Recyko B421 Instruction Manual

Recyko Everyday Charger (USB)
4-Slot NiMH
Instruction Manual
Unpacking and checking
You should find the following items in the packaging*. Please make sure they are undamaged and in
good working order.
B421 Everyday Charger (USB)
4-Slot NiMH
* For exact package contents and quantity, please refer to "In the box" section of the packaging.
Charging instructions
FIg.1
Fig.2a
LED indication
Condition
Charging in progress
Bad or single-use batteries
Charging completed
Charging time^
Size Capacity
Recyko
batteries
AA 1300 - 2600mAh
(2 or 4pcs)
AAA 650 - 950mAh
^ Charging time is subjected to the power rating of the USB adaptor with 5V/1A DC output and varies depending on battery capacities.
B421
Go to gpbatteries.com
for product information
Recyko batteries USB charging cable
(input/output)*
Fig.3
Fig.2b
LED indicator
Green (Flashing)
Green (Rapid flashing)
Green
Charging time (hrs)
4 - 7.5
2.5 - 3.5
Read the instruction manual thoroughly before use.
Keep the manual for future reference.
1. Insert 2pcs or 4pcs NiMH batteries into the battery charger according to the battery polarity. (Fig. 1).
2. Connect the micro USB end of the cable to the micro USB port of the battery charger (Fig. 2a).
3. Connect the other end of the USB cable to a smartphone wall charger (Fig. 2b) or similar USB port
on a computer, power bank or USB car charger.
4. Charging will commence and the LED indicator will show the status of the battery (Fig. 3).The LED
indicator will show the flashing green color when the battery is charging. For bad or single-use
battery, the rapid flashing green color will be shown in the LED indicator when charging.
5. Once the battery is fully charged (LED constant green), remove the battery and disconnect the
battery charger from the power supply.
6. For charging via 4-slot or 8-slot charger dock, please refer to the instruction manual of corresponding
Recyko charger dock.
For best performance and safety, always use NiMH Recyko batteries
Features
• 4 slots charging with 2 LED indication
• Auto power cut-off : Negative delta V & safety timer
• USB power input (5V/1A)
• Trickle charge mode
• Approximate charging time (AA, 2100mAh / AAA, 850mAh): 6/3 hrs
Usage tips
• It is normal for batteries to become hot during charging and they will gradually cool down to room
temperature after fully charged.
• Remove batteries from the electrical device if the device is not going to be used for a long time.
• Battery storage temperature: -20 ~ 35°C
• Charger operation temperature: 0 ~ 35°C
Safety information
• This charger is designed to charge NiMH batteries only. Charging other batteries may lead to
explosion, battery rupture or leakage, personal injury or property damage.
• This charger is designed for indoor use only. Do not expose the charger to rain, snow or direct sunlight.
• Do not use the charger in humid conditions.
• Make sure the charger is used between 0 ~ 35°C.
• Do not use non-rechargeable, LiFePO4, NiCD or Li-ion batteries.
• Do not use the charger if it has a damaged plug.
• Do not use the charger after it has been dropped or damaged. Do not open/disassemble the charger.
• Once the batteries are fully charged, recommend to remove the batteries and disconnect the battery
charger from the power supply.
• In case a battery sleeve is damaged do not use it in the charger.
• Never remove the outer sleeve from batteries.
• Please use the charger in a well-ventilated place and ensure there are no other items covering the
charger to avoid overheating. Do not stack up multiple chargers while charging.
• This charger is maintenance-free but should be wiped clean regularly with a dry and soft cloth. Do not
use sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information
regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
GB
