espedeo Supra-5000 ............37 Overview of Supra Command Center web interface ............38 Home Screen ............................38 Switching ON the Laser Light Source ....................
Page 4 Introduction ....................... 84 10.2 Dimensions ........................ 85 10.3 Packing List ........................ 86 10.4 Safety Instructions ..................... 89 10.5 Assembly and Installation ..................90 Supra-5000 Digital Cinema and Secured Media Projection System - 4 - February 22 , 2022 Installation Manual...
Page 5 12. Daily Maintenance ..................103 12.1 Preventive Maintenance Recommendations ............. 103 12.2 Filter Components and Maintenance Intervals ............103 13. Switching Off the Espedeo Supra-5000 ............104 14. Projector Specifications ................105 14.1 Projector Dimensions ....................105 14.2 Projector Base Dimensions ..................105 14.3...
Page 6 In no other event shall Espedeo Holdings Limited be liable for any loss of profit or any other commercial damages, including but not limited to special, consequential or other damages.
Page 7: About This Manual
1. About this Manual 1.1 Using this Manual We highly recommend that you read this manual before you install and operate the Espedeo Supra-5000 Digital Cinema and Secured Media Projection System. Within this manual, you will find important information regarding safety, installation, maintenance and other important notes which need to be considered while handling and using this unit.
Page 8: Safety
A person must use a specific tool, lock or key or take other safety measures to access this area. Additionally, access to this area is controlled by the specified agency. Supra-5000 Digital Cinema and Secured Media Projection System - 8 -...
Page 9: Laser Safety Precautions
▪ Any operation or adjustment not specifically instructed by the Supra-5000 Manuals creates the risk of hazardous laser radiation exposure. ▪...
Page 10: Important Safety Instructions
This protects the projector from being damaged by a lightning strike or AC wire surge. WARNING A large current leakage may occur. Therefore, the projector must be grounded properly before it is powered ON. Supra-5000 Digital Cinema and Secured Media Projection System - 10 - February 22 , 2022...
Page 11: Preventing Fire
This is a Class A device that may cause radio interference in a residential environment. In such conditions, the user may need to take practical countermeasures against interference. Supra-5000 Digital Cinema and Secured Media Projection System - 11 - February 22...
Page 12: Preventing Damage To The Projector
Improper grounding, wiring or incorrect use of the projector will result in electric shock. Ground Protection: The equipment shall be connected to a grounded power socket. Before connecting the power supply, check the high-leakage current and ground cable. Supra-5000 Digital Cinema and Secured Media Projection System - 12 - February 22...
Page 13: About Repair
Unauthorized alternatives may result in deteriorated performance and stability, causing fire, electric shock or other hazards. Unapproved alternatives may void the warranty of the projector. Supra-5000 Digital Cinema and Secured Media Projection System - 13 - February 22...
Page 14: Hazard Distance (Hd)
➢ The end-user must take precautions against the hazardous distance. ➢ Installation method, obstacle, detection system or other applicable measures should prevent harmful radiation to the glasses within the hazardous distance. Supra-5000 Digital Cinema and Secured Media Projection System - 14 - February 22...
Page 15: Name And Content Of Hazardous Substances
Though a product may contain a Proposition 65 warning label or marking, it does not mean the product is a threat or danger to the consumer. Espedeo Holdings LLC is committed to the quality and safety of our products and consumers and we comply with necessary government requirements accordingly.
Page 16: Product Safety Labels
Laser Warning Label: Describe the laser levels and compliance standards. Label Description: III. Label Position: Position of the laser warning label, as seen in Figure 1. Figure 1 Supra-5000 Digital Cinema and Secured Media Projection System - 16 - February 22 , 2022 Installation Manual...
Page 17: Product Introduction
⑤ Lift the projector and place it on a surface that complies with the ‘Transportable Area’ instructions specified on the ‘Transport Warning’ label. Figure 2: NOTE Please retain the original packaging for possible RMA shipment in the future. Supra-5000 Digital Cinema and Secured Media Projection System - 17 - February 22 , 2022 Installation Manual...
Page 18: Packing List
3.2 Packing List When unboxing the Espedeo Supra-5000 package; please check the contents in the box against the packing list mentioned in Table 2: Sr. No. Part Description Quantity Espedeo Supra- ① Projector 1 PCS. 5000 Lens 1.28-1.92:1 ② 1 PCS.
