Shower Curtain Rod
Fittings instruction for the following product:
D02614 - 1200mm x 1200mm Stainless Steel Shower Curtain Rod
Fixing Pack Contents
(A) Fixing screws x 6
(B) Wall plugs x 6
(C) Hex head key x 1
(D) Spare grub screw x 3
Tools Required (not supplied)
Pencil; Tape measure; Cross-head screwdriver; Spirit level; Drill; 6mm masonry drill bit
(6mm ceramic drill bit optional); Fine toothed hacksaw.
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Note: The wall plugs supplied are for use on solid walls only. For cavity walls or
plasterboard use specialist fixings that are available from all good DIY stores.
Home Safety Advice
• It is recommended that two people fit this product to ensure that it is fitted safely.
• Always take care when using power tools, particularly in the bathroom.
• Always check for hidden cables and pipework before drilling and take extreme care if there is
any water in the working area.
• It is advisable to use a residual current circuit breaker (RCCB).
• Always wear suitable eye protection when drilling.
• If the product is to be fitted on a ceramic tiled wall, a ceramic drill bit should be used.
• Always ensure that the drill hole passes through the central tiled area rather than through the
grouted area. To prevent damage to the tile, mask the area around the hole with tape before
drilling.
• Do not strike the product with hard or sharp objects.
• Do not use product as a grab rail.
Product Care
To retain the best quality finish, clean product regularly with a soft damp cloth.
Do not use abrasive or chemical cleaners as these will damage the product.
Fitting Instruction
1. Lay out the components. Measure around the bath or shower tray to determine exact
dimensions and shape. Join the rod sections together using the corner joint, tapping gently
into place if required.
Note: The rod can be cut to length if required using a fine toothed hacksaw, but always cut
the end of the rod which fits and is concealed within the wall bracket. Ensure the end of the
rod is cut square and is deburred.
1
R&R 048 R01
Advertisement
Table of Contents
Related Manuals for Saracen D02614
Summary of Contents for Saracen D02614
- Page 1 Shower Curtain Rod Fittings instruction for the following product: D02614 - 1200mm x 1200mm Stainless Steel Shower Curtain Rod Fixing Pack Contents (A) Fixing screws x 6 (B) Wall plugs x 6 (C) Hex head key x 1 (D) Spare grub screw x 3 Tools Required (not supplied) Pencil;...
- Page 2 2. Measure the drop of the shower curtain to determine the position of the wall brackets, allowing for the curtain hooks and sufficient overlap in the bath or tray. Place the first wall bracket in the desired location and mark through the screw holes with a pencil. (See Fig.1) 3. Using a 6mm masonry drill, drill the hole in the marked position to a depth of 30mm. If drilling through tiles, please pre-drill using a ceramic drill bit.
