UNBOXING & ASSEMBLY instructions
GB:
WARNING
ES:
IMPORTANTE
F:
IMPORTANT
DE:
ACHTUNG
I:
IMPORTANTE
P:
IMPORTANTE
RUS:
NL:
BELANGRIJK
S:
VIKTIGT
重要なことがわからない場合は、Red Shark Bikesにお問い合わせください。
JP:
Before anything, read user's manuals
reference. Incorrect handling of this product could possibly result in personal injury or physical damage. The manufacturer assumes no responsibility for any damage caused by
mishandling that is beyond normal usage defined in these manuals of this water bike
IF YOU DO NOT AGREE FULLY TO ALL OF THESE PROVISIONS, YOU SHOULD NOT USE RED SHARK BIKES PRODUCTS.
BIKE SURF
(Personal Water Craft)
If you don't understand something please contact to Red Shark bikes.
Si no entiende algo, por favor contacte con Red Shark Bikes.
Si vous ne comprenez pas quelque chose, veuillez contacter Red Shark Bikes.
Wenn Sie etwas nicht verstehen, wenden Sie sich bitte an Red Shark Bikes.
se non capisci qualcosa, contatta Red Shark Bikes.
Se você não entender alguma coisa, entre em contato com a Red Shark Bikes.
ВАЖНО
Если вы что-то не понимаете, пожалуйста, свяжитесь с Red Shark Bikes.
als u iets niet begrijpt, neem dan contact op met Red Shark Bikes
Om du inte förstår något, vänligen kontakta Red Shark Bikes.
of this water bike to ensure correct usage through understanding. After reading, store them in a safe place for future

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADVENTURE and is the answer not in the manual?

Questions and answers

Summary of Contents for RedShark Bikes ADVENTURE

  • Page 1 BIKE SURF (Personal Water Craft) UNBOXING & ASSEMBLY instructions WARNING If you don't understand something please contact to Red Shark bikes. IMPORTANTE Si no entiende algo, por favor contacte con Red Shark Bikes. IMPORTANT Si vous ne comprenez pas quelque chose, veuillez contacter Red Shark Bikes. ACHTUNG Wenn Sie etwas nicht verstehen, wenden Sie sich bitte an Red Shark Bikes.
  • Page 2 ASSEMBLY INSTRUCTIONS ADVENTURE model FITNESS model ENJOY model...
  • Page 3 ASSEMBLY INSTRUCTIONS Please open the 2 boxes (from top side) and carefully remove all parts from the box. Remove all plastic bags and protections carefully. WARNING: Plastic bags can be dangerous, to avoid danger of suffocation, keep all the bags away from all babies, children, and house pets.
  • Page 4 PARTS & elements ENJOY model 16. PEDALS: 8. HANDLE bar 9. GRIPS 5. Seat post CLAM LEFT 17. PEDAL CRANK : RIGHT LEFT 1. FRAME 10. STEM 2. BOTTLE RIGHT 20. MULTI-TOOL KIT 22. REPAIR kit 3. BOTTLE cage 22.1 Valve tool 0.
  • Page 5 PARTS & elements FITNESS model 16. PEDALS: 8. HANDLEbar 5. Seat post CLAM LEFT / RIGHT 17. PEDAL CRANK: 9. GRIPS (Red or Black) LEFT / RIGHT 1. FRAME 10. STEM 35. DRY BAG 20. MULTI-TOOL KIT 25. Bungee NET for the dry bag (already 22.
  • Page 6 PARTS & elements ADVENTURE model 8. HANDLE bar 35. Smart phone holder (for handlebar) 9. GRIPS 10. STEM 34. Handlebar BAG 20. MULTI-TOOL KIT 36. NET board 33. Saddle BAG 5. Seat post CLAM 22. REPAIR kit board 25.1 & 25.2 Bungee NET to secure dry bag (on the fame) 0.
  • Page 7: Saddle Assembly

    ASSEMBLY INSTRUCTIONS SADDLE assembly Untight the bolt, adjust the seat to your SADDLE position adjustment (horizontal) position and tight the bolt. TORQUE SPECIFICATIONS: 7 Newtons...
  • Page 8 ASSEMBLY INSTRUCTIONS SADDLE assembly in the frame C Open and adjust seat Post CLAMP position Check your height TIGHT the post clamp 4.6. Check your position 45º Adjustment recommendations...
  • Page 9: Rudder Assembly