Page 19 Quick Installation Guide 1 PCS. Table 2 The required plug type for the Supra-5000 power cord can be specified as per regional requirements. Please refer to Section 4.1.4 for further details. Supra-5000 Digital Cinema and Secured Media Projection System - 19 -...
Page 20: Overview Of The Projector
Alternatively, adjust the replacement cycle appropriately according to the on-site usage of the projector. Figure 4: Supra-5000 Digital Cinema and Secured Media Projection System - 20 - February 22 , 2022...
Page 21: Projector Status Indicator
LED will be always ON. In case of any error or warning; the Green LED will turn OFF immediately and the Yellow or Red LED should start flashing. Refer to Table 3 for the complete list of status indicators for the Espedeo Supra-5000 projector. Figure 5:...
Page 22 Command Center UI. After the error information is handled, the Red indicator turns OFF. Steady ON An error has occurred, resulting in a system Error shutdown. Table 3 Supra-5000 Digital Cinema and Secured Media Projection System - 22 - February 22 , 2022 Installation Manual...
Page 23: Lens
The Projection ratio is the ratio of the projection distance to the width of the screen. The Projection ratio should be within the range of the available lens ratios. Different models of projector lens have different projection ratios. Espedeo provides three types of lenses that you can choose from, as described in Table 4.
Page 24: Adjustable Foot
Refer to Section 10 for more details. Video Source and Interface panels ▪ The Espedeo Supra-5000 can be connected to a Theatre Management System or TMS, using the network interfaces. The LAN1 and LAN2 ports on the DCMB are connected to ▪...
Page 25: Projector Dcmb (Digital Cinema Media Block) Panel Connections
16/24-bit AES/EBU, 16 channels, 48/96 kHz. AUTOMATION ⑧ 4 x GPIO These ports can be used for controlling automation devices. GPIO Table 5 Supra-5000 Digital Cinema and Secured Media Projection System - 25 - February 22 , 2022 Installation Manual...
Page 26: Pib (Projector Intelligence Board) Panel Connections
OS: Main control system status - The system monitors the main control chip. When the main control chip works properly after startup, the LED indicator rapidly blinks Green. Supra-5000 Digital Cinema and Secured Media Projection System - 26 - February 22...
Page 27 LED indicator blinking: The laser control module is waiting for startup. III. LED indicator is steady ON: The laser control module works properly. Table 6 Supra-5000 Digital Cinema and Secured Media Projection System - 27 - February 22 , 2022 Installation Manual...
Page 28: Installation Of The Espedeo Supra-5000
4. Installation of the Espedeo Supra-5000 This section describes how to install, connect and optimize the Espedeo Supra-5000 for the best audiovisual quality. The projector supports two types of installation: forward mounting and ceiling mounting. Forward mounting is the installation method in which the projector is horizontally placed on the special base of the projector, with the magnetic cover of the projector facing up.
Page 29: Espedeo Vm-1140 Vesa Ceiling Mount
The Espedeo VM-1140 is a VESA ceiling mount designed for in-auditorium or in-home installation of Espedeo Supra-5000 Projector. With the help of the VM-1140, the Supra-5000 can be easily mounted to a concrete ceiling or truss. For more details regarding the contents of the ceiling mount kit, dimensions and the installation procedure, refer to Section 10.
Page 30: Power Requirements
Please check the labeling on the Supra-5000 packing (refer to Table 7) to know which type of power supply has been installed in the projector. The two types of power supplies are listed below:...
Page 31: Requirements For Projection Window
▪ Fire gates should be provided. Supra-5000 Digital Cinema and Secured Media Projection System - 31 - February 22 , 2022...
Page 32: Requirements For The Screen
The Cinemas are asked to accurately measure the width, height and projection distance of the screen when showing wide-screen format films and covered format films. Mention the Screen Gain and fill in the data in the ‘Cinema Data Questionnaire’. Please contact Espedeo Holdings Limited for more details.
Page 33: Tools Required For Installation
1 PCS. ⑥ ⑦ Outer hexagon socket 1 PCS. Adjustable Wrench 8# adjustable wrench 1 PCS. ⑧ Lens Cloth 1 PCS. ⑨ Table 9 Supra-5000 Digital Cinema and Secured Media Projection System - 33 - February 22 , 2022 Installation Manual...
