The manufacturer reserves the right to change and release product firmware
updates and to keep this manual up to date.
https://www.okai.co

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES20 and is the answer not in the manual?

Questions and answers

Related Manuals for OKAI ES20

Summary of Contents for OKAI ES20

  • Page 1 The manufacturer reserves the right to change and release product firmware updates and to keep this manual up to date. https://www.okai.co...
  • Page 2 ES20 Instruction Manual...

  • Page 3: Table Of Contents

    Contents 1.Introduction 1-1.Technical Data 1-2.Symbol Explanations 1-3.List of finished product and parts 2.Intended Use 3.Safety Instructions 3-1.Safety instructions 3-2.Battery safety precautions 3-3. Safety instructions for battery charger 4.How To Use 4-1.Using the product for the first time 4-2.Ride preparation 5.Maintenance,Cleaning and Service 5-1.Maintain 5-2.Clean 5-3.Storage and transportation...

  • Page 4: Introduction

    Failure to comply with this user manual may cause serious injury to people or cause damage to the product. OKAI does not assume any responsibility for this. In order to be concise and easy to read, the OKAI E-Scooter will be referred to as “product” in the following Content.

  • Page 5: 1-1.Technical Data

    1-1.Technical Data Item Content ES20 Dimensions(Unfolding):length,width,height 1145*450*1130(mm) Dimensions(folding):length,width,height 1145*450*400(mm) N.W. 16KG Maximum Speed 25km/h *Range 40Km Specifications Maximum Gradient Adapted Terrain Flat /Mountain Operating Temperature 0～40℃ Storage Temperature —20～45℃ IP Rating Finished product IPX5 Charging Time 2A＜6 Rated Voltage Rated Capacity 9.8Ah （10 series 2 parallel）...
  • Page 6 Item Content ES20 Braking Distance ＜10M Brake The front wheel adopts electric brake, while the rear Brake Type wheel adopts disc brake. Tire Size Front and rear wheel: 8.5inch Tire Front wheel:Pneumatic tire Tire Material Rear wheel:Solid honeycomb tire Input Voltage...

  • Page 7: 1-2.Symbol Explanations

    1-2.Symbol Explanations DANGER Indicates a hazard signal with a high degree of danger. If not avoided, death or serious injury may occur. WARNING A hazard signal that indicates a moderate hazard. If not avoided, death or serious injury may occur. CAUTION A hazard signal that indicates a lower hazard.

  • Page 8: 1-3.List Of Finished Product And Parts

    1-3.List of finished product and parts Speed up Meter Grips Bell Brake lever Headlight Hook up Foldable Front tube Straight tube ambient light Rear light Rear fender Disc brake Folder Kickstand Pedal ambient Front fork light Front Mudguard Frame Side reflector 8.5in Wheel Hub Motor Size: length 1145*width 450*height 1130MM...

  • Page 9: Intended Use

    2.Intended Use ·An electric scooter is intended for sport and entertainment purposes, not for use as a means of transportation, but the transportation faction of the product once you drive it into public areas (as permitted by the laws and regulations of your region and country)also carries potential safety risks for all vehicles.
  • Page 10 4. Do not use this product after taking alcohol, sedatives or psychoactive drugs, so as not to affect your judgment. 5. Keep a distance of at least 1m from pedestrians, other vehicles and any obstacles. 6. This product can only be used when the environment permits it and the personal safety of bystanders is guaranteed.
  • Page 11 36. It is prohibited to refit this product, including steering tubes, steering sleeves, steering rods, folding mechanisms and rear brakes. 37. Accessories and any additional items which are not approved by the manufacturer shall not be used. 38. When riding, the noise should not exceed 70dB. 39.

  • Page 12: 3-2.Battery Safety Precautions

    3-2 Battery safety precautions ·The battery should not be exposed to excessive heat such as sunlight, fire or the like. Otherwise there will be a risk of explosion! ·If this product is not used for more than 30 days, please fully charge the battery. ·Fully charge the battery every 90 days.

  • Page 13: How To Use

    4.How to use 4-1 Using the product for the first time This section provides information on how to use the product correctly. To ensure user safety and service life, it is important to follow these instructions. 1.Take out the charger, wrench, NFC cards, screws and instruction. 2.Remove the front foam, the middle foam cover, and the tail paper from the carton.
  • Page 14 3.Remove the car head from the middle foam, after the wiring harness connection is completed, lift up the front tube, then insert the car head into the front tube and tighten it with screws, and then tighten the embrace hoop. 4.Lift up the front tube，...
  • Page 15 5.Remove the scooter from the carton. 6.NFC key card:In the off state, the NFC key card is close to the screen to turn on and unlock; in the power on state, the NFC key card is close to the screen, shut down and lock the scooter； Function button：...
  • Page 16 7.Wear a helmet and protective gear. 8.Please check the vehicle before each use. Press the brake lever to confirm that braking power is If the folding pole is loose normal. and shaking, tighten as soon as possible using stacker fixing screws. 9.After there is an initial speed through 10.Release the acceleration handle to reduce pedalling,use the throttle to accelerate.
  • Page 17 11.To change the center of gravity when 12.When you need to stop, release the turning, turn the handle slightly. acceleration handle to reduce speed, squeeze and brake the handlebar. Lay down the foot support and let the vehicle lean slightly in the foot support direction so that the foot support touches the ground, and the vehicle can be stabilized.
  • Page 18 14.Folding operation ①Hold the front tube, press the folding handle down and then open it outwards； ②Put down the front tube, the front ③Hold the fronttube to lift the electric tube is automatically locked； scooter.
  • Page 19 15.Activate the app Please scan the QR code to download the app (the system version and Bluetooth version are subject to the actual requirements of the app). You can find the cruise control function in the app, and discover more ways to use the scooter. ①Install APP, please register/login ②...

  • Page 20: 4-2.Ride Preparation

    4-2 Ride preparation Checklist： ·Wheels - check that the wheels are not damaged or excessively worn. ·Loose parts - make sure that all parts, such as nuts, bolts and fasteners are safe. Parts should not make any abnormal sounds. ·Operating area-make sure that the operating area is open and flat without any obstacles. ·Laws and requirements - check and comply with any local laws or regulations.

  • Page 21: 5-3.Storage And Transportation

    5-3.Storage and transportation ·Store the product in a dry, clean place, out of the reach of children, preferably in the original packaging. ·During transportation, turn off the product. ·The product can only be shipped in its original packaging. Don't throw away the packaging because shipping the product may be required in the future.

  • Page 22: Explanation Of Error Codes

    7.Explanation of error codes Error Error name The reason Troubleshooting method number The instantaneous output Overcurrent The controller output current is less current of the controller exceeds protection than 22A and then recovers the current limit range(＞22A) 1. The fault is resolved automatically Undervoltage When the battery voltage is after charging...
