InFocus ScreenPlay SP50md10 Product Dimensions

InFocus ScreenPlay SP50md10 and SP61md10
Ref From Floor
Assume with base
On hard surface.
MODEL A
SP50md10 42.72 19.12 43.43 18.21 2431 2.85 49.88 43.56 52.60 12.80 6.85 168 lbs
Without base
SP61md10 47.91 17.51 47.02 16.60 29.51 1.25 60.81 53.17 62.24 12.80 6.85 188 lbs
Without base
Dimensions (inches) -- for reference only! Weights are approximate.
Note: these dimensions do not include space requirements for cable connections or ventilation.
This television is a table model and is designed to sit on a firm, flat, surface. Don't place the TV on soft carpeting
or similar surface because the ventilation slots on the bottom of the unit will be blocked resulting in reduced
lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the
top and sides of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces. If used with the
optional wall mount, adequate ventilation must also be maintained to allow unrestrained exhaust and intake of
room temperature air. Also, make sure the stand or base you use is of adequate size and strength to prevent the
TV from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or damage
the TV.
B C D E F G H I
Product Shipping
J k Weight Weight
200 lbs
116 lbs
225 lbs
135 lbs
1