Page 34: Lens Installation
▪ Test to see if the projection lens is properly installed by trying to rotate it. Figure 10: Supra-5000 Digital Cinema and Secured Media Projection System - 34 - February 22 , 2022...
Page 35: Instructions For Forward Installation
To ensure optimum optical performance, tilt the projector if necessary. 4.5 Instructions for Ceiling Mounting The Espedeo Supra-5000 projector can be mounted to a concrete ceiling or truss using the Espedeo VM-1140 VESA ceiling mount kit. Please refer to Section 10 for more information related to the Ceiling Mount including the parts list, assembly instructions and installation procedure.
Page 36: Network Setup (For Cinema Users)
4.7 Network Setup (for Cinema users) The Espedeo Supra-5000 projector can be connected to the Media/Content and Management network of the Cinema, as depicted in Figure 11 below. Figure 11: ▪ The LAN1 port of the PIB and the GIGABIT Port 2 of the DCMB should be connected to the Cinema’s Management network, via a network switch.
Page 37: Powering Up The Espedeo Supra-5000
5. Powering Up the Espedeo Supra-5000 5.1 Starting the Projector Before starting the Espedeo Supra-5000 projector, it is essential that you refer to the safety instructions mentioned under Section 2. After connecting the power cable to a recommended power outlet as per your region (refer to Section 4.1.4 for more details), switch ON the power source to the projector.
Page 38: Overview Of Supra Command Center Web Interface
Show the warning and error information of the projector. A shortcut icon for projecting a test pattern. The default test pattern ⑥ Test Pattern can be selected Supra-5000 Digital Cinema and Secured Media Projection System - 38 - February 22 , 2022 Installation Manual...
Page 39 Table 10 NOTE For more information on the various menu options and corresponding functions of the Supra Command Center web interface, please refer to the ‘Espedeo Supra-5000 User Manual’. Supra-5000 Digital Cinema and Secured Media Projection System - 39 -...
Page 40: Switching On The Laser Light Source
Click on the Close Test Pattern button, to clear the test pattern from the screen so that Digital Cinema Package (DCP) content or input from an HDMI source can be projected. Figure 15 Supra-5000 Digital Cinema and Secured Media Projection System - 40 - February 22...
Page 41: Projector Settings
The Macro Settings menu allows you to edit the settings for the default macros of the projector i: e 2D-FLAT, 2D-SCOPE, 3D-FLAT, 3D-SCOPE, HDMI1 and HDMI2. Figure 16: Supra-5000 Digital Cinema and Secured Media Projection System - 41 - February 22...
Page 42: Editing The 2D-Flat Macro
NOTE By default, the source file and PCF file under this macro are imported and the 3D file cannot be selected. Figure 18: Supra-5000 Digital Cinema and Secured Media Projection System - 42 - February 22 , 2022 Installation Manual...
Page 43: Editing The 3D-Flat Macro
‘Save’. The macro will be successfully edited. NOTE By default, the source file and PCF file under this macro are imported and preset 3D file is selected. Figure 20: Supra-5000 Digital Cinema and Secured Media Projection System - 43 - February 22 , 2022 Installation Manual...
Page 44: Switching To Hdmi Macro
You can also add a custom 2D or 3D macro by clicking on the Add New Macro button and importing the relevant Source, Screen, Color, Light Source and Lens files as shown in Figure 22. Figure 22: Supra-5000 Digital Cinema and Secured Media Projection System - 44 - February 22 , 2022...
Page 45 3D file is selected. Figure 24: III. You can now view the created macros under Macro Settings as shown in Figure 25. Figure 25: Supra-5000 Digital Cinema and Secured Media Projection System - 45 - February 22 , 2022 Installation Manual...
Page 46: Installation → Source File Settings
Source file list As an alternative to DCP, you can also use HDMI content input. NOTE: The projector supports only 1080p@60Hz HDMI source Table 11 Supra-5000 Digital Cinema and Secured Media Projection System - 46 - February 22 , 2022...
Page 47: Installation → Screen File Settings
Screen File list You can also edit or delete a newly created screen file or save it as a new screen file. Table 12 Supra-5000 Digital Cinema and Secured Media Projection System - 47 - February 22 , 2022 Installation Manual...
