- Page 1 PM-2000B 3D Polarized System Installation Manual May 05 , 2021 Before installing and operating the PM-2000B 3D System, please read this Installation Manual thoroughly...
-
Page 2: Table Of Contents
Fixing the Liquid Crystal Splitter assembly to the Mounting Bracket ......13 Passive 3D System Wiring ..................14 3D Working Position Adjustment of Liquid Crystal Splitter ........17 PM-2000B 3D Polarized System Installation Manual - 2 - May 05 , 2021... -
Page 3: System Introduction
The Espedeo PM-2000B is a standalone 3D polarized system specially developed for Espedeo digital cinema projectors. The PM-2000B is designed for easy installation and operation by detecting 2D and 3D signals, which enables the system to shift corresponding working positions automatically. The PM-2000B is suitable for Espedeo Supra-5000 Digital Cinema and Secured Media Projection System in any orientation;... -
Page 4: System Specifications
Contrast ratio ＜ 0.5% Ghosting rate Operating temperature 0~50°C ≤ 60% Operating humidity Optical type Circular polarization Window size of liquid crystal splitter 132 x 66mm Table 2 PM-2000B 3D Polarized System Installation Manual - 4 - May 05 , 2021... -
Page 5: Corresponding Requirements For Cinema
Polarized glasses Espedeo polarized 3D glasses ≥ 2.4 Silver screen: gain coefficient Table 3 Digital Cinema Projector Settings: Black field duration 800μs Delay duration -120μs Table 4 PM-2000B 3D Polarized System Installation Manual - 5 - May 05 , 2021... -
Page 6: System Components
4. System Components The PM-2000B 3D System consists of the following components: Part Description Quantity ① Liquid Crystal Splitter 1 PCS. ② Electric Bracket 1 PCS. ③ Mounting Bracket 1 PCS. Motor Drive Signal Line (50mm) ④ 1 PCS. [connecting electric bracket and... - Page 7 [connecting splitter and projector] ⑥ No. 3 Hexagon Wrench 1 PCS. ⑦ No. 6 Hexagon Wrench 1 PCS. ⑧ M4 Screws 6 PCS. ⑨ M8 Screws 2 PCS. Table 5 PM-2000B 3D Polarized System Installation Manual - 7 - May 05 , 2021...
-
Page 8: Liquid Crystal Splitter
4.1 Liquid Crystal Splitter Figure 1: Liquid Crystal Splitter The liquid crystal splitter is the main optical element part of PM-2000B system with an overall dimension of about 163*128*16mm, which should be handled with care during installation. 4.2 Height Adjustment Bracket... -
Page 9: Electric Bracket
2D content, the liquid crystal splitter automatically moves away from the front of the lens. With the height adjustment bracket included in the accessories, the position of the liquid crystal splitter can be adjusted. PM-2000B 3D Polarized System Installation Manual - 9 - May 05 , 2021... -
Page 10: Installation Of Passive 3D System
Screw the mounting bracket to the projector and then turn the two knobs at the bottom of the mounting bracket to clamp the mounting bracket as shown in Figure 4 and Figure 5. Figure 4: Fixing of Mounting Bracket PM-2000B 3D Polarized System Installation Manual - 10 - May 05... - Page 11 Figure 5: PM-2000B 3D Polarized System Installation Manual - 11 - May 05 , 2021...
-
Page 12: Installation Of Liquid Crystal Splitter
Fix the liquid crystal splitter on the top of the height adjustment bracket with screws (M4 * 6mm), as shown in Figure 6 and Figure 7. Figure 6: Installation of Liquid Crystal Splitter Figure 7: PM-2000B 3D Polarized System Installation Manual - 12 - May 05 , 2021... -
Page 13: Fixing The Liquid Crystal Splitter Assembly To The Mounting Bracket
After installing the liquid crystal splitter and electric bracket, fix them to the mounting bracket as shown in Figure 8 and Figure 9. Figure 8: Fixed to Mounting Bracket Figure 9: PM-2000B 3D Polarized System Installation Manual - 13 - May 05 , 2021... -
Page 14: Passive 3D System Wiring
5.4 Passive 3D System Wiring Figure 10: Wiring of Passive 3D System PM-2000B 3D Polarized System Installation Manual - 14 - May 05 , 2021... - Page 15 Liquid Crystal Splitter and the other end is connected to the motor drive input interface on the electric bracket, as shown in Figure 12. Figure 12: Motor Drive signal line wiring connections PM-2000B 3D Polarized System Installation Manual - 15 - May 05...
- Page 16 / right eye signal can be switched for correction by pressing the L/R switch. Figure 14: L/R switch button for left and right eyes PM-2000B 3D Polarized System Installation Manual - 16 - May 05...
-
Page 17: Working Position Adjustment Of Liquid Crystal Splitter
The 3D working position of the liquid crystal splitter can be set by adjusting the height of the height bracket, as shown in Figure 15 and Figure 16. Figure 15: 3D Working Position Adjustment of Liquid Crystal Splitter PM-2000B 3D Polarized System Installation Manual - 17 - May 05... - Page 18 When a 2D content is played, the passive 3D system won’t block the light path from the digital projector. The liquid crystal splitter will not touch the digital projector lens in the process of moving. PM-2000B 3D Polarized System Installation Manual - 18 - May 05...