    ASSEMBLY INSTRUCTIONS RUDDER assembly 5.1. Insert the rudder BAR in to the frame 5.2. Pull the ruder post up to the screw...
  • Page 10 ASSEMBLY INSTRUCTIONS RUDDER assembly Insert the rudder BAR in to the frame TOP hole 7.2. Pull the ruder post up to the screw BOTTOM hole...
  • Page 11: Handlebar Assembly

    ASSEMBLY INSTRUCTIONS HANDLEBAR assembly Insert the handlebar in the STEM TIGHT the 4 screws: TORQUE SPECIFICATIONS: 6 Newtons...
  • Page 12 ASSEMBLY INSTRUCTIONS HANDLE BAR assembly 6.1. Insert the rudder post to the STEM 6.2. Line up the handle bar with the rudder. 6.3. Tight the 2 screws Handle Bar Stem TORQUE SPECIFICATIONS 6 Newtons ALIGNMENT WITH THE RUDDER bar W ith the white mark in the center of the stem.
  • Page 13: Transmission Assembly

    ASSEMBLY INSTRUCTIONS TRANSMISSION assembly 7.2. Lower the shaft down 7.1. Untight the 3 bolts 7.3. Correct position until it stops 7.4. Align with the central marked line 7.5. Tighten all the 3 screws Tighten top bolt Tighten bottom bolt Bolt & Locknut Please use a tool 13 From bottom side From top side...
  • Page 14: Pedals Assembly

    ASSEMBLY INSTRUCTIONS PEDALS assembly Find the pedals SIDE Remove Bold and washer EFT crank mark IGTH crank mark Screw the bold with the washer in to the transmisión axel side IGTH side TORQUE SPECIFICATIONS 10 Newtons front Insert the PEDAL crank Insert the WASHER Tight the BOLD direction...
  • Page 15 ASSEMBLY INSTRUCTIONS PROPELLER assembly Remove carefully the plastic protection 9.2. Remove the bold and washer Needle placement PROPELLER placement Tight the bolt and the washer TORQUE SPECIFICATIONS: 4 Newtons...
  • Page 16: Board Assembly

    ASSEMBLY INSTRUCTIONS BOARD assembly 10.1. Extend the board...
  • Page 17 ASSEMBLY INSTRUCTIONS BOARD assembly (Puff up /step 1 from 2) Board HOLE (rear) Board Rudder HOLE (front) KEEP ATTENTION: 1psi Inflate to T h e & H o l e s s u r f a c e : m u s t (approx.) c o m p l e t e l y c l e a n f r o m d u s t , s a n d a n d...
  • Page 18 ASSEMBLY INSTRUCTIONS BOARD assembly 10.3. TURN THE FRAME UPSIDE DOW N 10.4. PROPELLER in vertical position 10.5. RUDDER in vertical position KEEP ATTENTION to protect these elements (handlebars and saddle): To avoid damage to the handlebars and saddle with rough or abrasive flooring (please protect these elements with the SADDLE COVER or putting a rag or towel on the floor where you are going to perform this action ...)
  • Page 19 ASSEMBLY INSTRUCTIONS BOARD assembly Flip the table Board propeller HOLE B (rear) Board Rudder HOLE A (front) KEEP ATTENTION: AVOID THE INTERFERENCES from the rudder and propeller with the board surface (holes A and B) if not it could generate damages on the board. Suggestion: You can use a cloth rag to cover this two elements.
  • Page 20 ASSEMBLY INSTRUCTIONS BOARD assembly Move the board in to the frame Rear Front KEEP ATTENTION: The A & B Holes surface: must be completely clean from Too deep ! dust, sand and other dirty elements. If not it could generate damages on the board skin.
  • Page 21 ASSEMBLY INSTRUCTIONS BOARD assembly FINAL FRAME & BOARD FITTING confirmation with the frame plates Black metal plates (LEVEL GUIDES) must be 10 mm UP from the deck: Too deep! 10 mm 0,35 inch Black metal plates (Front and rear) are just a LEVEL GUIDES and they must not have contact with the deck/board.
  • Page 22 ASSEMBLY INSTRUCTIONS BOARD assembly 10.2. Bottom board INSERT 2 foam caps in the HOLLE B HOLLE B REAR From the BOTTOM SIDE 2 foam cups Put the second cap in Put one cap in the left Push the cap in the hole Push the cap in the hole the right hole hole (between the...
  • Page 23 ASSEMBLY INSTRUCTIONS FRAME & BOARD 10.2. PUFF UP the FINAL AIR PRESSURE From 13 to15 PSI 10.3. Screw the cap onto the valve...
  • Page 24 ASSEMBLY INSTRUCTIONS TENSORS assembly FIRST Confirm the frame position: Must be in vertical position (90º towards the board) 90º 90º 13.2. Pass the strap through 13.3. Pass the strap through the ring of the 13.4. Pull the chassis ring board 13.4.
  • Page 25: Fin Assembly