Page 48: Installation → Lens File Settings
You can use the edit option to adjust the offset of the position after the ③ Edit Lens file a new lens is created. Table 13 Supra-5000 Digital Cinema and Secured Media Projection System - 48 - February 22 , 2022 Installation Manual...
Page 49 Enter a name for the new Lens file. ⑥ Save Create a lens file in the current position as a new lens file. Table 14 Supra-5000 Digital Cinema and Secured Media Projection System - 49 - February 22 , 2022 Installation Manual...
Page 50: Installation → Color File Settings
You can edit or verify the corrected color file, save it as a new color file or delete a particular color file. Table 15 Figure 31 Supra-5000 Digital Cinema and Secured Media Projection System - 50 - February 22 , 2022...
Page 51 Checks whether the color is within the standard range after calibration. If yes, it is qualified. Otherwise, you need to find the reason. Table 16 Supra-5000 Digital Cinema and Secured Media Projection System - 51 - February 22 , 2022...
Page 52 3D glasses. ▪ The corrected color files should be differentiated between 2D and 3D and used for the corresponding 2D or 3D macros. Supra-5000 Digital Cinema and Secured Media Projection System - 52 - February 22 , 2022...
Page 53: Installation → Light Source File Settings
② Light Source file list 50% and 100% respectively. You can create suitable light source files according to the actual brightness Table 17 Supra-5000 Digital Cinema and Secured Media Projection System - 53 - February 22 , 2022 Installation Manual...
Page 54: Installation → 3D File Settings
New 3D File Lists all 3D files on the projector. ② 3D File List The default 3D file of the projector is ‘DEFAULT-3D’. Table 18 Supra-5000 Digital Cinema and Secured Media Projection System - 54 - February 22 , 2022 Installation Manual...
Page 55: File Settings For Pm-2000B 3D System
3D File Settings for PM-2000B 3D System To configure the PM-2000B 3D System with the Supra-5000 projector, go to the 3D File Settings menu and click on New 3D File. Set the values mentioned below for the corresponding parameters and save the 3D file by clicking on Save.
Page 56: Installation → Projector Ip Address Settings
NOTE: This setting takes effect only after you restart the projector. ② IP address of LAN2 port The IP address of port LAN2 is fixed to 192.168.254.241. Table 19 Supra-5000 Digital Cinema and Secured Media Projection System - 56 - February 22 , 2022 Installation Manual...
Page 57: Administrator Settings → Time Settings
The Time Settings menu allows you to set ‘Projector Time’ or ‘Auto Synchronize Date and Time’ from an NTP Server, as per actual requirements. Figure 36: Supra-5000 Digital Cinema and Secured Media Projection System - 57 - February 22 , 2022...
Page 58: Administrator Settings → Select Lens
Lens: drop-down. Click the Startup button to initialize the lens. After the initialization is successful, a "Success" message will be shown. Figure 37: Supra-5000 Digital Cinema and Secured Media Projection System - 58 - February 22...
Page 59: Dcmb Settings
DCMB’s operation. 7.1 DCMB IP Address Configuration The DCMB of the Supra-5000 projector has two network interfaces: IMB Ethernet 2 which corresponds to the GIGABIT Port 2 and IMB Ethernet 1 which corresponds to the GIGABIT Port 1 on the DCMB. The IMB Ethernet 2 IP Address is set to a default value of 192.168.1.12 as a part of the standard configuration.
Page 60 Please make sure the IP Addresses assigned to IMB Ethernet 2 and IMB Ethernet 1 network interfaces are unique and DO NOT conflict with the IP values assigned to other devices in the Cinema. Supra-5000 Digital Cinema and Secured Media Projection System - 60 -...
Page 61: Dcmb Storage Configuration
7.2 DCMB Storage Configuration In order to configure the storage for the Supra-5000 projector, you can follow the steps mentioned below: 1. Login to the DCMB Web UI with Maintenance user-level access. 2. Under the Configuration tab, click on the Storage sub-tab.
Page 62 ‘Attached Storage’. For a non-CA 2.0 setup, please choose either ‘CineCache’ or ‘NAS’ as primary storage in Storage Type along with the Priority as ‘IMB Storage’. Supra-5000 Digital Cinema and Secured Media Projection System - 62 - February 22...
