Code:
HOC-030
Product:
Folding Wheel Away Hockey Posts
1 2 x
Backboards
2 2 x Right Hand Sideframe
3 2 x Left Hand Sideframe
4 1 x Crossbar (Pair)
1 x Fittings Pack (packed with crossbar) Containing:
5 4 x M10 Nyloc BZP
6 24 x Washer 21od10.5id x 2.5 thick
7 4 x Washer M10 Stainless Steel
8 2 x Net Clips
9 4 x M10 x 60 Hex Bolt
10 8 x M10 x 30 Hex Bolt (on crossbar)
11 12 x M6 x 25mm Eyebolt
11
8
6
5
9
10
7
Brace Holes
10
(FEQ426)
(
FEQ427)
(FEQ428)
(FEQ429)
(BOL202)
(BOL721)
(BOL711)
(CLP040)
(BOL300)
(BOL330)
(BOL612)
Bolt Identification
Sideframe Brace
3
Pack Contents:
IMPORTANT
Please read the assembly instructions carefully
before starting to assemble your goal
TOOLS REQUIRED
2 x 17mm Spanner
1 x 13mm Spanner
1 x Step Ladder (optional)
APPROX ASSEMBLE TIME
2 People 10 Minutes Per Set.
3 People are required to move the goal.
View of Product
4
Net Retaining
Rod
Fig 1
10
1
IMPORTANT
: All freestanding
goals
MUST
be anchored at all times.
Please see additional general anchor
information sheet for assistance in
choosing the correct anchor option
for your goal or contact your
distributor for further advise.
INS589
Revision 2
30/01/2014
©
