Dutch Pinball – Technical Support TBL FAQ
rev 0.51
Technical support TBL FAQ
The Big Lebowski is a trademark and copyright of Universal Studios. Licensed by Universal Studios Licensing LLC. All Rights R eserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Big Lebowski and is the answer not in the manual?

Questions and answers

William Bamin
February 23, 2025

After playing the game for say 10 minutes lights begin to flicker then they go out only a couple of the light ramps come back on. The game still plays but points don't register on the areas of no light. On another matter that may be related occasionally the is a loud sound that interrupts the games music - bang like noise that only happens occasionally. I bought the machine new from Pinball Heaven in December 2024 and the code I have is 1.12

0
1 comments:
Mr. Anderson
February 23, 2025

The flickering lights and lack of point registration on a Dutch Pinball *The Big Lebowski* machine could be caused by an issue with the opto sensors. The opto sensors detect when pins are hit and fallen. If the opto is not triggering properly, the machine may not register hits or points. Possible causes include:

1. Misaligned Opto Sensor – If the opto is not properly aligned in front of the hole, it may not detect the ball correctly.
2. Wiring Issues – Faulty or loose wiring to the opto sensor could prevent it from functioning.
3. Wide Opto Beam – The shrinking sleeve on the transmitter narrows the beam. If the beam is too wide, the ball may not fully block it, causing missed detections.
4. Switch Test Needed – Running a switch test can help determine if the opto switch is triggering when obstructed.

Checking and adjusting the opto alignment, wiring, and beam width may resolve the issue.

This answer is automatically generated

0

Related Manuals for Dutch Pinball The Big Lebowski

Summary of Contents for Dutch Pinball The Big Lebowski

  • Page 1 Dutch Pinball – Technical Support TBL FAQ rev 0.51 Technical support TBL FAQ The Big Lebowski is a trademark and copyright of Universal Studios. Licensed by Universal Studios Licensing LLC. All Rights R eserved.
  • Page 2 Dutch Pinball – Technical Support TBL FAQ rev 0.51 Where applicable: based on firmware release 0.55 Caution If you are not comfortable working on pinball hardware and/or high voltage electronics, please get professional support for this. In general: use your common sense. Don’t experiment. Don’t be a nihilist. Only skilled and trained people are allowed to open this system.

  • Page 3: Table Of Contents

    Dutch Pinball – Technical Support TBL FAQ rev 0.51 Table of content Common parts and Tools required rel 0.50 ..................7 Tools ...............................7 Parts ...............................7 Switch test FAQ rel 0.60 ........................8 How do you do this switch-test? .....................9 Coin Door buttons ........................9 Menu function ..........................
  • Page 4 Dutch Pinball – Technical Support TBL FAQ rev 0.51 Reseat the RAM memory on the PC-board ..................38 Rug Toy FAQ rel 0.50 ......................... 39 Principle of operation........................40 Rugtoy makes noise when moving into third position..............42 Rugtoy makes noise when moving into fourth and final position ........... 43 Shots to the rugtoy are not registered ...................
  • Page 5 In the email itself include as many info as you have to be able to help you the fastest and best way possible. Also we would like to refer for more info to the The Lebowski section of the Dutch Pinball website, https://www.dutchpinball.com/the_big_lebowski_pinball .
  • Page 6 Dutch Pinball – Technical Support TBL FAQ rev 0.51 Changelog compared to previous release: • Release 0.50: first release 23 may 2021 • Release 0.51: added MPF kit installation guide...