Page 63: Dcmb Time Zone Setup
7.3 DCMB Time Zone Setup The DCMB of the Supra-5000 projector may or may not have the local time zone set as per your region. In order to change the time zone on the DCMB, you can follow the steps mentioned below: 1.
Page 64: Content Ingest Management
3. Select the storage device name and drive partition assigned by the DCMB. 4. Click on the OK button to mount the USB drive and select content for ingest. Figure 43: Supra-5000 Digital Cinema and Secured Media Projection System - 64 - February 22...
Page 65: Content Ingest From An Ftp Server
4. Click the Save button to save the FTP details. 5. Once added the FTP Source is added, click on the Open button to select content for ingest. Figure 44: Supra-5000 Digital Cinema and Secured Media Projection System - 65 - February 22...
Page 66: Dcmb Audio Setup
7.5 DCMB Audio Setup The DCMB of the Supra-5000 projector features AES digital audio signal via two RJ-45 Outputs. For compatibility with most audio processors, a standard RJ-45 to DB25 connector (refer to Figure 45) is provided as part of standard packaging.
Page 67 Figure 47: Figure 48: Supra-5000 Digital Cinema and Secured Media Projection System - 67 - February 22 , 2022 Installation Manual...
Page 68: Dcmb Subtitles
It is recommended to use subtitle overlay for subtitle display. To do so, please check Subtitle Overlay Option under the Playback sub-tab of the Configuration tab. Figure 49 Supra-5000 Digital Cinema and Secured Media Projection System - 68 - February 22 , 2022 Installation Manual...
Page 69: Dcmb Automation Setup
7.7 DCMB Automation Setup The DCMB of the Supra-5000 projector is capable of controlling external devices using its Automation interface. This can be used to automate repetitive tasks for the cinema operator to prevent user error. Automation setup for DCMB GPIO The DCMB GPIO automation device settings can be configured using the steps mentioned below: 1.
Page 70: Automation Setup For Ecna Devices
All cues are disabled by default. 6. Click Save to save the settings. Figure 51: Supra-5000 Digital Cinema and Secured Media Projection System - 70 - February 22 , 2022...
Page 71: Automation Setup For Jnior Devices
5. The settings for Port, Login and Password are set to the default values for JNIOR devices if left blank. 6. Click Save to save the settings. Figure 52: Supra-5000 Digital Cinema and Secured Media Projection System - 71 - February 22 , 2022...
Page 72: Automation Setup For Christie Act Devices
6. Default Control Cues will be set up for a new ChristieACT automation device. Control cues – can be added or removed by clicking the buttons. 7. Click Save to save the settings. Figure 53: Supra-5000 Digital Cinema and Secured Media Projection System - 72 - February 22 , 2022 Installation Manual...
Page 73: Automation Setup For Dolby Devices
3. Select ‘DolbyCP650’ as the device Type and enter the Name of the Dolby CP650 device. Click OK. 4. Enter the IP address of the Dolby CP650 device. 5. Click Save to save the settings. Figure 54: Supra-5000 Digital Cinema and Secured Media Projection System - 73 - February 22 , 2022 Installation Manual...
Page 74: Automation Setup For Usl Dax Devices
3. Select ‘USL-DAX’ as the device Type and enter the Name of the USL DAX device. Click OK. 4. Enter the IP address of the USL DAX device. 5. Click Save to save the settings. Figure 55: Supra-5000 Digital Cinema and Secured Media Projection System - 74 - February 22 , 2022...
Page 75: Automation Setup For Usl Jsd Devices
5. Select the correct model (‘JSD-80’ or ‘JSD-100’) of the device the DCMB is connected to. 6. Click Save to save the settings. Figure 56: Supra-5000 Digital Cinema and Secured Media Projection System - 75 - February 22 , 2022...
Page 76: Dcmb 3D Settings For Pm-2000B 3D System
“-120µs” (same value as 5. Set the Output Delay Reference Delay in the 3D File). 6. Click Save to save the settings. Figure 57: Supra-5000 Digital Cinema and Secured Media Projection System - 76 - February 22 , 2022 Installation Manual...
Page 77: Component Engineering Ta-10 Setup
8. Component Engineering TA-10 Setup The Component Engineering TA-10 can be used for cinema automation with the Supra-5000 projector. It requires that the TA-10 be wired in a particular configuration. A wiring diagram can be seen in Figure 58. The TA-10 is connected to the DCMB using the GPIO input/output port. Configure event labels with the GPIO device to trigger the TA-10.
