InFocus TD30 Supplementary Manual

Remote Control button mapping

IR Protocol: NEC, Custom Code 07F8
Button HEX Data Code
Power
Source
Info
Up Arrow
Down Arrow
Left Arrow
Right Arrow
Play/PiP
Audio Source
Sleep
Reset
Aspect
Mute
Swap
1
2
3
4
5
6
7
8
9
Recall
0
100
CH +
CH -
Vol +
Vol -
MTS
FAV.D
FAV.A
FAV
Function
87 Toggle Power
85 Input signal
91 Bring up display
9 Navigate up in the OSD
80 Navigate Down in the OSD
89 Navigate Left in the OSD
D0 Navigate Right in the OSD
DO Turn the PiP Mode On/Off
94 Change the Main Audio Input
84 Sleep Timer
82 Recall default value
DC Change Scaling Mode
C0 Mutes main audio
D4 Swap the Main and PiP Windows
86 Direct Access for Main Input, #1
8E Direct Access for Main Input, #2
8A Direct Access for Main Input, #3
8C Direct Access for Main Input, #4
8F Direct Access for Main Input, #5
CC Direct Access for Main Input, #6
9C Direct Access for Main Input, #7
9F Direct Access for Main Input, #8
C4 Direct Access for Main Input, #9
95 Switch to Last Chosen Channel/Input
90 Direct Access for Main Input, #0
98 Direct Access for Main Input, #100
93 Increment Main Input Channel
97 Decrement Main Input Channel
92 Increase Main Volume
96 Decrease Main Volume
83 Change the Main Audio Enhancement
CB
88
99