    ASSEMBLY INSTRUCTIONS FIN assembly 13.1 Insert the fin in the board (bottom rear) slot until the end. Slide the fin onto the bottom side of the board until the end and cross the pin until you hear a click. 13.2 and cross the pin on the hole fin until you hear a click.
  • Page 26: Horizontal Position

    TRANSPORT & manipulation BE CAREFULL on the below elelements RUDDER: in “T” (HORIZONTAL position) REMOVE the FIN PROPELLER: in HORIZONTAL position Keep the PROPELLER HORIZONTAL POSITION...
  • Page 27 TRANSPORT & manipulation WITH TROLLEY (is extra equipment) REMOVE the FIN Trolley BELT...
  • Page 28 TRANSPORT & manipulation ON THE SHORE keep it upright position. LEAVE IT IN THE SHADOW RECOMMENDATION Please us an small STOOL (not included).
  • Page 29 TRANSPORT & manipulation OPTIONS Most MOST recommended recommended...
  • Page 30 ASSEMBLY INSTRUCTIONS 14.1 Unscrew wing nut RUDDER assembly RUDDER FUNCTION “T” as transport 14.2 Chose the position POSITIONS: T: transport • I: level1 • II: Level 2 • III: Level 3 “T”(transport) Screw wing nut TIGHT the wing nut: TORQUE SPECIFICATIONS: 3 Newtons...
  • Page 31 ASSEMBLY instructions BEFORE RIDING check MINIMUM 16.2. RUDDER in VERTICAL position 16.1. FIN position DEPTH: 0,6 m...
  • Page 32 TO GET ON instructions Before start, PRACTICE THIS ACTIONS until you really know, Do it on a calm water with no wind. First moments are the most stressful ones, From the DEEP water: From the BEACH: SEAT on top of the deck And GO! TRANSFER Pedal...
  • Page 33 TO GET ON instructions From a WHARF, boat or similar: Always parallel & from the side PRACTICE THIS ACTION is Grab the handlebar and dangerous, some additional do not transfer the weight support from the wharf it will of your body (from the 2º help you to know how to do it.
  • Page 34 FIRST TIME NOTES: Do it on a calm water with no wind and with the comfort propeller. First moments are the most stressful ones, so you should ride smooth and constantly in a straight line. As soon as you feel stable please turn (left or right) very smoothly but with a constant pedalling. You may have a feeling of having a very smooth roll, this is normal, but it is misleading, your will see, after 30 minutes of pedalling fairly at a medium rate, the strength on your legs.”...
  • Page 35: Warnings And Precautions

    WARNINGS & PRECAUTIONS WARNING PROHIBITION ATENÇÁO / ADVERTENCIA. ACHTUNG / VAROITUS / PROIBIDO / PROHIBICIÓN / VERBOT. KIELTO / VERBOD / DIVIETI / INTERDICTION / W AARSCHUWING / AVVERTENZA / ATTENTION / ZAKAZ / TILTÁS / FÖRBUD. OSTRZEZENIE / FIGYELMEZTETÉS / VARNIG AIR: 13 -14 psi WEAR DO NOT USE IN...
  • Page 36 IMPORTANT: Always wear an approved Personal Flotation Device NEVER use the Red Shark to go further than you can swim, on your own power Like any other device, there is a chance of product failure, always ensure that such failure will not put you in danger Never use under the influence of drugs narcotic substances or alcohol Children and minors under 18 years old, must be used only under adult supervision.