Page 78: Optical Correction
1# and 2# screws at the same time or adjusting 3# screw separately. If there is left-right pitching, adjust it by adjusting 1# and 3# screw or adjusting 2# screw separately until the global picture is clear. Supra-5000 Digital Cinema and Secured Media Projection System - 78 - February 22...
Page 79 Up/Down/Left/Right buttons to adjust the offset and click the Lens Focus Up/Down buttons to make the image focus clear. Provide a name to the new Lens File and click on Save. Refer to Figure 62. Supra-5000 Digital Cinema and Secured Media Projection System - 79 - February 22...
Page 80 Figure 60: Figure 61: Figure 62: Supra-5000 Digital Cinema and Secured Media Projection System - 80 - February 22 , 2022 Installation Manual...
Page 81: Dmd Convergence
Step 2: The convergence adjusting mechanism of the light machine is indicated by the Red circle in Figure 64. It can be adjusted by using the M3 Straight screwdriver. Figure 64: Supra-5000 Digital Cinema and Secured Media Projection System - 81 - February 22...
Page 82 Red and Cyan grid patterns overlap up and down. After the adjustment is completed, the pixel convergence should be < 0.5 pixels. Supra-5000 Digital Cinema and Secured Media Projection System - 82 - February 22...
Page 83 Attention should be paid to the consistency of the adjustment range so that Red and Cyan grid patterns overlap up and down. After the adjustment is completed, the pixel convergence is < 0.5 pixel. Figure 67: Supra-5000 Digital Cinema and Secured Media Projection System - 83 - February 22 , 2022...
Page 84: Espedeo Vm-1140 Vesa Ceiling Mount
The VM-1140 is robust, easy to install and allows angular adjustments in three directions; which makes it easy to fit and position the Supra-5000. The mount is adjustable in height from 240mm (9.45 inches) to 1140mm (44.88 inches). The rotation angle adjustment range is +/- 20º...
Page 85: Dimensions
10.2 Dimensions Figure 69: Supra-5000 Digital Cinema and Secured Media Projection System - 85 - February 22 , 2022 Installation Manual...
Page 86: Packing List
Ceiling Plate 1 PCS. ② Upper Tube 1 PCS. ③ Lower Tube 1 PCS. ④ Top Plate 1 PCS. ⑤ Middle plate 1 PCS. Supra-5000 Digital Cinema and Secured Media Projection System - 86 - February 22 , 2022 Installation Manual...
Page 87 Anchor Bolt ⑪ 10 PCS. (10x60/M8) Safety Cable with ⑫ 1 PCS. 2 PCS of Quick Links ⑬ 1 PCS. Hex key 6 Supra-5000 Digital Cinema and Secured Media Projection System - 87 - February 22 , 2022 Installation Manual...
Page 88 Figure 70 below. The remaining parts ⑫ to ⑭ have been illustrated separately in Step 3B and Step 13 under Section 10.5. Figure 70: Supra-5000 Digital Cinema and Secured Media Projection System - 88 - February 22 , 2022...
Page 89: Safety Instructions
User should inspect the bolts on a regular basis to ensure all bolts are secure. Supra-5000 Digital Cinema and Secured Media Projection System - 89 - February 22...
Page 90: Assembly And Installation
The steps mentioned below explain how to assemble and mount the VM-1140 to a ceiling or truss as well as how to attach and secure the Supra-5000 projector to it. The numbers (① to ⑭) mentioned in these steps refer to the parts listed under Table 10.
Page 91 2. Fasten the safety anchor ⑦ near the ceiling plate ① by using the anchor bolts ⑪ (4 pcs.), as shown in Figure 74. Figure 74 Supra-5000 Digital Cinema and Secured Media Projection System - 91 - February 22 , 2022...
Page 92 First, fasten the truss clamps to the ceiling plate ① without tightening the nuts, as shown in Figure 75. Figure 75: 2. Hook the truss clamps to the truss structure, as shown in Figure 76. Figure 76: Supra-5000 Digital Cinema and Secured Media Projection System - 92 - February 22 , 2022 Installation Manual...
