ASSEMBLY INSTRUCTIONS
FBL-848-4G
7.32x2.44m 4G Stadium Pro Goal
A minimum of 2 people are required for this assembly
30
Estimated 30 minutes assembly time
mins
i
IMPORTANT:
the ground to at least the specification detailed in this document
i
IMPORTANT: Please read these assembly instructions carefully
before starting to assemble your goal
(not including sockets)
This goal
must
be secured in sockets concreted into
INS847
Revision 1
03/08/2021
GB2552496
GB2585031
Advertisement
Table of Contents
Related Manuals for Harrod Sport FBL-848-4G
Summary of Contents for Harrod Sport FBL-848-4G
- Page 1 ASSEMBLY INSTRUCTIONS INS847 Revision 1 FBL-848-4G 03/08/2021 7.32x2.44m 4G Stadium Pro Goal GB2552496 GB2585031 A minimum of 2 people are required for this assembly Estimated 30 minutes assembly time mins (not including sockets) IMPORTANT: This goal must be secured in sockets concreted into...
- Page 2 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal Pack Contents Stadium Pro Goal Crossbar L/H Upright R/H Upright Socket Socket Lid Tools Required (FPS273) 1x 4mm Allen Key (supplied) 1x 6mm Allen Key (supplied) 1x Spirit Level Optional Extras FBL-849-4G: 2 Post Freehanging Net...
- Page 3 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal Fittings Pack Contents FPK847: 4G Stadium Pro Fittings Upright Connector Socket Wedge M10x20mm Flange Screw M10x40mm Button Screw M10x30mm Button Screw M6x8mm Button Screw G. M10x16mm Grub Screw PEP899 APS128 BOL347 H. M10 Nord-Lock Washer...
- Page 4 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal Socket Installation Dig 2 holes, L600mm x W600mm x D645-700mm, with the centre of each hole in the centre of the goal line, 7422mm apart. Position the Sockets (4) centrally in the hole with the top of each Socket sitting 45mm below ground level, ensure the straight edge of the Socket is perpendicular to the goal line and the Sockets are sitting vertical.
- Page 5 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal Assembly Instructions (Only required if a Pro Bottom Hinged Net Support is being fitted) Page 4...
- Page 6 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal If a Bottom Hinged Net Support is being fitted; refer to appropriate instruction and fit the hinge assembly before proceeding. WARNING: Carefully lower the goal into the sockets. Dropping the goal in can cause damage to the adjustment mechanism.
- Page 7 Code FBL-848-4G Product 7.32x2.44m 4G Stadium Pro Goal 360°=0.9mm WARNING: Once fitted, ensure the socket wedge is loosened net tension removed before adjusting the goal height. Failure to do so will damage the raising mechanism. WARNING: Use power tools with...
- Page 8 Corresponding net designs; Net Support - Box - Straight Back - Standard Weight 70.5 Goal System Weight; Matrix FBL-303 83.5 70.5 104.5 FIFA Certification number; LBL850 FBL-308 85.5 72.5 106.5 Manufactured in the UK by Harrod Sport in: Page 7...
