InFocus SP50MD10 Code Manual

InFocus HDTV Remote Hexcodes Including Discrete Hexcodes
Label/Function
1 ON-OFF
2 TV
3 DVD (RCA default of 3000);
AUX/AUX-HD programmed
to 3000; AUX/AUX-HD
programmed to universal
DVD
4 VCR (RCA default of 2000);
AUX/AUX-HD programmed
to 2000
5 SAT/CABLE (RCA default
of 5000 SAT1); AUX/AUX-
HD programmed to 5000
SAT1 or AUX programmed
to universal SAT or CABLE)
5 SAT/Cable (programmed to
5001 SAT2 or AUX/AUX-
HD programmed to 5001
SAT1
6 AUX (default 2001 VCR2;
any VCR programmed to
AUX or AUX-HD)
7 AUDIO default 4003;
AUDIO or AUX
programmed to 4003;
AUDIO or AUX
programmed to universal
amp or AV receiver
7 AUDIO or AUX
programmed to 4004
7 AUDIO or AUX
programmed to RCA
PHONO 4005 or universal
PHONO
7 AUDIO or AUX
programmed to RCA TAPE
4006 or universal TAPE
7 AUDIO or AUX
programmed to RCA CD
4007 or universal CD player
8 GO BACK
9 CH+
10 CH -
11 MUTE
12 VOL+
13 VOL-
14 GUIDE
15 CLEAR
16 INFO
17 MENU
18 (UP)
19 (DOWN)
20 (LEFT)
21 (RIGHT)
22 OK
23 DIGIT 1
24 DIGIT 2
25 DIGIT 3
26 DIGIT 4
27 DIGIT 5
28 DIGIT 6
29 DIGIT 7
30 DIGIT 8
31 DIGIT 9
32 DIGIT 0
* For a complete description of remote functions (excluding discretes), see User's Manual.
Note 1: By default, the TV responds to the 0 ("TV1") preamble. However, this can be
changed in the Connections > Special Features > Remote Setup menu so that the TV
responds to either the 5 ("TV2") or E ("TV3") remote preambles. (This might be done to
avoid command conflicts if there are 2 or 3 TVs within IR range of each other and you want
to control each TV independently). If that change is made in the menu, then the TV
responds to the hexcodes listed here, but with the assigned preamble (e.g., OK is now 50B
or E0B instead of the default 00B). When making this change, the remote must also be
programmed; see the User's Manual for instructions.
Note 2: Whereas the TV and remote will be able to be switched to support TV2 and TV3
preamble, the KBR755TA1 keyboard cannot. Therefore, if a user has three co-located
RCA/InFocus HDTV's, the keyboard will operate only with the TV which responds to the
"TV1" (0) preamble (i.e., the default preamble).
Hexcode Comments*
0D5 Power Toggle for last-used
mode of remote
0C5 Discrete TV Power On
AC5 Discrete RCA DVD Power
On; Works with AutoTuning
Feature
1C5 Discrete RCA DVD Power
On; Works with AutoTuning
Feature
8C5 Discrete RCA SAT/Cable
Power On; Works with
AutoTuning Feature
BC5 Discrete RCA SAT/Cable
Power On; Works with
AutoTuning Feature
2C5 Discrete RCA VCR2 Power
On; Works with AutoTuning
Feature
3C5 Discrete RCA AUDIO
Receiver Power On; Works
with AutoTuning Feature
4C5
5C5
6C5
7C5
0D8 Last channel; go back to
previous menu or exit main
menu
0D2 Channel Up; Page+ in Guide
0D3 Channel Down; Page- in
Guide
0C0 Note: In remote, Volume
Punchthrough to Audio Amp
0D0
can be assigned.
0D1
0E5 Brings up program guide.
0F9 Clears out of on-screen
displays (exit)
0C3 Shows full channel banner.
0F7 Brings up main menu.
0A6
Navigation
0A7
0A9
0A8
00B
0CE
0CD
0CC
0CB
0CA
0C9
0C8
0C7
0C6
0CF
Label/Function
33 INPUT
INPUT+0 =
INPUT+1 =
INPUT+2 =
INPUT+3 =
INPUT+4 =
INPUT+5 =
INPUT+6 =
INPUT+7 =
INPUT+8 =
INPUT+9 =
INPUT+ON-OFF =
Discrete Off
34 REVERSE
35 PLAY
36 FORWARD
37 RECORD
38 STOP
39 PAUSE
40 SKIP
LOW VOLTAGE (LVD)
41 SOUND
42 BACKLIGHT
43 ANT-CAB
Discrete Cable Input
Discrete Antenna Input
44 PIP
45 SWAP
47 CH CTRL
46 FORMAT
Discrete "Normal" Screen
Format
Discrete "Stretch" Screen
Format
Discrete "Zoom" Screen
Format
Discrete "Cinerama"
Screen Format
48 FREEZE
49 PRESETS
Discrete Vibrant (Day)
Picture Preset
Discrete Natural Picture
Preset
Discrete Cinematic
(Night) Picture Preset
Discrete Videogame
Picture Preset
Discrete Professional
Picture Preset
Discrete Personal Picture
Preset
50 CC
51 FAV
FAV+0 = "FAV HOME"
FAV+1 = "FAV 1"
FAV+2 = "FAV 2"
FAV+3 = "FAV 3"
FAV+4 = "FAV 4"
FAV+5 = "FAV 5"
FAV+6 = "FAV 6"
FAV+7 = "FAV SEARCH"
FAV+8 = 8
FAV+9 = 9
* For a complete description of remote functions (excluding discretes), see User's Manual.
Hexcode Comments*
05C Toggle to next input (video
source)
054 Discrete Front Input (video
source) (N/A to Slim DLP)
055 Discrete Input 1
(composite/S-video source)
056 Discrete Input 2
(composite/component video
source)
057 Discrete Input 3
(composite/S-video source)
058 Discrete Input 4
(composite/component video
source)
075 Discrete HDMI/DVI Input
(video source)
076 Discrete DTVLink Input
(video source) then toggle
077 UNDEFINED Discrete Input
(video source)
(8 code) -
(9 code) -
0C4 Discrete TV Power Off
0E2
0EA
0E3
0E8
0E0
0E6
0AC Skip Timer
00F When remote batteries get
low, a code is sent and the
TV notifies the user.
0A5 Audio Mode / SAP Toggle
0E1 For factory use
0FA Toggle between Antenna
Input and Cable Input
033
034
0E4 Pip on/off toggle
03C PIP swap main/PIP windows
01A Toggle channel focus on
main or PIP
06F Toggle Screen Format
(Aspect ratio)
035
036
037
067
0F3 Freeze picture
0ED Toggle Picture Presets
021
022
023
024
025
026
07F Toggle closed captioning
- (Need to press a number
after FAV to launch a web
browser favorite website)
0x20 (PPM5)
0x80 (PPM5)
0x81 (PPM5)
Launches favorite web
0x82 (PPM5)
browser websites that have
0x83 (PPM5)
been stored.
0x84 (PPM5)
0x85 (PPM5)
0xD7 (PPM5)
(8 code) -
(9 code) -