Page 93 ⑭, as shown in Figure 77. Figure 77: Step 4: Slide the top plate ④ over the lower tube ③, as shown in Figure 78. Figure 78: Supra-5000 Digital Cinema and Secured Media Projection System - 93 - February 22 , 2022...
Page 94 Figure 79: Step 6: Slide the middle plate ⑤ over the lower tube ③ and top plate ④, as shown in Figure 80. Figure 80: Supra-5000 Digital Cinema and Secured Media Projection System - 94 - February 22 , 2022...
Page 95 Step 8: Insert the lower tube ③ into the upper tube ②. Please note that for correct alignment/installation of the upper and lower tubes, the rectangular holes must match, as shown in Figure 82. Figure 82: Supra-5000 Digital Cinema and Secured Media Projection System - 95 - February 22 , 2022...
Page 96 Step 9: Tighten the lower tube ③ to the upper tube ② by using the bolts ⑧ (4 pcs.) at the desired height/drop, as shown in Figure 83. Figure 83: Step 10: Attach the projector plate ⑥ to the Supra-5000 projector using the projector mounting kit ⑩ (4pcs.), as shown in Figure 84. Figure 84:...
Page 97 Step 12: Tighten the projector plate ⑥ to the middle plate ⑤ by using the clamping handles ⑨ (4 pcs.), as shown in Figure 86. Figure 86: Supra-5000 Digital Cinema and Secured Media Projection System - 97 - February 22...
Page 98 Figure 88 Step 14: Attach the other end of the safety cable ⑫ to the projector plate ⑥ using a quick link, as shown in Figure 89. Supra-5000 Digital Cinema and Secured Media Projection System - 98 - February 22...
Page 99 Figure 89: Supra-5000 Digital Cinema and Secured Media Projection System - 99 - February 22 , 2022 Installation Manual...
Page 100: Height Adjustment
In case a lower height/drop is required, simply cut the upper tube ② and lower tube ③ ▪ along the two lines: Cut Line A and Cut Line B (refer to Figure 91). Figure 91: Supra-5000 Digital Cinema and Secured Media Projection System - 100 - February 22 , 2022...
Page 101 If the VM-1140 is unavailable in your region, a compatible ceiling mount, VCTUB XL Universal Projector mount (https://www.legrandav.com/products/chief/mounts/projector/ceiling/vct/vctub) ® can be sourced from Legrand Supra-5000 Digital Cinema and Secured Media Projection System - 101 - February 22 , 2022 Installation Manual...
Page 102: Testing Procedures After Installation
11. Testing Procedures after Installation After the installation has been completed, it is necessary to test the following to ensure that the Supra-5000 Projector has been properly installed: 1. Test the video playback capabilities of the Supra-5000. 2. Test the audio playback capabilities of the Supra-5000 and verify that all the macros are working.
Page 103: Daily Maintenance
NOTE Only trained projectionists or qualified maintenance personnel are allowed to perform routine maintenance operations on the Espedeo Supra-5000 projector. Supra-5000 Digital Cinema and Secured Media Projection System - 103 - February 22 , 2022...
Page 104: Switching Off The Espedeo Supra-5000
13. Switching Off the Espedeo Supra-5000 To switch off the Espedeo Supra-5000 digital cinema and secured media projection system, please follow the power down sequence depicted in Figure 94: • From the Supra Command Center, click the Laser Off button on the top menu bar to turn off the Laser Light Source.
Page 105: Projector Specifications
14. Projector Specifications 14.1 Projector Dimensions Figure 95: 14.2 Projector Base Dimensions Figure 96: Supra-5000 Digital Cinema and Secured Media Projection System - 105 - February 22 , 2022 Installation Manual...
Page 106: Certifications
14.3 Certifications Item Compliance Standards and Requirements DCSS/CTP IEC60825-1:2014(Class 1) ，IEC62471-5:2015 (RG2) Laser safety HDMI HDMI 1.4b Table 21 Supra-5000 Digital Cinema and Secured Media Projection System - 106 - February 22 , 2022 Installation Manual...
Page 107: Appendix
Relay ON-resistance: Min = 6 / Typ = 10 / Max = 15 ohms Relay Current limit: Min = 300 / Typ = 360 / Max = 460 mA Relay output power dissipation (continuous) = 600 mW Supra-5000 Digital Cinema and Secured Media Projection System - 107 - February 22...
