Saracen D12207 Fitting Instructions

Shower Rail

Fittings instruction for the following products:

D12207 - Angled Rail 1675 x 760mm, Silver
D12208 - Straight Rail 1830mm, Silver
D12209 - Straight Rail 2135mm, Silver
D12210 - Angled Rail 915 x 915mm, Silver
D12211 - Straight Rail 915mm, Silver
D12215 - Universal Shower Rail Kit

Fixing Pack Components

a. b. c.
k.
(a) Wall plugs
(b) 11/4" screws
(c) 1" self tapping screw
(d) 1/4" self tapping screw
*Only used with universal shower rail kit.
Note: The universal shower rail kit is supplied with the following rail sections:
Long rail x 1, Short rail x 2, Corner rail x 2

Tools Required (not supplied)

Drill; 5.5mm masonry drill bit, 5.5mm ceramic drill bit (optional), Flat head and cross head
screwdriver, Pencil; Spirit level; Tape measure; Small hacksaw (optional).
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN

Home Safety Advice

• It is recommended that two people fit this product to ensure that it is fitted safely.
• Always take care when using power tools, particularly in the bathroom.
• Always check for hidden cables and pipework before drilling and take extreme care if there is
any water in the working area.
• It is advisable to use a residual current circuit breaker (RCCB).
• Always wear suitable eye protection when drilling.
• If the product is to be fitted on a ceramic tiled wall, a ceramic drill bit should be used.
• Always ensure that the drill hole passes through the central tiled area rather than through the
grouted area. To prevent damage to the tile, mask the area around the hole with tape before
drilling.
• Do not overload the rail. Use a maximum of two standard shower curtains.
• Do not use product as a grab bar.
• Do not strike the product with hard or sharp objects.
• If you find that the curtain gliders stick during use then spray a small amount of furniture
polish into the bottom channel of the rail track to improve the glider performance.
d. e. f.
(e) Gliders and Hooks
(f) End stop and fixing nut
(g) Ceiling hanger support
(h) Ceiling support bracket
g. h.
1
i.
(i) Connector*
(j) Wall bracket Hanger rod
(k) Hanger rod
j.
